Eco Series 4-Port Polarization Insen-
sitive Miniature Optical Circulator
MIOC4 Eco Series
Product Description
Oplink’s polarization insensitive miniature circulator features excellent opti¬cal
characteristics over a wide wavelength range while delivering a smallest form
factor. It possesses low insertion loss, high isolation, and low PDL making it
an ideal candidate for EDFA, add/drop, dynamic gain equalization, dispersion
compensation and other optical network applications.
Oplink can provide customized designs to meet specialized feature applica-
tions. Also, Oplink offers modular assemblies that integrate other components
to form a full function module or subsystem.
Performance Specificationns
MIOC4 Eco Series
1310
Operating Wavelength Range ( λ
Op
)
C Band
L Band
C+L Band
Insertion Loss (1→2, 2→3, 3→4 @
λ
Op
, T
Op
, SOP)
Polarization Mode Dispersion (PMD)
Channel Isolation (2→1, 3→2, 4→3
@ λ
Op
, T
Op
, SOP)
Peak Isolation
Directivity (1→3, 2→4)
Polarization Dependent Loss (PDL)
Return Loss (RL)
Optical Power Handling
Operating Temperature Rang (T
Op
)
Storage Temperature
Fiber Type
Physical Dimension
Note:
1)
All the parameters exclude connector contribution.
0 to +70
-40 to +85
Corning SMF-28
(Φ) 5.5 x (L) 40.0
mm
50
500
1310, C or L
C+L Band
1310, C or L
C+L Band
1310, C or L
C+L Band
38
32
50
50
0.15
Min
Typical
1290 ~ 1330
1525 ~ 1565
1570 ~ 1610
1525 ~ 1610
0.6
0.7
0.8
0.9
0.06
0.1
dB
ps
dB
dB
dB
dB
dB
mW
°C
°C
nm
Max
Unit
Features
Wide Wavelength Selection
Smallest Package Size
Low Insertion Loss, PDL
High Channel Isolation
Epoxy-free on Optical Path
Telcordia GR1221/1209 Qualified
RoHS6/6 Compliant
Applications
Dispersion Compensation
Fiber Sensor
Test Instruments
Optical Amplification
S0329 - R02. (web) 20120629
Eco Series 4-Port Polarization Insensitive
Miniature Optical Circulator
MIOC4 Eco Series
Mechanical Drawing / Package Dimensions
NOTES: (UNLESS OTHERWISE SPECIFIED)
1. ALL DIMENSIONS ARE IN mm.
2. TOL: .X=±0.5, .XX=±0.2.
46335 Landing Pkwy Fremont, CA 94538 Tel: (510) 933-7200 Fax: (510) 933-7300 Email: Sales@Oplink.com • www.oplink.com
Ordering Information
Oplink can provide a remarkable range of customized optical solutions. For detail, please contact Oplink’s OEM
design team or account manager for your requirements and ordering information (510) 933-7200.
MIOC
G
E
C
O
0
4
1
Wavelength
1310 window = 3
C band = 5
L band = L
C+L band = E
Port Configuration
4 ports = 4
Fiber Length
0.5 meter = H
1.0 meter = 1
1.5 meters = 5
2.0 meters = 2
Connector Type
None = 1
FC/PC = 2
FC/SPC = 3
FC/APC = 4
SC/PC = 5
SC/SPC = 6
SC/APC = 7
ST = 8
LC /UPC = 9
MU = A
LC/APC = B
Package Type
P1 = 1
Fiber Type
250μm bare fiber = 1
900μm loose tube = 2
* The tolerance of fiber length is +/-0.1m.
* 1 meter is standard. The lead time for special fiber length will be longer.
S0329 - R02. (web) 20120629
Product Lines:
Mux/Demux
Switching/Routing
Coupling/Splitting
Monitoring/Conditioning
Amplification
Transmission
Interconnect
RGB Laser Modules
