Push-In |
Spacing 5.0 mm
AK4101/..KD-5.0-PEBBLE GREY
1- to n-poles
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.08 mm²
2.5 mm²
0.5 mm²
1.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing 5.0 mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
Width (mm)
11.60
16.60
21.60
26.60
31.60
36.60
41.60
46.60
51.60
56.60
61.60
Article Designation
AK4101/2KD-5.0-PEBBLE GREY
AK4101/3KD-5.0-PEBBLE GREY
AK4101/4KD-5.0-PEBBLE GREY
AK4101/5KD-5.0-PEBBLE GREY
AK4101/6KD-5.0-PEBBLE GREY
AK4101/7KD-5.0-PEBBLE GREY
AK4101/8KD-5.0-PEBBLE GREY
AK4101/9KD-5.0-PEBBLE GREY
AK4101/10KD-5.0-PEBBLE GREY
AK4101/11KD-5.0-PEBBLE GREY
AK4101/12KD-5.0-PEBBLE GREY
Article Number
54101020001F
54101030001F
54101040001E
54101050001E
54101060001D
54101070001D
54101080001D
54101090001D
54101100001D
54101110001D
54101120001D
PU
200
200
100
100
50
50
50
50
50
50
50
Stranded with Ferrule 0.14 mm²
min
Stranded with Ferrule 1.0 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Solder Tag
Clamp Spring
Copper Alloy
Stainless Steel
9.0 mm
1.0 mm
Accessories
Figure
Designation
Bridge, 2-pole, insulated, BRI/2-5.0/5.08-
LIGHT GREY
Article Number
50000000006
Colours
PEBBLE GREY
BLUE
RAL7032
RAL5015
RAL7032
Bridge, 3-pole, insulated, BRI/3-5.0/5.08-
LIGHT GREY
50000000007
RAL5015
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Ratings
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Test Voltage
B
300 V
10 A
AWG 20-14
-
1.6 kV
C
-
-
-
-
-
D
300 V
10 A
AWG 20-14
-
1.6 kV
min
0.5 mm²
250 V
17.5 A
max
2.5 mm²
2.0 kV
