BZX84C Series
350mW Surface Mount Zener Diode
3:cathode
C:
5% tolerance
SOT-23
Features
Planar Die Construction.
350mw Power Dissipation.
Zener Voltages From 2.4V -51V
1：ANODE
2
Ideally Suited For Automated Assembly Prcesses.
Applications
350Mw Surface mount zener diode
Dimensions in inches and (millimeters)
Ordering Information
Type No.
BZX84C2V4-BZX84C51
Marking
See Table on page2
Package Code
SOT-23
MAXIMUM RATING
@ Ta=25℃ unless otherwise specified
Characteristic
Symbol
Value
Unit
= 10mA
Forward Valtage@I
F
Power Dissipation
Thermal Resistance, Junction to Ambient Air
Operating and Storage Temperature Range
V
F
P
d
0.9
350
V
mW
R
θjA
T
j，
T
stg
357
-65 to+150
℃/W
℃
Notes: 1. Valid provided that device terminals are kept at ambient temperature.
2. Tested with pulses, 300μs pulse width, period = 5ms.
3. f = 1KHz.
Revision:20170701-P1
ht
t
p
:
//
www.lgesemi
.c
o
m
mail:lge@lgesemi.com
BZX84C Series
350mW Surface Mount Zener Diode
ELECTRICAL CHARACTERISTICS
@ Ta=25℃ unless otherwise specified
Maximum
Reverse
Current
Typical
Temperature
Coefficient @I
ZT
mV/℃
Zerner Voltage Range
Type
Number
Marking
Code
V
Z
@I
ZT
Nom(V)
BZX84C2V4
BZX84C2V7
BZX84C3V0
BZX84C3V3
BZX84C3V6
BZX84C3V9
BZX84C4V3
BZX84C4V7
BZX84C5V1
BZX84C5V6
BZX84C6V2
BZX84C6V8
BZX84C7V5
BZX84C8V2
BZX84C9V1
BZX84C10
BZX84C11
Z11
Z12
Z13
Z14
Z15
Z16
Z17
Z1
Z2
Z3
Z4
Z5
Z6
Z7
Z8
Z9
Y1
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
Min(V)
2.2
2.5
2.8
3.1
3.4
3.7
4.0
4.4
4.8
5.2
5.8
6.4
7.0
7.7
8.5
9.4
10.4
Max(V)
2.6
2.9
3.2
3.5
3.8
4.1
4.6
5.0
5.4
6.0
6.6
7.2
7.9
8.7
9.6
10.6
11.6
I
ZT
(mA)
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
Maximum Zener
Impedance
Z
ZT@
I
ZT
(Ω)
100
100
95
95
90
90
90
80
60
40
10
15
15
15
15
20
20
Z
ZK
@I
ZK
(Ω)
600
600
600
600
600
600
600
500
480
400
150
80
80
80
100
150
150
(mA)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
I
R
(μA)
50
20
10
5.0
5.0
3.0
3.0
3.0
2.0
1.0
3.0
2.0
1.0
0.7
0.5
0.2
0.1
V
R
Min
(V)
1.0
1.0
1.0
1.0
1.0
1.0
1.0
2.0
2.0
2.0
4.0
4.0
5.0
5.0
6.0
7.0
8.0
-3.5
-3.5
-3.5
-3.5
-3.5
-3.5
-3.5
-3.5
-2.7
-2.0
0.4
1.2
2.5
3.2
3.8
4.5
5.4
0
0
0
0
0
0
0
0.2
1.2
2.5
3.7
4.5
5.3
6.2
7.0
8.0
9.0
Max
Revision:20170701-P1
ht
t
p
:
//
www.lgesemi
.c
o
m
mail:lge@lgesemi.com
