PSL range of
X7R MLC capacitors
X7R MLCCs
The PSL range of multilayer ceramic capacitors
is suitable for a variety of applications including
power supplies, DC-DC converters and LED
lighting.
This X7R range is manufactured to exacting
standards using our unique screen printing
process. This provides a high quality component
suitable for demanding applications.
Specification
Capacitance Values
X7R
220pF - 1µF
See table for full list of values
Electrical
Operating Temperature
-55°C to +125°C
Temperature Coefficient of Capacitance
(Typical)
±15%
Insulation Resistance
Time constant (Ri xCr) (whichever is the least)
Product ranges
- Capacitance values
Rated
Voltage
50V
63V
100V
200V
250V
500V
630V
1000V
2000V
100GΩ or 1000s
Ageing Rate
Typically less than 2% per time decade
Chip Size
0805
1206
1210
1nF - 1µF
1nF - 330nF
1nF - 180nF
1nF - 100nF
1nF - 68nF
1nF - 22nF
1nF - 4.7nF
1812
N/A
1nF - 680nF
1nF - 470nF
1nF - 220nF
1nF - 150nF
1nF - 68nF
1nF - 10nF
2220
N/A
N/A
N/A
1.5nF - 470nF
1.5nF - 330nF
1.5nF - 100nF
N/A
Mechanical
Termination Material
See ordering information overleaf
Solderability
IEC 60068-2-58. Passed 3 times reflow profile defined
in J-STD-020
Lead Free Soldering
This range is fully compliant with the RoHS and WEEE
directives and parts are compatible with lead free
solders.
Climatic Category
55/125/56
Reeled Quantities
See taped quantities table overleaf
220pF - 100nF 470pF - 470nF
220pF - 47nF
220pF - 27nF
220pF - 10nF
220pF - 5.6nF
220pF - 3.3nF
N/A
470pF - 150nF
470pF - 100nF
470pF - 56nF
470pF - 47nF
470pF - 10nF
470pF - 2.2nF
NOTE:
Other capacitance values may become available, please contact our Sales Office if you need values other
than those shown in the above table. For dimensions and soldering information, please go to our website
(www.syfer.com) or see our MLC Catalogue.
www.knowlescapacitors.com
9320/14/v7
Taped quantities
Chip Size
7” Reel
13” Reel
0805
3,000
12,000
1206
2,500
10,000
1210
2,000
8,000
1812
500/1,000*
2,000/4,000*
2220
500/1,000*
2,000/4,000*
*Reel quantity depends on chip thickness. Please contact Sales Office.
Ordering information
- PSL capacitors
1206
Chip size
0805
1206
1210
1812
2220
J
Termination
J
= Nickel barrier
with 100% matte tin plating.
RoHS compliant.
Y=FlexiCap™
termination base
with nickel barrier (100% matte tin
plating). RoHS compliant.
Lead free.
1K0
Voltage
050
= 50V
063
= 63V
100
= 100V
200
= 200V
250
= 250V
500
= 500V
630
= 630V
1K0
= 1kV
2K0
= 2kV
0103
Capacitance in picofarads (pF)
First digit is 0.
Second and third digits are
significant figures of capacitance code.
The fourth digit is number of 0’s following
Example:
0103
= 10000pF
K
Capacitance
tolerance
K
= ±10%
M
= ±20%
J
Dielectric
J
= X7R
T
Packaging
T
= 178mm
(7”) reel
R
= 330mm
(13”) reel
B
= Bulk
pack - tubs
Dielectric Laboratories, Inc
2777 Route 20 East, Cazenovia,
NY 13035 USA
Phone: +1 315 655 8710
Fax: +1 315 655 0445
DLISales@knowles.com
9320/14/v7
Novacap
25111 Anza Drive, Valencia,
CA 91355 USA
Phone: +1 661 295 5920
Fax: +1 661 295 5928
NovacapSales@knowles.com
Syfer Technology Limited
Old Stoke Road, Arminghall, Norwich,
NR14 8SQ UK
Phone: +44 1603 723300
Fax: +44 1603 723301
SyferSales@knowles.com
Voltronics Corporation
2250 Northwood Drive, Salisbury,
MD 21801 USA
Phone: +1 410 749 2424
Fax: +1 443 260 2263
VoltronicsSales@knowles.com
