CY7C1568KV18/CY7C1570KV18

72-Mbit DDR II+ SRAM Two-Word

Burst Architecture (2.5 Cycle Read Latency)

72-Mbit DDR II+ SRAM Two-Word Burst Architecture (2.5 Cycle Read Latency)

Features

■

Configurations

With Read Cycle Latency of 2.5 cycles:

CY7C1568KV18 – 4M × 18

CY7C1570KV18 – 2M × 36

72-Mbit density (4M × 18, 2M × 36)

550 MHz clock for high bandwidth

Two-word burst for reducing address bus frequency

Double data rate (DDR) interfaces (data transferred at

1100 MHz) at 550 MHz

Available in 2.5 clock cycle latency

Two input clocks (K and K) for precise DDR timing

❐

SRAM uses rising edges only

Echo clocks (CQ and CQ) simplify data capture in high speed

systems

Data valid pin (QVLD) to indicate valid data on the output

Synchronous internally self-timed writes

DDR II+ operates with 2.5 cycle read latency when DOFF is

asserted HIGH

Operates similar to DDR I device with 1 cycle read latency when

DOFF is asserted LOW

Core V

= 1.8 V ± 0.1 V; I/O V

DDQ

= 1.4 V to V

DD[1]

❐

Supports both 1.5 V and 1.8 V I/O supply

HSTL inputs and variable drive HSTL output buffers

Available in 165-ball fine pitch ball grid array (FBGA) package

(13 × 15 × 1.4 mm)

Offered in both Pb-free and non Pb-free packages

JTAG 1149.1 compatible test access port

Phase-locked loop (PLL) for accurate data placement

Functional Description

The CY7C1568KV18 and CY7C1570KV18 are 1.8 V

synchronous pipelined SRAMs equipped with DDR II+

architecture. The DDR II+ consists of an SRAM core with

advanced synchronous peripheral circuitry. Addresses for read

and write are latched on alternate rising edges of the input (K)

clock. Write data is registered on the rising edges of both K and

K. Read data is driven on the rising edges of K and K. Each

address location is associated with two 18-bit words

(CY7C1568KV18), or 36-bit words (CY7C1570KV18) that burst

sequentially into or out of the device.

Asynchronous inputs include an output impedance matching

input (ZQ). Synchronous data outputs (Q, sharing the same

physical pins as the data inputs D) are tightly matched to the two

output echo clocks CQ/CQ, eliminating the need for separately

capturing data from each individual DDR SRAM in the system

design.

All synchronous inputs pass through input registers controlled by

the K or K input clocks. All data outputs pass through output

registers controlled by the K or K input clocks. Writes are

conducted with on-chip synchronous self-timed write circuitry.

For a complete list of related documentation, click

here.

■

Selection Guide

Description

Maximum operating frequency

Maximum operating current

× 18

× 36

550 MHz

550

760

970

500 MHz

500

700

890

450 MHz

450

650

820

400 MHz

400

590

750

Unit

MHz

Note

1. The Cypress QDR II+ devices surpass the QDR consortium specification and can support V

DDQ

= 1.4 V to V

Cypress Semiconductor Corporation

Document Number: 001-15880 Rev. *R

•

198 Champion Court

•

San Jose

CA 95134-1709

•

408-943-2600

Revised March 11, 2016
