Surface Mount Low-Profile Power Toroids
SERIES 4501 FERROUS ALLOY CORE
Parallel Connected Specifications
-102M
-104M
-106M
-108M
-110M
-112M
-114M
-116M
-118M
-120M
-122M
-124M
-126M
-128M
-130M
-132M
-134M
0.47
0.68
1.00
2.00
5.00
8.00
10.0
15.0
20.0
25.0
33.0
50.0
68.0
100.0
150.0
200.0
300.0
0.005
0.006
0.008
0.010
0.020
0.025
0.030
0.060
0.080
0.090
0.105
0.200
0.300
0.400
0.550
0.750
1.100
6.50
5.50
5.00
4.50
3.00
2.70
2.50
1.70
1.50
1.40
1.40
0.95
0.80
0.65
0.60
0.45
0.40
0.30
0.40
0.60
1.20
3.00
4.80
6.00
9.50
12.0
15.0
20.0
30.0
40.0
60.0
90.0
120.0
180.0
Actual Size
*Complete part # must include series # PLUS the dash #
For surface finish information, refer to www.delevanfinishes.com
Test Methods
Solderability per MIL-STD-202, Method
208. Inductance tested @ 10 kHz and zero Amps DC.
Tested at 25°C.
Mechanical Configuration
A flat top surface mount case
with excellent coplanarity of terminals.
Physical Parameters
Inches
A
0.285 ± 0.010
B
0.360 ± 0.010
C
0.060 ± 0.010
D
0.350 ± 0.010
E
0.200 ± 0.010
F
0.025 ± 0.010
G
0.040 (Ref.)
Millimeters
7.24 ± 0.25
9.14 ± 0.25
1.52 ± 0.25
8.90 ± 0.25
5.08 ± 0.25
0.64 ± 0.25
1.02 (Ref.)
Electrical Configuration
Two inductors per unit;
internal terminals: #1(start) – #2(finish) &
#4(start) – #3 (finish).
Series
Externally connect #2 to #4.
Parallel
Externally connect #1 to # 4 and # 2 to # 3.
Operating Temperature Range
–55°C to +125°C
Rated DC Current
Based upon 20°C temperature rise
from 25°C ambient.
Maximum Power Dissipation at 25°C
0.230 Watts
Inductance Tolerance
Tolerance is specified by suffixing
an alpha character to the part number as follows: K = 10%,
L = 15%. M = 20%. Units are normally supplied to the
tolerance indicated in the tables.
Marking
Delevan; inductance and tolerance. A white dot
indicates the location of pin 1. Note: RoHS component
components will be marked with 4501R.
Example: 4501-102
DELEVAN
.47uH±20%
Series Connected Specifications
Inductance
Four (4) times parallel inductance specifications.
DCR
Four (4) times parallel DCR specifications.
Rated DC Current
minimum One-half of parallel Rated DC Current
specifications.
Packaging
Tape & reel (24mm):
13" reel, 600 pieces max.; 7" reel not available
Weight (Grams)
1.0 (Ref.)
