D5V0L6A3LP37: DescriptionCHANNEL LOW CAPACITANCE BI-DIRECTIONAL TVS ARRAY; File Size108KB，5 Pages; ManufacturerDiodes; Websitehttp://www.diodes.com/

Download Datasheet View All

D5V0L6A3LP37 Overview

CHANNEL LOW CAPACITANCE BI-DIRECTIONAL TVS ARRAY

Preview

Download Datasheet

View All

D5V0L2B3SO

2 CHANNEL LOW CAPACITANCE BI-DIRECTIONAL TVS ARRAY

Features

ADVANCE INFORMATION

•

Provides ESD Protection per IEC 61000-4-2 Standard:

Air – ±30kV, Contact – ±30kV

2 Channels of Bi-Directional ESD Protection

Low Channel Input Capacitance

Typically Used in Cellular Handsets, Portable Electronics,

Communication Systems, Computers and Peripherals

Lead Free/RoHS Compliant (Note 1)

“Green” Device (Note 2)

Mechanical Data

•

Case: SOT23

Case Material: Molded Plastic, “Green” Molding Compound.

UL Flammability Classification Rating 94V-0

Moisture Sensitivity: Level 1 per J-STD-020

Terminals: Matte Tin Finish annealed over Alloy 42 leadframe

(Lead Free Plating). Solderable per MIL-STD-202, Method 208

Weight: 0.0089 grams (approximate)

Device Schematic

Top View

Pin Configuration

Ordering Information

(Note 3)

D 5V0 L X B X XXX- XX

Voltage

Capacitance

# of Channels

1: 1 Channel

2: 2 Channels

4: 4 Channels

6: 6 Channels

Polarity

B: Bidirectional

(Symmetrical)

U: Unidirectional

A: Bidirectional

(Asymmetrical)

# of Pins

2: 2 Pins

3: 3 Pins

5: 5 Pins

6: 6 Pins

8: 8 Pins

10: 10 Pins

Package

Packing

5V0: 5.0 Volts X: Extremely Low (<0.5pF)

F: Ultra Low (0.5 ~ 1.0pF)

P: Very Low (1.1 ~ 10pF)

L: Low (10.1 ~ 20pF)

M: Medium (>20pF)

LP3: X3-DFN0603-2

7: 7” reel (3K/reel)

LP: X1-DFN1006-2 7B: 7” reel (10Kreel)

LP4: X2-DFN1006-2

13: 13” reel

WS: SOD323

T: SOD523/SOT523

SO: SOT23/SOT25

W: SOD123/SOT323

TS: TSOT25/TSOT26

S: SOT353/SOT363

V:SOT553/SOT563

Part Number

D5V0L2B3SO-7

Notes:

Case

SOT23

Packaging

3000/Tape & Reel

1. EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant. No purposely added lead. Halogen and Antimony free.

2. Diodes Inc.’s “Green” policy can be found on our website at http://www.diodes.com.

3. For packaging details, go to our website at http://www.diodes.com.

Marking Information

TB2

TB2 = Product Type Marking Code

YM = Date Code Marking

Y = Year (ex: Z = 2012)

M = Month (ex: 9 = September)

Date Code Key

Year

Code

Month

Code

2011

Jan

Feb

2012

Mar

Apr

2013

May

Jun

2014

Jul

2015

Aug

Sep

2016

Oct

Nov

2017

Dec

D5V0L2B3SO

Document number: DS35430 Rev. 5 - 2

1 of 4

www.diodes.com

January 2012

D5V0L2B3SO

ADVANCE INFORMATION

IMPORTANT NOTICE

DIODES INCORPORATED MAKES NO WARRANTY OF ANY KIND, EXPRESS OR IMPLIED, WITH REGARDING TO THIS DOCUMENT,

INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE

(AND THEIR EQUIVALENTS UNDER THE LAWS OF ANY JURISDICTION).

Diodes Incorporated and its subsidiaries reserve the right to make modifications, enhancements, improvements, corrections or other changes

without further notice to this document and any product described herein. Diodes Incorporated does not assume any liability arising out of the

application or use of this document or any product described herein; neither does Diodes Incorporated convey any license under its patent or

trademark rights, nor the rights of others. Any Customer or user of this document or products described herein in such applications shall assume

all risks of such use and will agree to hold Diodes Incorporated and all the companies whose products are represented on Diodes Incorporated

website, harmless against all damages.

Diodes Incorporated does not warrant or accept any liability whatsoever in respect of any products purchased through unauthorized sales channel.

Should Customers purchase or use Diodes Incorporated products for any unintended or unauthorized application, Customers shall indemnify and

hold Diodes Incorporated and its representatives harmless against all claims, damages, expenses, and attorney fees arising out of, directly or

indirectly, any claim of personal injury or death associated with such unintended or unauthorized application.

Products described herein may be covered by one or more United States, international or foreign patents pending. Product names and markings

noted herein may also be covered by one or more United States, international or foreign trademarks.

LIFE SUPPORT

Diodes Incorporated products are specifically not authorized for use as critical components in life support devices or systems without the express

written approval of the Chief Executive Officer of Diodes Incorporated. As used herein:

A. Life support devices or systems are devices or systems which:

1. are intended to implant into the body, or

2. support or sustain life and whose failure to perform when properly used in accordance with instructions for use provided in the

labeling can be reasonably expected to result in significant injury to the user.

A critical component is any component in a life support device or system whose failure to perform can be reasonably expected to cause the

failure of the life support device or to affect its safety or effectiveness.

Customers represent that they have all necessary expertise in the safety and regulatory ramifications of their life support devices or systems, and

acknowledge and agree that they are solely responsible for all legal, regulatory and safety-related requirements concerning their products and any

use of Diodes Incorporated products in such safety-critical, life support devices or systems, notwithstanding any devices- or systems-related

information or support that may be provided by Diodes Incorporated. Further, Customers must fully indemnify Diodes Incorporated and its

representatives against any damages arising out of the use of Diodes Incorporated products in such safety-critical, life support devices or systems.

www.diodes.com

D5V0L2B3SO

Document number: DS35430 Rev. 5 - 2

4 of 4

www.diodes.com

January 2012
