898D Overview

Female mini-plus cordset

Connection Systems
Selection Guide
889N
Mini-Plus Style
Cordsets
889N
Mini-Plus Style
Patchcords
889N
Mini-Plus Style
Cordsets
889N
Mini-Plus Style
Patchcords
889N
Mini-Style
Cordsets
889N
Mini-Style
Cordsets
Female mini-plus
cordset
9, 10 and 12 pin
connector types
Straight and right angle
versions
Heavy duty STOOW-A
16 AWG cable
Oil resistant yellow
PVC jacket
Mates with main
connectors on
898-series distribution
boxes
600V
Male to female mini-
plus patchcord
9, 10, and 12-pin
connector types
Straight and right
angle versions
Heavy duty STOOW
16AWG or 18AWG cable
Oil resistant PVC jacket
Mates 898-series
distribution boxes to
1667-series
PanelConnect
Female mini-plus
cordset
7 and 8 pin
connector types
Straight female
connector
Heavy duty STOOW
16 AWG cable
Oil resistant yellow
PVC jacket
Mates with main
connectors on
898-series distribution
boxes
600V
Male to female mini-
plus patchcord
7 and 8-pin
connector types
Straight configuration
Heavy duty STOOW
16AWG cable
Oil resistant PVC jacket
Mates with main
connectors on
898-series distribution
boxes
Female mini
cordset
3, 4, 5 and 6 pin
connector types
Straight and right
angle versions
Heavy duty STOOW
16 AWG or standard
18 AWG cable
Oil resistant yellow
PVC jacket
Coiled cord available
Female illuminated
mini cordset
3 pin connector type
Right angle female
connector
300V 18 AWG cable
Oil resistant yellow
PVC jacket
Description
Features
16AWG: 600V
18AWG: 300V
Straight:
51mm x 32mm
Right angle:
56mm x 67mm
600V
16 AWG: 600V
18 AWG: 300V
Straight:
56mm x 25.4mm
Right angle:
40mm x 45mm
120V AC
Rated Voltage
Connector/
Body
Dimensions
Additional
Info
Straight:
51mm x 32mm
Right angle:
56mm x 67mm
56mm x 28mm
56mm x 28mm
40mm x 45mm
M115 catalog page 3-26
www.ab.com/catalogs
M115 catalog page 3-29
www.ab.com/catalogs
M115 catalog page 3-24
www.ab.com/catalogs
M115 catalog page 3-28
www.ab.com/catalogs
M115 catalog page 3-8
and 3-11
www.ab.com/catalogs
M115 catalog page 3-10
www.ab.com/catalogs
889N
Mini-Style
Male Cordsets
889N
Mini-Style
Patchcords
889D
DC Micro-Style
Cordsets
889D
DC Micro-Style
Cordsets
889D
DC Micro-Style
Male Cordsets
889D
DC Micro-Style
Patchcords
Male mini cordset
Male to female
mini patchcord
3, 4, 5, and 6 pin
connector types
Straight female
connector to straight or
right angle male
Heavy duty STOOW
16 AWG cable
Oil resistant yellow
PVC jacket
Female DC micro
cordset
4, 5, and 8 pin
connector types
Straight or right angle
versions
22 AWG or 18 AWG cable
Yellow or black cable
Standard or braided
versions
Multiple jacket types:
PVC, TPE, ToughLink,
ToughWeld
Coiled cord available
300V
Female illuminated
DC micro cordset
4 pin connector type
Straight and right angle
connectors
Standard 22 AWG
cable
PNP or NPN versions
Oil resistant yellow
PVC jacket
Male DC micro
cordset
4 and 5 pin connector
type
Straight and right angle
male connector
Standard 22 AWG cable
Yellow or black cable
Multiple jacket types:
PVC, TPE, ToughLink,
ToughWeld
Male to female DC
micro patchcord
4, 5, and 8 pin connector
types
Straight or right angle
female connector to
straight or right angle
male
22 AWG or 18 AWG cable
Yellow or black cable
Multiple jacket types:
PVC, TPE, ToughLink,
ToughWeld
300V
Description
3 and 4 pin connector
types
Straight male connector
Heavy duty STOOW
16 AWG cable
Oil resistant yellow PVC
jacket
Features
600V
600V
10-30V DC
300V
Rated Voltage
Connector/
Body
Dimensions
Additional
Info
59
49mm x 25.4mm
Straight:
49mm x 25.4mm
Right angle:
30mm x 42mm
Straight:
42mm x 15mm
Right angle:
27mm x 30mm
Straight:
42mm x 15mm
Right angle:
27mm x 30mm
Straight:
43mm x 15mm
Right angle:
43mm x 31mm
Straight:
43mm x 15mm
Right angle:
43mm x 31mm
M115 catalog page 3-12
www.ab.com/catalogs
M115 catalog page 3-13
www.ab.com/catalogs
This magazine page 70
M115 catalog page 3-36
www.ab.com/catalogs
M115 catalog page 3-40
www.ab.com/catalogs
This magazine page 70
M115 catalog page 3-45
www.ab.com/catalogs
This magazine page 70
M115 catalog page 3-46
www.ab.com/catalogs
