RECEPTACLES

FOR .015” - .025” DIAMETER PINS

8964

8964-0-15-XX-30-XX-04-0

Press-fit in .057 mounting hole

5342

5342-0-15-XX-35-XX-10-0

8857

Solder mount in .051 min. mounting hole

Also available on 8mm wide carrier tape:

6,000 parts per 13” reel

Order as: 5342-0-57-XX-35-XX-10-0

8857-X-15-XX-32-XX-04-0

Press-fit in .057 mounting hole

Basic Part

Number

Length

A

8857-0

8857-1

8857-2

8857-3

8857-4

.311

.448

.589

.731

.871

8862/8877

88XX-0-15-XX-30-XX-04-0

Press-fit in .056 mounting hole

1334

Basic Part

Number

Length

A

.072 DIA.

.057 DIA.

1334-0-15-XX-30-XX-04-0

Press-fit in .057 mounting hole

8855

.071 DIA.

8855-0-15-XX-30-XX-34-0

Press-fit in .057 mounting hole

.034

.096

.078

.148

.161

.031

.028 .100

.161.167

.059 DIA.

.053 DIA.

8862-0

8877-0

.300

.350

.059 DIA.

.025 DIA.

.053 DIA.

.020 DIA.

.064

.020 DIA.

.144

2954

.072 DIA.

.058 DIA.

2954-0-18-XX-30-XX-10-0

Press-fit in .057 mounting hole

Accepts wire sizes up to .028” dia.

.031

.100

.150

.290

9363

9363-0-15-XX-35-XX-10-0

Solder mount in .057 min. mounting hole

1023

.066 DIA.

.072 DIA.

.064 DIA.

.059 DIA.

1023-0-15-XX-30-XX-04-0

Press-fit in .061 mounting hole

.016

.030

.031 .088

.146

1701

1701-0-15-XX-30-XX-10-0

Press-fit in .057 mounting hole

.057 DIA.

.059 DIA.

.165

.075 .086

.145

.200

.053 DIA.

.036 DIA.

HOLE

.046 DIA.

.060

.038 DIA.

HOLE

.090

.022 DIA.

.125

.034 DIA.

SPECIFICATIONS:

Shell Material:

Brass Alloy 360, 1/2 Hard

Contact Material:

Beryllium Copper Alloy 172, HT

Dimensions: Inches

Tolerances On:

Lengths: ± .005

Diameters: ± .002

Angles:

±2°

ORDER CODE: XXXX - X - 1X - XX -

XX

- XX - 10 - 0

BASIC PART #

SPECIFY SHELL FINISH:

01

200

μ”

TIN/LEAD OVER NICKEL

80

200

μ”

TIN OVER NICKEL (RoHS)

15

10

μ”

GOLD OVER NICKEL (RoHS)

SPECIFY CONTACT FINISH:

02

100

μ”

TIN/LEAD OVER NICKEL

84

100

μ”

TIN OVER NICKEL (RoHS)

27

30

μ”

GOLD OVER NICKEL (RoHS)

2011/65/EU

RoHS - 2

SELECT CONTACT:

#30, #32 or #35

CONTACT (DATA ON PAGE 253 & 254)

(For alternate contact choices, see groups B and C on page 248)

Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com

PAGE 171 | PIN RECEPTACLES
