Connection Systems
Cordsets and Patchcords
Mini and Mini-Plus Style Quick-Disconnect, 4-pin, 5-pin, 7-pin and 8-pin Cordset
Specifications
Coupling Nut
Connector
Contacts
Approvals
Cable
Cable O.D.
Epoxy-coated zinc
Molded oil-resistant PVC
Gold-plated palladium/nickel
UL recognized and CSA certified
Oil-resistant, yellow PVC jacket, 300V
4/c = 7.4mm (0.29in)
5/c = 7.4mm (0.29in)
7/c = 8.0mm (0.32in)
8/c = 9.0mm (0.35in)
-20°C to +105°C (-4°F to +221°F)
Temperature
Approximate Dimensions—mm (inches)
Features
• 4-, 5-, 7- and 8-pin configurations
• One-piece molded body design for application durability
• Highly visible yellow PVC jacket offers good oil and chemical
resistance
• Ratcheting coupling nut for vibration resistance
➊
55.8 (2.2)
Straight Female
➊
Mini: 25.4 (1.0) Dia.
Mini-Plus: 28.4 (1.12) Dia.
Dimensions are approximate. Illustrations are not drawn to scale.
Cable
Body Size
Wire Colour
1 Black
2 Blue
3 Brown
4 White
Mini
Straight
5
4
3
1
2
Product Selection—Mini
Female Connector (Sensor End)
Face View of Female
Connector Style
Straight
4
3
Wire Rating
Length—m (ft)
1.8 (6)
3.7 (12)
6.1 (20)
1.8 (6)
3.7 (12)
6.1 (20)
1.8 (6)
3.7 (12)
6.1 (20)
1.8 (6)
3.7 (12)
6.1 (20)
2 (6.5)
5 (16.4)
10 (32.8)
15 (49.2)
20 (65.6)
30 (98.4)
2 (6.5)
5 (16.4)
Catalogue Number
889N-F4AE-6F
889N-F4AE-12F
889N-F4AE-20F
889N-R4AE-6F
889N-R4AE-12F
889N-R4AE-20F
889N-F5AE-6F
889N-F5AE-12F
889N-F5AE-20F
889N-R5AE-6F
889N-R5AE-12F
889N-R5AE-20F
889N-F7AG-2
889N-F7AG-5
889N-F7AG-10
889N-F7AG-15
889N-F7AG-20
889N-F7AG-30
889N-F8AE-2
889N-F8AE-5
889N-F8AE-10
889N-F8AE-15
889N-F8AE-20
889N-F8AE-30
1
2
Right Angle
Right Angle
1 Black
2 Blue
3 Grey
4 Brown
5 White
1 Black
2 White
3 Blue
4 Brown
5 Grey
6 Yellow
7 Green
18AWG
300V
3A
6
5
4
7
1
2
3
Straight
Mini-Plus
(5) 18AWG
(2) 20AWG
300V
3A
6
5
4
7
8
1
2
3
1 Red
2 White
3 Blue
4 Brown
5 Grey
6 Yellow
7 Green
8 Pink
18AWG
300V
3A
10 (32.8)
15 (49.2)
20 (65.6)
30 (98.4)
15-12
