◆CMOS
Low Power Consumption
◆Dropout
Voltage
: 60mV@30mA
200mV@100mA
◆Output
Current
: 150mA (V
OUT
<1.75V)
240mA (V
OUT≧
1.8V)
(300mA limit)
◆Highly
Accurate
:
±2%(V
OUT
>1.5V)
±30mV
(V
OUT
≦1.5V)
◆Output
Voltage Range : 0.9V to 5.0V (50mV increments)
◆Low
ESR Capacitor Compatible
■APPLICATIONS
●Mobile
phones
●Cordless
phones, radio communication equipment
●Portable
games
●Cameras,
Video cameras
●Reference
voltage sources
●Battery
powered equipment
■GENERAL
DESCRIPTION
The XC6211/XC6219 series are highly accurate, low noise,
CMOS LDO Voltage Regulators. Offering low output noise, high
ripple rejection ratio, low dropout and very fast turn-on times,
the XC6211/6219 series is ideal for today’s cutting edge mobile
phone.
Internally the XC6211/6219 includes a reference voltage
source, error amplifiers, driver transistors, current limiters and
phase compensators. The XC6211/6219’s current limiters'
foldback circuit also operates as a short protect for the output
current limiter and. the output pin. The output voltage is set by
laser trimming.
Voltages are selectable in 50mV steps within a range of 0.9V to
5.0V. The XC6211/6219 series is also fully compatible with
low ESR ceramic capacitors, reducing cost and improving
output stability.
This high level of output stability is maintained even during
frequent load fluctuations, due to the excellent transient
response performance and high PSRR achieved across a
broad range of frequencies.
The CE function allows the output of regulator to be turned off,
resulting in greatly reduced power consumption.
■FEATURES
Maximum Output Current
: 150mA (V
OUT
<1.75V)
240mA (V
OUT≧
1.8V)
(300mA limit (TYP.))
Dropout Voltage
Output Voltage Range
Highly Accuracy
: 200mV (I
OUT
=100mA)
: 0.9V ~ 5.0V (50mV steps)
:
±2%
(V
OUT
>1.5)
±30mV
(V
OUT≦
1.5V)
Low Power Consumption
: 25μA (TYP.)
Standby Current
High Ripple Rejection
Low ESR Capacitor
Ultra Small Packages
: Less than 0.1μA (TYP.)
: 65dB @10kHz
: Ceramic capacitor
: SOT-25 (SOT-23-5)
SOT-89-5(XC6219)
USP-6B(XC6219)
Operating Voltage Range
: 2.0V ~ 6.0V
Operating Temperature Range
: -40℃ ~ 85℃
■TYPICAL
APPLICATION CIRCUIT
●XC6219
series
■TYPICAL
PERFORMANCE
CHARACTERISTICS
●Ripple
Rejection Rate
XC6211x302
XC6211x302
VIN=3.0V, DC + Vp-pAC,
IOUT=50mA, CL=1μF (ceramics)
1
2
VIN
VOUT
5
CL
1
µ
F
100
90
Ripple Rejection Rate RR (dB)
VSS
CE
NC
80
70
60
50
40
30
20
10
0
0.01
0.1
1
10
Ripple Frequen cy f (kHz)
100
3
CIN
1
µ
F
4
SOT-25 (SOT-23-5)
277
XC6211/6219
Series
■PIN
CONFIGURATION
[XC6211 Series]
VIN
5
VOUT
4
1
CE
2
VSS
3
NC
SOT-25 (SOT-23-5)
(TOP VIEW)
[XC6219 Series]
VOUT
NC
5
4
VOUT VSS
5
2
VIN
4
CE
VSS
1
VIN
2
VSS
3
CE
1
NC
2
VSS
3
CE
V IN
NC
VOUT
NC
SOT-25 (SOT-23-5)
(TOP VIEW)
SOT-89-5
(TOP VIEW)
*Please use the circuit without connecting the heat dissipation
pad. If the pad needs to be connected to other pins, it should
be noted that the pin configuration of the USP-6B package is
different on the IC series. Please refer to Contents-2.
■PIN
ASSIGNMENT
XC6211
SOT-25
5
2
1
3
4
PIN NUMBER
XC6219
SOT-25 SOT-89-5
1
4
2
2
3
3
4
1
5
5
PIN NAME
USP-6B
1
5
6
2, 4
3
V
IN
V
SS
CE
NC
V
OUT
FUNCTIONS
Power Input
Ground
ON / OFF Control
No Connection
Output
278
XC6211/6219
Series
■PRODUCT
CLASSIFICATION
●Selection
Guide
The following options for the CE pin logic and internal pull-up/down are available:
High Active + no pull-down resistor built-in (standard)
High Active + 2.0MΩ pull-down resistor built-in <between CE-V
SS
> (semi-custom)
Low Active + no pull-up resistor built-in (semi-custom)
Low Active + 2.0MΩ pull-up resistor built-in <between V
IN
-CE> (semi-custom)
Note: *With the pull-up resistor or pull-down resistor built-in types, the supply current during operation will increase
by V
IN
/ 2.0MΩ (TYP.)
●Ordering
Information
XC6211/XC6219
①②③④⑤⑥
DESIGNATOR
DESCRIPTION
SYMBOL
A
B
C
D
09∼50
2
: High Active
: High Active
: Low Active
: Low Active
DESCRIPTION
(pull-down resistor built in)
(no pull-down resistor built in)
(pull-up resistor built in)
(no pull-up resistor built in)
①
CE Pin Logic
② ③
Output Voltage
: e.g.
②
=3,
③
=0,
→
3.0V
: 100mV increments,
±2%
accuracy
e.g.
③
=2,
③=8,
④
=2
→
2.80V,
±2%
: 50mV increments,
±2%
accuracy
e.g.
②
=2,
③
=8,
④
=A
→
2.85V,
±2%
: SOT-25 (SOT-23-5)
: SOT-89-5 (XC6219)
: USP-6B (XC6219)
: Embossed tape, Standard feed
: Embossed tape, Reverse feed
④
Output Voltage
A
M
⑤
Packages
P
D
R
L
⑥
Device Orientation
279
