R1 Type
H
A±0.25
2.54
5.09
C+1.0
2.54
2.7
5.08
C+1.0
Number of
Contacts
2
3
4
5
6
7
8
9
Dimensions
A
2.54
5.08
7.62
10.16
12.70
15.24
17.78
20.32
22.86
25.40
27.94
30.48
33.02
35.56
38.10
40.64
43.18
45.72
48.26
50.80
53.34
55.88
58.42
60.96
63.50
66.04
68.58
71.12
73.66
76.20
78.74
81.28
83.82
86.36
88.90
91.44
93.98
96.52
99.06
B
5.58
8.12
10.66
13.20
15.74
18.28
20.82
23.36
25.90
28.44
30.98
33.52
36.06
38.60
41.14
43.68
46.22
48.76
51.30
53.84
56.38
58.92
61.46
64.00
66.54
69.08
71.62
74.16
76.70
79.24
81.78
84.32
86.86
89.40
91.94
94.48
97.02
99.56
102.10
2.19
1.
02
2.54
1.02
G
B±0.38
Pin 1
Pin 1
1.02
Ø
Pin 1
R2 Type
A±0.25
Pin 1
2.54
Ø
5.08
2
1 .0
Pin 1
2.54
5.08
Pin 1
10
11
12
13
14
15
16
17
18
19
20
C+1.0
F
B±0.38
(Minimum Insertion Depth)
2.19
2.54
1.02
2.7
1.02
Recommended PCB Layouts
Bottom Entry General Tolerance ±0.05
Solder Area
Recommended PCB Layouts
Top Entry General Tolerance ±0.05
Solder Area
Height = 5.0mm: Pin Size = 0.75mm x 0.25mm
Height = 7.5mm: Pin Size = 0.60mm x 0.25mm
E
Height = 5.0mm: Min. Insertion Depth = 1.55mm
Height = 7.5mm: Min. Insertion Depth = 2.16mm
2.54
C+1.0
21
22
23
H
0.15
C
24
25
26
27
28
D
Specifications
规格
Material
物料
Contact
端子
: Phosphor Bronze
Insulator Material
绝缘½
:
Standard
标准
: Polyamide, Nylon 6T, UL 94V-0
Options
可选
: Polyester, LCP, UL 94V-0
Electrical
电气
Current Rating
电流额定值
: 3 Amp
Insulator Resistance
绝缘电阻值
: 1000 MΩ min.
Contact Resistance
接触电阻值
: 20 mΩ max.
Dielectric Withstanding
耐电压
: AC 600 V
Ordering Grid
BG125
No. of Contacts
02 to 40
XX
X
X
X
XXXX
X
X
Request Samples
and Quotation
29
30
31
32
33
34
35
36
37
38
39
40
C
Contact Plating
A = Gold Flash All Over
(Standard)
B = Selective Gold Flash Contact Area/
Tin On Tail
C = Tin All Over
G = 10µ" Gold Contact Area/Tin On Tail
I = 30µ" Gold Contact Area/Tin On Tail
Height H
1 = 5.00mm
(Standard)
2 = 7.50mm
Packing Options
C = Tape and Reel with Film
(Standard)
B = Tape and Reel with Cap
D = Tube
E = Tube with Cap
F = Tube with Film
Insulator Material
N = Nylon 6T
(Standard)
L = LCP
Dimension C
(Footprint Width) (1/100mm)
0440 = 4.40mm
(Standard when 'H' = 5.00mm)
0420 = 4.20mm
(Standard when 'H' = 7.50mm)
B
A
Environmental & Mechanical
机械
&
环境
Operating Temperature
工½温度
: -40° to +105°C
Soldering Process
可焊性
:
Nylon 6T (Standard
标准物料
) -
IR Reflow
回流焊
: 260°C for 10 sec.
Wave
波峰焊
: 230°C for 5-10 sec.
Manual Solder
人工焊接
: 350°C for 3-5 sec
LCP (Option
可选物料
) -
IR Reflow
回流焊
: 260°C for 10 sec.
Wave
波峰焊
: 250°C for 5-10 sec.
Manual Solder
人工焊接
: 350°C for 3-5 sec
Type
1 = R1 Type
2 = R2 Type
Mates with
配套之母座
(subject to pin length
在端子长度适合的条件下
)
BG020
BG030
BG035
BG055
BG060
BG075
BG080
For bottom entry applications, stringent soldering
control & pin alignment are required as lead to pad
misalignment could cause incorrect mating.
Part Number
Product Description
BG125
Drawing Date
30th October 2006
By
Detail
Revision
Date
AJO
BG125
H PCN
H
07/27/15
Length
2.54mm Pitch Socket
Single Row, Surface Mount, Vertical, Dual Entry
