NRSH472M6.3V12.5X25SP7.5LLF datasheet, PDF

Datasheet> All Categories > Passive components> capacitor> NRSH472M6.3V12.5X25SP7.5LLF

NRSH472M6.3V12.5X25SP7.5LLF: DescriptionAluminum Electrolytic Capacitor, Polarized, Aluminum, 6.3V, 20% +Tol, 20% -Tol, 4700uF,; CategoryPassive components capacitor; File Size200KB，8 Pages; ManufacturerNIC Components Corp; Environmental Compliance

Download Datasheet Parametric View All

NRSH472M6.3V12.5X25SP7.5LLF Overview

Aluminum Electrolytic Capacitor, Polarized, Aluminum, 6.3V, 20% +Tol, 20% -Tol, 4700uF,

NRSH472M6.3V12.5X25SP7.5LLF Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Objectid	831369945
package instruction	,
Reach Compliance Code	compliant
Country Of Origin	Japan, Mainland China, Taiwan
ECCN code	EAR99
YTEOL	6.95
capacitance	4700 µF
Capacitor type	ALUMINUM ELECTROLYTIC CAPACITOR
diameter	12.5 mm
dielectric materials	ALUMINUM (WET)
ESR	15 mΩ
length	25 mm
negative tolerance	20%
Number of terminals	2
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Package form	Radial
method of packing	Bulk
polarity	POLARIZED
positive tolerance	20%
Rated (DC) voltage (URdc)	6.3 V
ripple current	2900 mA
Terminal pitch	5 mm

Preview

Download Datasheet

View All

Miniature Aluminum Electrolytic Capacitors

HIGH TEMPERATURE, EXTENDED LOAD LIFE, RADIAL LEADS, POLARIZED

FEATURES

• IMPROVED ENDURANCE AT HIGH TEMPERATURE

(up to 10,000HRS @ 105°C)

• LOW IMPEDANCE & HIGH RIPPLE CURRENT RATINGS

• NEW REDUCED SIZES

CHARACTERISTICS

Rated Voltage Range

Capacitance Range

Operating Temperature Range

Capacitance Tolerance

Maximum Leakage Current

After 2 minutes

W.V. (Vdc)

S.V. (Vdc)

C < 1,000μF

C = 1,200μF

C = 1,500μF

C = 1,800μF

C = 2,200μF

Max. Tan

at 120Hz/20°C

C = 2,700μF

C = 3,300μF

C = 3,900μF

C = 4,700μF

C = 5,600μF

C = 6,800μF

C = 8,200μF

Z-25°C/Z+20°C

Low Temperature Stability

Impedance Ratio @ 120Hz

Z-40°C/Z+20°C

Duration

Capacitance

Load Life Test

@ 105°C

Tan

6.3 ~ 100VDC

8.2 ~ 8,200μF

-40°C ~ +105°C

±20% (M)

0.01CV or 3μA whichever is greater

6.3

0.22

0.24

0.26

0.28

0.30

0.32

0.36

NRSH Series

EXPANDED!

63V ~ 100V

100

0.19

0.16

0.14

0.12

0.10

0.09

0.08

0.19

0.16

0.14

0.12

0.09

0.08

0.19

0.16

0.14

0.12

0.09

0.08

0.19

0.16

0.14

0.12

0.09

0.21

0.18

0.16

0.14

0.11

0.21

0.18

0.16

0.23

0.20

0.18

0.23

0.20

0.25

0.22

0.27

0.29

D = 5 & 6.3: 6,000 hours,

D = 8: 8,000 hours,

D = 10>: 10,000 hours

Within ±25% of initial measured value

Less than 200% of speciﬁed value

Less than speciﬁed value

100

125

0.08

PART NUMBER SYSTEM

NRSH 221 M 50V 10X16 TB F

RoHS Compliant

TB = Tape & Box*

Case Size (DφxL)

Working Voltage (Vdc)

Tolerance Code (M=20%)

Capacitance Code: First 2 characters

signiﬁcant, third character is multiplier

Series

*see taping speciﬁcations for details

Please review the notes on correct use, safety and precautions found on

pages T10

T11

of NIC’s

Electrolytic Capacitor catalog.

Also found at

www.niccomp.com/precautions

If in doubt or uncertainty, please review your speciﬁc application - process

details with NIC’s technical support personnel:

tpmg@niccomp.com

PRECAUTIONS

NIC COMPONENTS CORP.

www.niccomp.com

www.lowESR.com

www.RFpassives.com

www.SMTmagnetics.com

183
