MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
SKV
SKV
SERIES
105℃, Lead Free Reflow Soldering.
◆FEATURES
•
Load Life : 105℃ 1000 hours.
•
Lead free reflow soldering is available.
•
Available for high density mounting.
•
RoHS compliance.
◆SPECIFICATIONS
Items
Category Temperature Range
Characteristics
−55∼＋105℃
6.3∼50V.DC
±20％（20℃，120Hz）
I＝0.01CV
or 3μA whichever is greater.
(After 2 minutes application of rated voltage)
Rated Voltage Range
Capacitance Tolerance
Leakage Current(MAX)
I＝
Leakage Current
(μA) C＝
Rated Capacitance
(μF) V＝
Rated Voltage
(V)
Rated Voltage
6.3 10 16 25 35 50
(V)
φ4∼φ6.3 0.30 0.24 0.20 0.16 0.14 0.12
tanδ
φ8, φ10 0.35 0.26 0.20 0.16 0.14 0.12
（20℃，120Hz）
Dissipation Factor(MAX)
(tanδ)
After applying rated voltage with rated ripple current for 1000 hrs at 105℃, the capacitors shall meet the following requirements.
Capacitance Change
Dissipation Factor
Leakage Current
Within ±30％ of the initial value. (φ8,10:±25％)
Not more than 300％ of the specified value. (φ8,10:200％)
Not more than the specified value.
Endurance
Low Temperature Stability
Impedance Ratio(MAX)
Rated Voltage
6.3
(V)
Z
（−25℃）（20℃） 4
/Z
Z
（−40℃）（20℃） 8
/Z
10
3
8
16
2
4
25
2
4
35
2
3
50
2
3
（120Hz）
◆MARKING
◆MULTIPLIER FOR RIPPLE CURRENT
Frequency coefficient
60 50） 120
（
（Hz）
0.1∼1μF
0.50 1.00
0.65 1.00
Coefficient
2.2∼4.7μF
10∼47μF
0.80 1.00
100∼1000μF 0.80 1.00
Frequency
〈φ4∼φ6.3, φ8×6.5〉
Series
〈φ8×10.5, φ10〉
500
1.20
1.20
1.20
1.10
1k
1.30
1.30
1.30
1.15
10k≦
1.50
1.50
1.50
1.20
IAA
47
16V
Lot No.
Capacitance
Rated voltage
（6.3WV Marking 6V）
：
Rubycon
100μF
50V
N0538
105℃
Trade mark
Capacitance
Rated voltage
Lot No.
Maximum operating
temperature
Polarity of the terminals
◆PART NUMBER
□□□
Rated Voltage
SKV
Series
□□□□□
Rated Capacitance
□
Capacitance Tolerance
□□□
Option
D×L
Case Size
MINIATURE ALUMINUM ELECTROLYTIC CAPACITORS
SKV
(mm)
◆DIMENSIONS
L MAX
A
1±0.2
φ8×10.5 and φ10 have sleeve.
φD
φD＋0.5MAX
L
A
1
B
1
C
W
1
P
4
5
5.5 4.3 4.3 1.8 0.5∼0.8 1.0
5.5 5.3 5.3 2.2 0.5∼0.8 1.3
B
1±0.2
P
C
6.3 5.5 6.6 6.6 2.7 0.5∼0.8 1.8
C
8
0.3MAX
W
1
0.5MAX
6.5 8.3 8.3 3.4 0.5∼0.8 2.2
10.5 8.3 8.3 2.9 0.8∼1.1 3.1
8
10 10.5 10.3 10.3 3.2 0.8∼1.1 4.5
◆STANDARD
SIZE, RATED RIPPLE CURRENT
Size
φD×L(mm),
Ripple Current (mA r.m.s./105℃, 120Hz)
WV(V.DC)
Cap(μF)
0.1
0.22
0.33
0.47
1
2.2
3.3
4.7
10
22
33
47
100
220
330
470
1000
8×10.5
10×10.5
210
480
5×5.5
6.3×5.5
6.3×5.5
37
57
74
8×10.5
8×10.5
10×10.5
195
210
440
4×5.5
23
5×5.5
34
6.3×5.5
6.3×5.5
8×10.5
8×10.5
10×10.5
10×10.5
56
65
185
195
440
460
8×6.5
8×10.5
8×10.5
10×10.5
10×10.5
118
180
190
353
450
8×10.5
10×10.5
10×10.5
180
305
360
4×5.5
5×5.5
20
31
6.3×5.5
48
4×5.5
5×5.5
6.3×5.5
14
24
46
6.3
(0J)
Size
Ripple
10
(1A)
Size
Ripple
16
(1C)
Size
Ripple
25
(1E)
Size
Ripple
35
(1V)
Size
Ripple
50
(1H)
Size
4×5.5
4×5.5
4×5.5
4×5.5
4×5.5
4×5.5
4×5.5
5×5.5
6.3×5.5
8×6.5
8×10.5
8×10.5
10×10.5
8×10.5
10×10.5
Ripple
1.0
2.0
3.0
4.0
8.0
11
13
18
28
70
135
155
180
200
315
