IW2415SA-M

Description
Analog Circuit
CategoryPower/power management    The power supply circuit
File Size96KB,1 Pages
ManufacturerXP Power
Websitehttps://www.xppower.com/
Environmental Compliance
Download Datasheet Parametric View All

IW2415SA-M Overview

Analog Circuit

IW2415SA-M Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
Objectid8323791348
package instruction,
Reach Compliance Codecompliant
ECCN codeEAR99
YTEOL7.2
Analog Integrated Circuits - Other TypesDC-DC REGULATED POWER SUPPLY MODULE
Maximum input voltage36 V
Minimum input voltage18 V
Nominal input voltage24 V
JESD-30 codeR-MSMA-T5
length21.85 mm
Maximum load regulation1%
Number of functions1
Output times1
Number of terminals5
Maximum operating temperature85 °C
Minimum operating temperature-40 °C
Maximum output voltage15.3 V
Minimum output voltage14.7 V
Nominal output voltage15 V
Package body materialMETAL
Package shapeRECTANGULAR
Package formMICROELECTRONIC ASSEMBLY
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Maximum seat height11.6 mm
surface mountNO
technologyHYBRID
Temperature levelINDUSTRIAL
Terminal formTHROUGH-HOLE
Terminal pitch2.54 mm
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
Maximum total power output1 W
Fine-tuning/adjustable outputNO
width9.2 mm
DC DC
1 Watt
IW Series
Wide 2:1 Input Range
SIP or DIP Package
xppower.com
Regulated Single & Dual Output
1000 VDC Isolation (Optional 3000 VDC)
Continuous Short Circuit Protection
Optional Metal Case
3 Year Warranty
Specification
Input
Input Voltage Range
Input Reflected
Ripple Current
Input Reverse
Voltage Protection
Input Filter
Input Surge
• See table
• 35 mA pk-pk through 12 µH inductor,
5 Hz to 20 MHz
• None
• Capacitor
• 5 V models: 12 VDC for 100 ms
12 V models: 24 VDC for 100 ms
24 V models: 40 VDC for 100 ms
48 V models: 80 VDC for 100 ms
See table
None
(8)
±0.5% max
±1.0% max from 25-100% load
(7)
±2% max
80 mV pk-pk max, 20 MHz bandwidth
(6)
Continuous with auto recovery (foldback)
±5% on dual output models
Optional on SIP package model
(4)
0.02%/°C
See table
1000 VDC (optional 3000 VDC)
10
9
60 pF
100-650 kHz
>1.66 MHrs to MIL-HDBK-217F at 25 °C, GB
Output
Output Voltage
Minimum Load
Line Regulation
Load Regulation
Setpoint Accuracy
Ripple & Noise
Short Circuit Protection
Cross Regulation
Remote On/Off
Temperature Coefficient
No Load
Input
Current
15 mA
15 mA
40 mA
4.5-9.0 V
55 mA
55 mA
70 mA
15 mA
15 mA
15 mA
9.0-18.0 V
15 mA
15 mA
15 mA
8 mA
8 mA
8 mA
18.0-36.0 V
8 mA
8 mA
8 mA
6 mA
6 mA
6 mA
36.0-72.0 V
6 mA
6 mA
6 mA
Input
Voltage
Output
Voltage
(3)
3.3
5.0
9.0
12.0
15.0
24.0
3.3
5.0
9.0
12.0
15.0
24.0
3.3
5.0
9.0
12.0
15.0
24.0
3.3
5.0
9.0
12.0
15.0
24.0
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
V
Output
Current
303
200
111
83
67
42
303
200
111
83
67
42
303
200
111
83
67
42
303
200
111
83
67
42
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
Max.
Capacitive Efficiency
Load
3300 µF
67%
3300 µF
67%
470 µF
70%
470 µF
70%
470 µF
70%
220 µF
68%
3300 µF
70%
3300 µF
72%
470 µF
77%
470 µF
77%
470 µF
77%
220 µF
73%
3300 µF
70%
3300 µF
72%
470 µF
75%
470 µF
75%
470 µF
75%
220 µF
75%
3300 µF
66%
3300 µF
68%
470 µF
70%
470 µF
70%
470 µF
70%
220 µF
68%
Model
Number
(1-5)
IW0503SA
IW0505SA
IW0509SA
IW0512SA
IW0515SA
IW0524SA
IW1203SA
IW1205SA
IW1209SA
IW1212SA
IW1215SA
IW1224SA
IW2403SA
IW2405SA
IW2409SA
IW2412SA
IW2415SA
IW2424SA
IW4803SA
IW4805SA
IW4809SA
IW4812SA
IW4815SA
IW4824SA
General
Efficiency
Isolation Voltage
Isolation Resistance
Isolation Capacitance
Switching Frequency
MTBF
Mechanical Details
0.86
(21.85)
0.42
(10.6)
0.02
(0.50)
0.10
(2.54)
0.02
(0.50)
0.70 (17.78)
0.02
(0.50)
0.14
0.36
(3.50)
(9.20)
1 2 3
5 6 7 8
0.01
(0.25)
0.36
(9.20)
0.44
(11.10)
0.12
(3.05)
Environmental
Operating Temperature
• -40 °C to +100 °C, derate from 100% load
at 85 °C to 0% load at 100 °C
Storage Temperature
• -40 °C to +125 °C
Case Temperature
• 100 °C max
Cooling
• Convection cooled
Notes
1.
2.
3.
4.
Pin
1
2
3
5
6
7
8
PIN CONNECTIONS
Single
Dual
-V Input
-V Input
+V Input
+V Input
Opt. ROF*
Opt. ROF**
N.P. / N.C.
N.C.
+V Output
+V Output
-V Output
-V Output
NC
Common
*When optional ROF is present pin 5
is No Connection. When not present
pin 3 & 5 are No Pin.
**When optional ROF is present pin 5
is No Connection. When not present
pin 3 & 5 are No Connection.
PIN CONNECTIONS
Single
Dual
-V Input
-V Input
-V Input
-V Input
NC
Common
NC
-V Output
+V Output
+V Output
-V Output
Common
+V Input
+V Input
+V Input
+V Input
0.92
(23.40)
For dual inline package replace ‘S’ in model number with ‘D’.
For optional 3 kV isolation add suffix ‘-H’ to the model number.
For dual output delete suffix ‘A’ & split output current equally between rails.
For optional Remote On/Off on SIP models, add suffix ‘-R’ to model number.
Applying 5 V via 1 k current limiting resistor and diode turns output off.
5. For optional metal case, add suffix ‘-M’ to model number, contact sales for details.
6. Output capacitor of 100 µF required to meet quoted ripple & noise.
7. Minimum load of 25% required to meet quoted specifications.
8. Operation at no load will not damage the converter but it may not meet all specifications.
9. Pin pitch tolerance: ±0.014 (±0.35), Case tolerance: ±0.02 (±0.5)
10. Weight: SIP 0.009 lbs (4.0 g), DIP 0.013 lbs (6.0 g)
Metal case weight: SIP 0.014 lbs (6.5 g), DIP 0.017 lbs (8.0 g)
