SERIES
0402R
ct
du
In
DA
SH
Q
Open Construction
Wirewound Surface Mount Inductors
s
or
Actual Size (Max.)
Physical Parameters
Inches
A
0.050 Max.
B
0.030 Max.
C
0.024 Max.
D
0.020 (Ref. only)
E
0.009 (Ref. only)
F
0.022 (Ref. only)
G
0.026
H
0.019
I
0.018
Millimeters
1.27 Max.
0.76 Max.
0.61 Max.
0.51 (Ref. only)
0.23 (Ref. only)
0.56 (Ref. only)
0.66
0.50
0.46
Operating Temperature Range
–40°C to +125°C
Inductance and Q
tested on HP4291A using HP16193A
test fixture, or equivalent
Packaging
Tape & reel (8mm): 7" reel, 4000 pieces max.
-1N0K
-1N9K
-2N0K
-2N2K
-2N4K
-2N7K
-3N3K
-3N6K
-3N9K
-4N3K
-4N7K
-5N1K
-5N6K
-6N2K
-6N8K
-7N5K
-8N2K
-8N7K
-9N0K
-10NK
-11NK
-12NK
-13NK
-15NK
-16NK
-18NK
-19NK
-20NK
-22NK
-23NK
-24NK
-27NK
-30NK
-33NK
-36NK
-39NK
-40NK
-43NK
-47NK
-51NK
-56NK
-68NK
1.0
1.9
2.0
2.2
2.4
2.7
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
8.7
9.0
10
11
12
13
15
16
18
19
20
22
23
24
27
30
33
36
39
40
43
47
51
56
68
SERIES 0402R CERAMIC CORE
16
12,700
250
16
11,300
250
16
11,100
250
19
10,800
250
15
10,500
250
16
10,400
250
19
7000
250
19
6800
250
19
5800
250
18
6000
250
15
4700
250
20
4800
250
20
4800
250
20
4800
250
20
4800
250
22
4800
250
22
4400
250
18
4100
250
22
4160
250
21
3900
250
24
3680
250
24
3600
250
24
3450
250
24
3280
250
24
3100
250
24
3100
250
24
3040
250
25
3000
250
25
2800
250
24
2720
250
25
2700
250
24
2480
250
25
2350
250
24
2350
250
24
2320
250
25
2100
250
24
2240
250
25
2030
250
20
2100
250
25
1750
250
22
1700
250
22
1620
250
0.045
0.070
0.070
0.070
0.070
0.120
0.066
0.066
0.066
0.091
0.130
0.083
0.083
0.083
0.083
0.104
0.104
0.200
0.104
0.195
0.120
0.120
0.210
0.172
0.220
0.230
0.202
0.250
0.300
0.300
0.300
0.300
0.350
0.350
0.440
0.550
0.440
0.810
0.830
0.820
0.970
1.120
1360
1040
1040
960
790
640
840
840
840
700
640
800
760
760
680
680
680
480
680
480
640
640
440
560
560
420
480
420
400
400
400
400
400
400
320
200
320
100
150
100
100
100
Optional Tolerances (except 1.0nH & 1.9nH): J = 5%
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
