NT
Features
■
Formerly
model
■
Current rating up to 5.3 A
■
Inductance range: 10 µH to 1000 µH
■
RoHS compliant*
Applications
■
■
■
■
DC/DC converters
Power supplies
Desktop notebooks
Output chokes
CO
M
PL
IA
Electrical Specifications (@ 25 °C)
Test Frequency
Part
Inductance
Number
(µH)
RL110-100M-RC
10
RL110-120M-RC
12
RL110-150M-RC
15
RL110-180M-RC
18
RL110-220M-RC
22
RL110-270M-RC
27
RL110-330K-RC
33
RL110-390K-RC
39
RL110-470K-RC
47
RL110-560K-RC
56
RL110-680K-RC
68
RL110-820K-RC
82
RL110-101K-RC
100
RL110-121K-RC
120
RL110-151K-RC
150
RL110-181K-RC
180
RL110-221K-RC
220
RL110-271K-RC
270
RL110-331K-RC
330
RL110-391K-RC
390
RL110-471K-RC
470
RL110-561K-RC
560
RL110-681K-RC
680
RL110-821K-RC
820
RL110-102K-RC
1000
Tol.
±20 %
±20 %
±20 %
±20 %
±20 %
±20 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
±10 %
Q
(Ref.)
20
20
20
20
20
20
20
25
25
25
25
25
25
25
25
25
25
20
20
20
20
20
20
20
20
L
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
1 KHz
Q
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
2.52 MHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
796 KHz
252 KHz
SRF
(MHz)
Typ.
14
11
7.7
7.1
6.8
6.1
6.0
8.6
8.1
7.6
6.3
6.0
5.7
4.8
4.2
3.9
3.8
3.4
2.8
2.7
2.5
2.2
2.1
2.0
1.7
DCR
(Ω)
Max.
0.022
0.023
0.026
0.033
0.037
0.048
0.055
0.073
0.083
0.092
0.12
0.14
0.16
0.20
0.23
0.31
0.34
0.40
0.52
0.65
0.71
1.00
1.10
1.30
1.70
I dc
(A)
5.3
4.9
4.4
4.0
3.6
3.3
2.9
2.7
2.5
2.3
2.1
1.9
1.7
1.5
1.4
1.3
1.1
1.0
0.93
0.86
0.78
0.71
0.65
0.59
0.53
How To Order
Model
Value/Tolerance Code (see table)
Compliance Code
RC = RoHS Compliant
Example:
RL110-471K-RC = 470 µH, ±10 %
REV. 11/13
*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
121
RL110 - 471K - RC
*R
oH
S
RL110 Series - Radial Lead RF Choke
General Specifications
Rated Current .....Inductance drop 10 %,
or 40 °C temperature rise at I dc
Operating Temperature
................................-40 °C to +105 °C
Storage Temperature
................................-40 °C to +105 °C
Materials
Core Material ................................Ferrite
Wire ...........................Enameled copper
Terminal Coating.................................Sn
Marking
............. Value code on top of inductor
Packaging
Standard ...................... 100 pcs. per tray
Product Dimensions
10.0 ± 0.5
(.394 ± .020)
10.0 ± 0.5
(.394 ± .020)
3.5
(.138)
Electrical Schematic
10 - 33
μH
1
2
4.0 ± 0.3
(.157 ± .012)
4
3
1
4
39 - 1000
μH
2
4
2
3
0.7
(.028)
5.0 ± 0.3
(.197 ± .012)
CONNECTION:
10 - 33
μH
..........Pin (1,4) & (2,3)
39 - 1000
μH
......Pin 2 & 4
DIMENSIONS:
MM
(INCHES)
