Tantalum Surface Mount Capacitors – Automotive Grade
T510 Automotive Grade Multiple Anode Low ESR MnO
2
Electrical Characteristics
Impedance, ESR vs. Frequency
100
T510X226M035ATE100_IMP
Capacitance vs. Frequency
100
Impedance, ESR (Ohms)
T510X336M035ATE065_IMP
10
T510E476M035ATE050_IMP
T510X336M035ATE065_ESR
T510E476M035ATE050_ESR
Capacitance (μF)
T510X226M035ATE100_ESR
1
10
T510X226M035ATE100
T510X336M035ATE065
T510E476M035ATE050
0.1
0.01
100
1,000
10,000
Frequency (Hz)
100,000
1,000,000
10,000,000
1
100
1,000
10,000
Frequency (Hz)
100,000
1,000,000
10,000,000
Dimensions – Millimeters (Inches)
Metric will govern
CATHODE (-) END VIEW
W
H
X
T
S
G
S
Termination cutout
at KEMET's option,
either end
SIDE VIEW
B
B
ANODE (+) END VIEW
BOTTOM VIEW
A
E
P
R
L
F
Case Size
KEMET
X
E
EIA
7343–43
Component
L
W
H
F ±0.1 S ±0.3 B ±0.15
±(.004) ±(.012) (Ref) ±.006
2.4
(0.094)
4.1
(0.161)
1.3
(0.051)
1.3
(0.051)
0.5
(0.020)
0.5
(0.020)
Typical
Weight
P
R
T
A
G
E
(Ref) (Ref) (Ref) (Min) (Ref) (Ref)
1.0
0.13
3.8
(0.039) (0.005) (0.150)
0.13
3.8
n/a
(0.005) (0.150)
3.5
(0.138)
3.5
(0.138)
3.5
(0.138)
3.5
(0.138)
X
(Ref)
(mg)
430.15
500.73
7.3 ±0.3
4.3 ±0.3
4.0 ±0.3
(0.287 ±0.012) (0.169 ±0.012) (0.157 ±0.012)
7.3 ±0.3
6.0 ±0.3
3.6 ±0.2
7360–38
(0.287 ±0.012) (0.236 ±0.012) (0.142 ±0.008)
0.10 ±0.10
1.7
(0.004 ±0.004) (0.067)
0.10 ±0.10
n/a
(0.004 ±0.004)
Notes: (Ref) – Dimensions provided for reference only. For low profile cases, no dimensions are provided for B, P, or R because these cases do not have a bevel or
a notch.
These weights are provided as reference. If exact weights are needed, please contact your KEMET Sales Representative.
Fort Lauderdale, FL 33301 USA • 954-766-2800 • www.kemet.com
T2055_T510_AUTO • 9/23/2021
4
Tantalum Surface Mount Capacitors – Automotive Grade
T510 Automotive Grade Multiple Anode Low ESR MnO
2
Table 1 – Ratings & Part Number Reference
Rated Rated
Voltage Cap
VDC at 85°C
4
4
4
6.3
6.3
6.3
10
16
16
20
20
20
25
25
35
35
35
35
35
35
35
50
50
50
VDC at 85°C
µF
680
1000
1000
470
680
680
330
150
220
100
100
100
68
100
22
22
22
33
47
47
47
10
10
22
µF
Case
Code/
Case Size
KEMET/EIA
X/7343-43
X/7343-43
E/7360-38
X/7343-43
X/7343-43
E/7360-38
X/7343-43
X/7343-43
X/7343-43
X/7343-43
X/7343-43
X/7343-43
X/7343-43
E/7360-38
X/7343-43
X/7343-43
X/7343-43
X/7343-43
X/7343-43
X/7343-43
E/7360-38
X/7343-43
X/7343-43
X/7343-43
KEMET/EIA
KEMET Part
Number
(See below for
part options)
T510X687(1)004A(2)A030
T510X108(1)004A(2)A035
T510E108(1)004A(2)A018
T510X477(1)006A(2)A030
T510X687(1)006A(2)A023
T510E687(1)006A(2)A023
T510X337(1)010A(2)A035
T510X157(1)016A(2)A040
T510X227(1)016A(2)A040
T510X107(1)020A(2)A035
T510X107(1)020A(2)A040
T510X107(1)020A(2)A045
T510X686(1)025A(2)A045
T510E107(1)025A(2)A050
T510X226(1)035A(2)A100
T510X226(1)035A(2)A080
T510X226(1)035A(2)A060
T510X336(1)035A(2)A065
T510X476(1)035A(2)A055
T510X476(1)035A(2)A065
T510E476(1)035A(2)A050
T510X106(1)050A(2)A090
T510X106(1)050A(2)A120
T510X226(1)050A(2)A100
(See below for
part options)
DC
Leakage
µA at +25°C
Max/5 Min
27.2
40.0
40.0
29.6
42.8
42.8
33.0
24.0
35.2
20.0
20.0
20.0
17.0
25.0
7.7
7.7
7.7
11.6
16.5
16.5
16.5
5.0
5.0
11.0
µA at +25°C
Max/5 Min
DF
ESR
Maximum Allowable
Ripple Current (rms)
mA at
+85°C
100 kHz
2700
2499
3581
2700
3083
3168
2499
2338
2338
2499
2338
2204
2204
2148
1479
1653
1909
1834
1994
1834
2148
1559
1350
1479
mA at
+85°C
100 kHz
mA at
+125°C
100 kHz
1200
1111
1592
1200
1370
1408
1111
1039
1039
1111
1039
980
980
955
657
735
848
815
886
815
955
693
600
657
mA at
+125°C
100 kHz
Maximum
Operating
Temp
°C
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
125
°C
MSL
Reflow
Temp
≤ 260°C
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
Reflow
Temp
≤ 260°C
% at +25°C mΩ at +25°C mA at +25°C
120 Hz
100 kHz
100 kHz
Max
Max
6.0
30
3000
6.0
35
2777
6.0
18
3979
6.0
30
3000
6.0
23
3426
6.0
23
3520
6.0
35
2777
6.0
40
2598
10.0
40
2598
8.0
35
2777
6.0
40
2598
6.0
45
2449
8.0
45
2449
8.0
50
2387
6.0
100
1643
6.0
80
1837
6.0
60
2121
6.0
65
2038
8.0
55
2216
8.0
65
2038
8.0
50
2387
8.0
90
1732
8.0
120
1500
8.0
100
1643
% at +25°C mΩ at +25°C
mA at
120 Hz
100 kHz
+25°C
Max
Max
100 kHz
Rated
Voltage
Rated
Cap
Case Code/
Case Size
KEMET Part Number
DC
Leakage
DF
ESR
Maximum Allowable
Ripple Current (rms)
Maximum
Operating
Temp
MSL
(1) To complete KEMET part number, insert M for ±20% or K for ±10%. Designates Capacitance tolerance.
(2) To complete KEMET part number, insert T = 100% Matte Tin (Sn)-plated, G = Gold -plated, H = Standard Solder coated (SnPb 5% Pb minimum), N =
Non-Magnetic 100% Tin (Sn), M = Non-Magnetic (SnPb). Designates Termination Finish.
Refer to Ordering Information for additional detail.
Higher voltage ratings and tighter tolerance product including ESR may be substituted within the same size at KEMET's option. Voltage substitution will
be marked with the higher voltage rating. Substitutions can include better than series.
