SENSITRON
SEMICONDUCTOR
TECHNICAL DATA
DATA SHEET 4710, REV. A.1
SHD125046
SHD125046P
SHD125046N
SHD125046D
HERMETIC POWER SCHOTTKY RECTIFIER
175C Maximum Operation Temperature
DESCRIPTION:
A 200-VOLT, 3/6 AMP, POWER SCHOTTKY RECTIFIER IN A HERMETIC TO-254
PACKAGE.
ALL RATINGS ARE @ T
C
= 25
C
UNLESS OTHERWISE SPECIFIED.
MAXIMUM RATINGS
RATING
PEAK INVERSE VOLTAGE
SYMBOL
PIV
O
O
MAX.
200
3
6
55
60
11.9
-65 to
+ 175
-65 to
+ 175
UNITS
Volts
Amps
Amps
Amps
pF
C/W
C
C
MAXIMUM DC OUTPUT CURRENT (@ T
C
=100 C) (Single, Doubler)
MAXIMUM DC OUTPUT CURRENT (@ T
C
=100 C)
(Common Cathode, Common Anode)
MAXIMUM NONREPETITIVE FORWARD SURGE CURRENT (t=8.3ms, Sine)
MAXIMUM JUNCTION CAPACITANCE
MAXIMUM THERMAL RESISTANCE (per leg)
MAXIMUM OPERATING TEMPERATURE RANGE
MAXIMUM STORAGE TEMPERATURE RANGE
(V
r
=5V)
I
O
I
O
I
FSM
C
T
R
JC
Top/Tstg
Top/Tstg
ELECTRICAL CHARACTERISTICS
CHARACTERISTIC
MAXIMUM FORWARD VOLTAGE DROP, Pulsed (I
f
= 3 Amps)
T
J
= 25
C
T
J
= 125
C
MAXIMUM REVERSE CURRENT (I
r
@ 200 V PIV)
T
J
= 25
C
T
J
= 125
C
I
r
0.07
1.6
mA
V
f
1.02
0.86
Volts
SYMBOL
MAX.
UNITS
2018
Sensitron Semiconductor
221 West Industry Court
Deer Park, NY 11729-4681
PHONE (631) 586-7600
FAX (631) 242-9798
www.sensitron.com
sales@sensitron.com
SHD125046
SHD125046P
SHD125046N
SHD125046D
SENSITRON
TECHNICAL DATA
DATASHEET 4710, REV. A.1
Mechanical Dimensions: In inches / mm
.149 (3.78
Dia.
.139 3.53)
.545 (13.84
.535 13.60)
.260
.249
.050
.040
(6.60
6.32)
(1.27
1.02)
SINGLE
COMMON CATHODE
.685 (17.40
.665 16.89)
1.235 (31.37
1.195 30.35)
.800 (20.32
.790 20.07) .545 (13.84
.535 13.58)
1
2
3
1
2
DOUBLER
3
1
2
3
COMMON ANODE
1
.045 (1.14
.035 0.89)
3 Places
.150(3.81) BSC
2 Places
.150(3.81) BSC
2
3
1
2
3
TO-254
PIN 1
CATHODE
ANODE 1
CATHODE 1
ANODE
PIN 2
ANODE
COMMON CATHODE
COMMON ANODE
CATHODE/ ANODE
PIN 3
ANODE
ANODE 2
CATHODE 2
CATHODE
PINOUT TABLE
TYPE
SINGLE RECTIFIER
DUAL RECTIFIER, COMMON CATHODE (P)
DUAL RECTIFIER, COMMON ANODE (N)
DUAL RECTIFIER, DOUBLER (D)
Curves shown are for bare die only.
Typical Forw ard Characteristics
Typical Rev erse Characteristics
10
0
200 °C
175 °C
150 °C
(mA)
10
0
10
-1
200 °C
175 °C
Instantaneous Reverse Current - I
R
10
-2
125 °C
100 °C
75 °C
(A)
10
-3
Instantaneous Forward Current - I
F
10
-4
10
-1
50 °C
10
-5
25 °C
0
40
80
120
160
Reverse Voltage - V
R
(V)
200
240
125 °C
10
-2
Typical Junction Capacitance
(pF)
T
25 °C
60
45
30
15
0
0
40
80
120
160
Reverse Voltage - V
R
(V)
200
240
10
-3
0.0
0.2
0.4
0.6
Forward Voltage Drop - V
0.8
F
(V)
1.0
2018
Sensitron Semiconductor
221 West Industry Court
Deer Park, NY 11729-4681
PHONE (631) 586-7600
FAX (631) 242-9798
www.sensitron.com
sales@sensitron.com
Junction Capacitance - C
SHD125046
SHD125046P
SHD125046N
SHD125046D
SENSITRON
TECHNICAL DATA
DATASHEET 4710, REV. A.1
PART ORDERING INFORMATION:
SHD125046 XX X
Part Number
Screening Level (blank is no screening):
Suffix
blank
SX*
SV*
SS*
Screened in Accordance with:
No screening level
MIL-PRF-19500, TX Level
MIL-PRF-19500, TXV Level
MIL-PRF-19500, S Level
QCI (blank is no QCI):
Suffix
blank
Q*
Inspection in Accordance with:
No QCI
MIL-PRF-19500 QCI
*The 200V schottky diodes may be de-rated to 170V. In addition, PDA requirement may be modified to not include delta removals
for reverse leakage current.
