FR107
SMA
FEATURES
The plastic package carries Underwriters Laboratory
Flammability Classification 94V-0
For surface mounted applications
Fast switching for high efficiency
Low reverse leakage
Built-in strain relief,ideal for automated placement
High forward surge current capability
High temperature soldering guaranteed:
250 C/10 seconds at terminals
0.087 (2.21)
0.070 (1.80)
0.110(2.80)
0.100(2.54)
0.177(4.50)
0.157(3.99)
0.012(0.305)
0.006(0.152)
A
MECHANICAL DATA
0.060(1.52)
0.030(0.76)
0.008(0.203)MAX.
0.222(5.66)
0.194(4.93)
SMA
SMA(H)
A:
0.096(2.42)
0.078(1.98)
0.122(3.12)
0.110(2.82)
Case:
JEDEC SMA molded plastic body
Terminals:
Solder plated, solderable per MIL-STD-750,
Method 2026
Polarity:
Color band denotes cathode end
Mounting Position:
Any
Weight:0.003
ounce, 0.093 grams
0.004 ounce, 0.111 grams SMA(H)
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25 C ambient temperature unless otherwise specified.
Single phase half-wave 60Hz,resistive or inductive load,for capacitive load current derate by 20%.
CatalogNumber
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
at T
L
=90 C
Peak forward surge current
8.3ms single half sine-wave superimposed on
rated load (JEDEC Method)
Maximum instantaneous forward voltage at 1.0A
Maximum DC reverse current
T
A
=25 C
at rated DC blocking voltage
T
A
=100 C
Maximum reverse recovery time
(NOTE 1)
Typical junction capacitance (NOTE 2)
SYMBOLS
FR107
1000
700
1000
UNITS
VOLTS
VOLTS
VOLTS
V
RRM
V
RMS
V
DC
I
(AV)
1.0
Amp
I
FSM
V
F
I
R
t
rr
C
J
30.0
1.3
5.0
50.0
500
15.0
50.0
-65 to +150
Amps
Volts
m
A
ns
pF
C/W
C
Typical thermal resistance (NOTE 3)
R
q
JA
Operating junction and storage temperature range T
J
,
T
STG
Note:1.Reverse
recovery condition I
F
=0.5A,I
R
=1.0A,Irr=0.25A
2.Measured at 1MHz and applied reverse voltage of 4.0V D.C.
3.P.C.B. mounted with 0.2x0.2”(5.0x5.0mm) copper pad areas
www.yongyutai.com
PAGE 1
FR107
AVERAGE FORWARD RECTIFIED CURRENT,
AMPERES
FIG. 1- FORWARD CURRENT DERATING CURVE
£PEAK FORWARD SURGE CURRENT,
AMPERES
0
25
50
75
100
125
150
175
1.0
FIG. 2-MAXIMUM NON-REPETITIVE PEAK FORWARD
SURGE CURRENT
30
0.8
25
0.6
20
0.4
15
0.2
10
0
5.0
1
10
100
AMBIENT TEMPERATURE, C
NUMBER OF CYCLES AT 60 Hz
FIG. 3-TYPICAL INSTANTANEOUS FORWARD
CHARACTERISTICS
20
1,000
10
FIG. 4-TYPICAL REVERSE CHARACTERISTICS
INSTANTANEOUS REVERSE CURRENT,
MICROAMPERES
INSTANTANEOUS FORWARD
CURRENT,AMPERES
100
1
10
0.1
1
0.01
0.6
0.8
1.0
1.2
1.4
1.5
0.1
0.01
0
20
40
60
80
100
INSTANTANEOUS FORWARD VOLEAGE,
VOLTS
PERCENT OF PEAK REVERSE VOLTAGE,%
FIG. 5-TYPICAL JUNCTION CAPACITANCE
200
100
FIG. 6-TYPICAL TRANSIENT THERMAL IMPEDANCE
TRANSIENT THERMAL IMPEDANCE,
C/W
100
JUNCTION CAPACITANCE, pF
10
10
1
0.1
0.01
0.1
1
10
100
1
0.1
1.0
10
100
REVERSE VOLTAGE,VOLTS
t,PULSE DURATION,sec.
www.yongyutai.com
PAGE 2
