Type 3198 105 °C Aluminum Electrolytic, Screw Terminal
Very Long Life, Low ESR
Type 3198 has very long life and low ESR. Applications
include industrial, power supplies and audio.
Specifications
Temperature Range
Rated Voltage Range
Capacitance Range
Endurance
–40 ºC to +105 ºC
6.3 Vdc to 75 Vdc
220 uF to 1.0 F
3000 h / 105 °C
RoHS Compliant
Case Dimensions, Uninsulated Bare Can
Case
Code
BA
BB
BC
BD
BE
BF
BG
BH
DA
DB
DC
DD
DE
DF
DG
DH
EA
EB
EC
ED
EE
EF
EG
EH
FB
FC
FD
FE
FF
FG
FH
GC
GD
GE
GF
GG
GH
GJ
GN
Diam. (D)
±0.031
(in)
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.375
1.750
1.750
1.750
1.750
1.750
1.750
1.750
1.750
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.000
2.500
2.500
2.500
2.500
2.500
2.500
2.500
3.000
3.000
3.000
3.000
3.000
3.000
3.000
3.000
±0.8
(mm )
34.9
34.9
34.9
34.9
34.9
34.9
34.9
34.9
44.5
44.5
44.5
44.5
44.5
44.5
44.5
44.5
50.8
50.8
50.8
50.8
50.8
50.8
50.8
50.8
63.5
63.5
63.5
63.5
63.5
63.5
63.5
76.2
76.2
76.2
76.2
76.2
76.2
76.2
76.2
Length (L)
±0.062
(in)
2.125
2.625
3.125
3.625
4.125
4.625
5.125
5.625
2.125
2.625
3.125
3.625
4.125
4.625
5.125
5.625
2.125
2.625
3.125
3.625
4.125
4.625
5.125
5.625
2.625
3.125
3.625
4.125
4.625
5.125
5.625
3.125
3.625
4.125
4.625
5.125
5.625
5.875
8.625
±1.6
(mm )
54.0
66.7
79.4
92.1
104.8
117.5
130.2
142.9
54.0
66.7
79.4
92.1
104.8
117.5
130.2
142.9
54.0
66.7
79.4
92.1
104.8
117.5
130.2
142.9
66.7
79.4
92.1
104.8
117.5
130.2
142.9
79.4
92.1
104.8
117.5
130.2
142.9
149.2
219.1
Terminal Space(P)
±0.014
±0.4
(in)
(mm )
0.5
12.7
0.5
12.7
0.5
12.7
0.5
12.7
0.5
12.7
0.5
12.7
0.5
12.7
0.5
12.7
0.75
19.1
0.75
19.1
0.75
19.1
0.75
19.1
0.75
19.1
0.75
19.1
0.75
19.1
0.75
19.1
0.875
22.2
0.875
22.2
0.875
22.2
0.875
22.2
0.875
22.2
0.875
22.2
0.875
22.2
0.875
22.2
1.125
28.6
1.125
28.6
1.125
28.6
1.125
28.6
1.125
28.6
1.125
28.6
1.125
28.6
1.25
31.8
1.25
31.8
1.25
31.8
1.25
31.8
1.25
31.8
1.25
31.8
1.25
31.8
1.25
31.8
Vent Plug (A)
(in)
(mm )
0.39
8.0
0.39
8.0
0.39
8.0
0.39
8.0
0.39
8.0
0.39
8.0
0.39
8.0
0.39
8.0
0.453
11.5
0.453
11.5
0.453
11.5
0.453
11.5
0.453
11.5
0.453
11.5
0.453
11.5
0.453
11.5
0.5
12.7
0.5
12.7
0.5
12.7
0.5
12.7
0.5
12.7
0.5
12.7
0.5
12.7
0.5
12.7
0.625
15.9
0.625
15.9
0.625
15.9
0.625
15.9
0.625
15.9
0.625
15.9
0.625
15.9
0.75
19.0
0.75
19.0
0.75
19.0
0.75
19.0
0.75
19.0
0.75
19.0
0.75
19.0
0.75
19.0
Typical Weight
(oz )
(g)
2.5
72
3.2
90
3.7
105
4.2
120
4.7
135
6.0
170
7.7
220
9.5
270
5.6
160
6.1
175
6.3
180
7.2
205
7.7
220
8.2
235
8.8
250
9.5
270
6.0
170
6.3
180
6.7
190
7.7
220
8.9
255
10.2
290
11.2
320
12.3
350
10.5
300
13.0
370
14.0
400
15.6
445
21.0
600
22.8
650
21.0
600
18.2
520
20.0
570
21.0
600
25.2
720
29.8
850
34.0
970
36.8
1050
51.1
1460
Optional
Bracket
Part No.
115058-06
115058-06
115058-06
115058-06
115058-06
115058-06
115058-06
115058-06
115058-15
115058-15
115058-15
115058-15
115058-15
115058-15
115058-15
115058-15
115058-09
115058-09
115058-09
115058-09
115058-09
115058-09
115058-09
115058-09
115058-14
115058-14
115058-14
115058-14
115058-14
115058-14
115058-14
115058-11
115058-11
115058-11
115058-11
115058-11
115058-11
115058-11
115058-11
CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: (864)843-2277 • Fax: (864)843-3800
