Ceramic
Capacitor Solutions
AC Safety Certified
High Voltage SMT
High Capacitance
High Temperature
X2Y
®
Low ESL
LICC Low ESL
SMPS Stacks
High Voltage Radials
Planar Array
Discoidal
CapStrate
®
Custom Solutions
13
20
Your Technology Partner
The mission of the Johanson Companies is to
translate our customer needs into quality electronic
components, produced in factories that are models
of excellence, supported by innovative service. With
over 30 years of experience, Johanson Dielectrics
provides both standard and custom technology solu-
tions tailored to your specific electronic applications.
Our standard product range includes High Voltage
and AC Safety Capacitors providing solutions for
Lighting, IT and Business Equipment designs. Our
X2Y® Capacitor line provides advanced EMI fil-
tering and IC decoupling solutions and our High
Capacitance Tanceram® products provide the highest
capacitance values in the smallest cases sizes.
Customized solutions in the areas of High Tem-
perature and High AC power ceramic capacitors are
available to customers who require a partnered tech-
nology solution.
Johanson Dielectrics design and manufacturing
operations are located in Sylmar, California and
Zhoaqing, PRC. Our quality minded management
system utilizes continuous improvement programs
focused on increased product reliability, manufac-
turing through-put, and product performance. Our
broad experience, applications support, and respon-
sive service enhance our ability to drive down your
total cost of procurement and speed your time to
market.
H
igH
F
requency
c
eramic
S
olutionS
Johanson Technology Inc., Camarillo CA. Products
include High Q Capacitors, Ceramic and Wire-
wound Chip Inductors, and a broad range of LTCC
based RF IPCs such as Antennas, Filters, Baluns,
Couplers, Matched Filter Baluns, etc.
www.johansontechnology.com
Johanson Dielectrics, Inc. reserves the right to make design and price changes without notice. All sales
are subject to the terms and conditions printed on the back side of our sales order acknowledgment forms,
including a limited warranty and remedies for non-conforming goods or defective goods. We will be pleased
to provide a copy of these terms and conditions for your review.
www.johanson dielectrics.com
2
I
ndex of
P
roducts
S
urFace
m
ount
c
eramic
c
apacitorS
Ceramic Capacitor Prototyping Kits
High Voltage Capacitors 250 - 6,000 VDC
Safety Capacitors 250 VAC, Y2, Y3, Japan Standard
Low Inductance X2Y
®
Capacitors
Low Inductance Capacitors
Chip Feedthru Filter Capacitors
High Temperature - 200°C Capacitors
High Capacitance Tanceram
®
Capacitors
SMT Multi-layer Ceramic Capacitors 10 - 200 VDC
4-5
6-7
8-9
10-13
14
15
16-17
18-19
20-21
l
eaded
c
eramic
c
apacitorS
SMPS Stacked Capacitors, 125°C & 200°C versions
Mini-SMPS Stacked Capacitors
Maxi-CapTM SMPS Capacitors
X2Y
®
Low ESL SMPS Stacked Capacitors
Switch-mode Radial Leaded Capacitors
High Voltage Radial Leaded Capacitors, 125°C, 200°C, 250°C versions
22-23
24-25
26-27
28-29
30-31
32-33
p
lanar
c
apacitorS
& c
uStom
c
eramic
S
olutionS
Planar Array Capacitors
CapStrate
®
& Customer Ceramic Solutions
Part Number, Dielectric, Packaging Specifications
34-35
36-37
38-39
o
n
-
line
p
roductS
N2200 Chip Capacitors
200°C Radial Leaded Capacitors
Tin-Lead Termination Capacitors
Polyterm
®
Termination Capacitors
Large Size MLC Capacitors
High Power AC Capacitors
o
n
-
line
i
nFormation
Packaging & Marking
Environmental Compliance Policies
Lead-Free Reflow Processing
High Voltage PCB Design
Capacitor Power Handling
X2Y
®
Filter Eval. & PCB Design Guide
www.johanson dielectrics.com
3
c
eramIc
c
aPacItor
e
ngIneerIng
d
esIgn
K
Its
Johanson Dielectrics, Inc. offers a variety of multi-layer chip capacitor
sample kits for proto-type design work. Each kit is grouped by type,
size, or voltage and contains a selection of popular values and
tolerances. The chips are individually packaged in labeled plastic
compartments for easy access. The general range of kit contents
is described below. Specific part number details may be found at
www.johansondielectrics.com
0402 Ceramic Chip Capacitor Kit
1400 piece sample assortment of selected values from 1.0pF to 0.1µF
Chip Size
0402
Voltage Rating
50 VDC - 6.3 VDC
Dielectric
NPO, X7R,Y5V
Capacitanc Range
1.0pF to 0.22µF
Qty / Value
50 pcs
P/N: S-0402
Total Qty
1400 pcs
P/N: S-0603
Dielectric
NPO, X7R,Y5V
Capacitanc Range
10pF to 0.22µF
Qty / Value
50 pcs
Total Qty
1400 pcs
P/N: S-0805
Dielectric
NPO, X7R
Capacitanc Range
10pF to 0.47µF
Qty / Value
50 pcs
Total Qty
1400 pcs
P/N: S-TAN-X5R
Capacitanc Range
1.0µF - 100µF
Qty / Value
10 - 25 pcs
Total Qty
500 pcs
P/N: S-500
Dielectric
NPO, X7R
Capacitanc Range
33pF to 0.1µF
Qty / Value
10-20 pcs
Total Qty
400 pcs
P/N: S-1KV
Dielectric
NPO, X7R
Capacitanc Range
22pF to 0.1µF
Qty / Value
10-20 pcs
Total Qty
400 pcs
0603 Ceramic Chip Capacitor Kit
1400 piece sample assortment of selected values from 1.0pF to 0.1µF
Chip Size
0603
Voltage Rating
50 VDC - 16 VDC
0805 Ceramic Chip Capacitor Kit
1400 piece sample assortment of selected values from 1.0pF to 0.1µF
Chip Size
0805
Voltage Rating
100 VDC - 16 VDC
TANCERAM
®
HIGH CAPACITANCE Ceramic Chip Capacitor Kit
500 piece sample assortment of selected values from 1.0µF to 100µF
Chip Size
0402, 0603, 0805
1206, 1210
Voltage Rating
25 VDC - 6.3 VDC
Dielectric
X5R
500 VDC Ceramic Chip Capacitor Kit
400 piece sample assortment of selected values from 33pF to 0.1µF
Chip Size
0805 - 1812
Voltage Rating
500 VDC
1000 VDC Ceramic Chip Capacitor Kit
400 piece sample assortment of selected values from 22pF to 0.1µF
Chip Size
0805 - 2225
Voltage Rating
1000 VDC
Johanson may from time-time adjust actual kit contents based on design demand trends.
Check the Johanson web site for design kit updates and kit content changes.
4
www.johanson dielectrics.com
c
eramIc
c
aPacItor
e
ngIneerIng
d
esIgn
K
Its
2000 VDC Ceramic Chip Capacitor Kit
300 piece sample assortment of selected values from 22pF to 0.022µF
Chip Size
1206 - 2225
Voltage Rating
2000 VDC
Dielectric
NPO, X7R
Capacitanc Range
22pF to 0.022µF
Qty / Value
10-20 pcs
Total Qty
300 pcs
P/N: S-SY3
Capacitanc Range
10pF to 1500 pF
Qty / Value
20 pcs
Total Qty
240 pcs
P/N: S-SY2
Capacitanc Range
10pF to 2200pF
Qty / Value
20 pcs
Total Qty
200 pcs
P/N: S-X07CBK
Dielectric
NPO, X7R
Capacitanc Range
1.0pF to 0.01µF
Qty / Value
50 pcs
Total Qty
600 pcs
P/N: S-X14CBK
Dielectric
NPO, X7R
Capacitanc Range
1.0pF to 0.01µF
Qty / Value
50 pcs
Total Qty
700 pcs
P/N: S-X14-PBP
Dielectric
X7R, X5R
Capacitanc Range
1.0nF to 1.0µF
Qty / Value
20 pcs
Total Qty
300 pcs
P/N: S-X15-EMI
Dielectric
NPO, X7R
Capacitanc Range
1.0pF to 0.01µF
Qty / Value
20 pcs
Total Qty
300 pcs
P/N: S-X2Y-MTR
Dielectric
X7R
Capacitanc Range
0.10µF to 0.47µF
Qty / Value
30 pcs
Total Qty
300 pcs
P/N: S-2KV
X2/Y3 SAFETY CERTIFIED Ceramic Chip Capacitor Kit
240 piece sample assortment of selected values from 10pF to 1500 pF
Chip Size
1808
Voltage Rating
3KV DC / 250 AC
Dielectric
NPO, X7R
X1/Y2 SAFETY CERTIFIED Ceramic Chip Capacitor Kit
200 piece sample assortment of selected values from 10pF to 2200 pF
Chip Size
1808 - 2220
Voltage Rating
5KV DC / 250 AC
Dielectric
NPO, X7R
X2Y
®
EMI FILTER Capacitor Kit - 0402 Size
600 piece sample assortment of selected values from 1.0pF to 0.01µF
Chip Size
0402
Voltage Rating
10 - 50 VDC
X2Y
®
EMI FILTER Capacitor Kit - 0603 Size
700 piece sample assortment of selected values from 1.0pF to 0.01µF
Chip Size
0603
Voltage Rating
50 - 100 VDC
X2Y
®
POWER BYPASS Capacitor Kit - 0603 Size
300 piece sample assortment of selected values from 1.0nF to 1.0µF
Chip Size
0603
Voltage Rating
6.3 - 100 VDC
X2Y
®
EMI FILTER Capacitor Kit - 0805 Size
300 piece sample assortment of selected values from 1.0pF to 0.01µF
Chip Size
0805
Voltage Rating
50 - 100 VDC
X2Y
®
DC MOTOR FILTER Capacitor Kit
300 piece sample assortment of selected values from 0.10µF to 0.47µF
Chip Size
1206 - 1812
Voltage Rating
100 VDC
Johanson may from time-time adjust actual kit contents based on design demand trends.
Check the Johanson web site for design kit updates and kit content changes.
www.johanson dielectrics.com
5
