HFXO OSCILLATOR
220 kHz to 220 MHz
High Precision & High Shock,
Low Profile Miniature
Surface Mount Crystal Oscillator
DESCRIPTION
Statek’s high shock HFXO oscillators, available in tight
frequency tolerances, consist of a Statek miniature quartz
crystal and a CMOS/TTL compatible hybrid circuit in a
ceramic package. Each crystal used in the HFXO oscillator is
pre-qualified before assembly through electrical tests and
characterization over temperature.
FEATURES
Mechanical shock survivability of 75,000 g
Tight frequency tolerance
Low acceleration sensitivity
Low aging (Double Hermetic Seal)
Low jitter
Optional Output Enable/Disable with Tri-State
Low EMI emission
Full military testing to MIL-PRF-55310 available
Low power consumption
APPLICATIONS
2
3
BOTTOM
1
4
D
D
DIMENSIONS
A
TOP
Military & Aerospace
Smart Munitions
Cockpit Systems
Navigation
Industrial, Computer & Communications
Industrial Controls
Instrumentation
Down-hole Drilling
SUGGESTED LAND PATTERN
0.067 (1.70)
0.070 (1.78)
B
C
E
TYPICAL
DIM
A
B
inches
0.256
0.197
mm
6.50
5.00
1.65
1.75
1.40
1.52
MAXIMUM
inches
0.263
0.204
0.068
0.075
0.065
0.070
mm
6.68
5.18
1.73
1.91
1.65
1.78
0.065
C
(SM1)
C
(SM3/SM5)
0.069
D
E
0.055
0.060
0.065 (1.65)
PIN CONNECTIONS
1. Enable/Disable (E or T) or not connected (N)
0.201 (5.11)
0.136 (3.45)
2. Ground
3. Output
4.
V
DD
0. 37 (3.48)
1
inches
(mm)
GRID
PLACEMENT
COURTYARD
S
10189 Rev B
YS
TE
M
C
ERT
I
F
I
C
A
T
IO
N
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
IS
O
01
90
SPECIFICATIONS
ABSOLUTE MAXIMUM RATINGS
Specifications are typical at 25
O
C unless otherwise noted.
Specifications are subject to change without notice. Tighter
specifications available. Please contact factory.
Supply Voltages
1
Calibration Tolerance
Frequency Stability
Over Temperature
2
Total Frequency
Tolerance
Output Load (CMOS)
4
Start-up Time
Rise/Fall Time
Duty Cycle
5
Aging, first year
Shock, survival
6
Vibration, survival
3
Supply Voltage V
DD
Storage Temperature
Maximum Process Temperature
-0.5 V to 7.0 V*
-55
O
C to +125
O
C
260
O
C for 20 seconds
0.9 V to 5.0 V
± 10 ppm and up
± 10 ppm for Commercial
± 20 ppm for Industrial
± 40 ppm for Military
± 15 ppm and up for Commercial
± 20 ppm and up for Industrial
± 50 ppm and up for Military
15 pF
5 ms MAX
10 ns MAX
45% MIN, 55% MAX
5 ppm
up to 75,000 g, 0.5 ms,
1
/
2
sine
20 g, 10-2,000 Hz swept sine
*The supply voltage range is -0.5 V to +4.0 V for some products. Contact Factory.
ENABLE/DISABLE OPTIONS (E/T/N)
Statek offers three enable/disable options: E, T, and N.
Both the E-version and T-version have Tri-State outputs and
differ in whether the oscillator continues to run internally
when the output is put into the high Z state: it stops in the
E-version and continues to run in the T-version. So, the E-
version offers very low current consumption when the
oscillator is disabled and the T-version offers very fast output
recovery when the oscillator is re-enabled. The N-version
does not have PIN 1 connected internally and so has no
enable/disable capability. The following table summarizes the
three options.
COMPARISON OF
ENABLE/DISABLE OPTIONS E AND T
E
T
8
Operating Temp Ranges
7
-10
O
C to +70
O
C (Commercial)
-40
O
C to +85
O
C (Industrial)
-55
O
C to + 125
O
C (Military)
1. Not all frequencies are available in certain voltages. Contact factory for details.
2. Does not include calibration tolerance
3. Frequency over temperature relative to nominal frequency.
4. Higher CMOS loads and TTL loads available. Contact factory.
5. Tighter Duty Cycles available. Contact factory.
6. Higher shock version available. Contact factory for requirements above 75,000 g.
7. Higher temp available (up to 200
O
C). Contact factory.
8. The T-version is not available for all frequencies. Contact factory.
Note: All parameters are measured at ambient temperature with a 10 M!, 15 pF load.
When enabled (PIN 1 is high*)
Output
Oscillator
Current consumption
Freq. output
Oscillates
Normal
Freq. output
Oscillates
Normal
When disabled (PIN 1 is low)
Output
Oscillator
Current consumption
High Z state
Stops
Very low
High Z state
Oscillates
Lower than normal
PACKAGING OPTIONS
When re-enabled (PIN 1 changes from low to high)
Output recovery
Delayed
Immediate
HFXO
-Tray Pack
-16mm tape, 7” or 13” reels
(Reference tape and reel data sheet 10109)
*
When PIN 1 is allowed to float, it is held high by an internal pull-up resistor.
HOW TO ORDER HFXO SURFACE MOUNT CRYSTAL OSCILLATORS
HFXO
3
D
Shock Level
A = 5,000 g
B = 10,000 g
C = 20,000 g
D = 30,000 g
F = 50,000 g
G = 75,000 g
S
Blank = Standard
S = Special or
custom
T
Enable/Disable
Option
E, T, or N
SM3
Termination
Blank = SM1
= Gold Plated (Pb Free)
SM3 = Solder Dipped
SM5 = Solder Dipped (Pb Free)
20.0M ,
Frequency
K = kHz
M = MHz
30
/
50
/
/
I
Supply Voltage
9 = 0.9V
1 = 1.8V
2 = 2.5V
3 = 3.0V
4 = 3.3V
5 = 5.0V
Calibration
Tolerance
@ 25
0
C
(in ppm)
Frequency
Stability over
Temp.Range
(in ppm)
Temperature Range:
C = -10
O
C to +70
O
C
I
= -40
O
C to +85
O
C
M = -55
O
C to +125
O
C
S = Customer Specified
OR
/
Note: The HFXO oscillator with SM1 or SM5
termination is Pb free. The HFXO oscillator with
SM3 termination contains Pb.
/
100
Total
Frequency
Tolerance
(in ppm)
/
I
Temperature Range:
C = -10
O
C to +70
O
C
I
= -40
O
C to +85
O
C
M = -55
O
C to +125
O
C
S = Customer Specified
10189 Rev B
S
YS
TE
M
C
ERT
I
F
I
C
A
T
IO
N
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
IS
O
01
90
