TNPW2010154RDEEF datasheet, PDF

Datasheet> All Categories > Passive components> The resistor> TNPW2010154RDEEF

TNPW2010154RDEEF: DescriptionFixed Resistor, Thin Film, 0.4W, 154ohm, 300V, 0.5% +/-Tol, 25ppm/Cel, Surface Mount, 2010, CHIP, ROHS COMPLIANT; CategoryPassive components The resistor; File Size127KB，10 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric View All

TNPW2010154RDEEF Overview

Fixed Resistor, Thin Film, 0.4W, 154ohm, 300V, 0.5% +/-Tol, 25ppm/Cel, Surface Mount, 2010, CHIP, ROHS COMPLIANT

TNPW2010154RDEEF Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1576789499
package instruction	CHIP, ROHS COMPLIANT
Reach Compliance Code	compliant
Country Of Origin	Germany, Israel
ECCN code	EAR99
YTEOL	7.2
Other features	LASER TRIMMABLE; PRECISION; RATED AC VOLTAGE: 300V
structure	Chip
JESD-609 code	e3
Installation features	SURFACE MOUNT
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package height	0.6 mm
Package length	5 mm
Package shape	RECTANGULAR PACKAGE
Package form	SMT
Package width	2.5 mm
method of packing	TR, BLISTER, 7 INCH
Rated power dissipation(P)	0.4 W
Rated temperature	70 °C
resistance	154 Ω
Resistor type	FIXED RESISTOR
size code	2010
surface mount	YES
technology	THIN FILM
Temperature Coefficient	25 ppm/°C
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal shape	WRAPAROUND
Tolerance	0.5%
Operating Voltage	300 V

Preview

Download Datasheet

View All

TNPW e3

Vishay

High Stability Thin Film Flat Chip Resistor

≤

0.05 % (1000 h rated power at 70 °C)

FEATURES

•

Superior moisture resistivity

≤

0.25 % (85 °C;

56 days; 85 % RH)

•

Lead (Pb)-free solder contacts, RoHS compliant

•

AEC-Q200 compliant (sizes 0402 to 1206)

•

Low temperature coefficient and tight tolerances

(± 0.1 %; ± 10 ppm/K)

•

Waste gas resistant

RoHS

COMPLIANT

APPLICATIONS

TNPW e3 Precision Thin Film Flat Chip Resistors are the

perfect choice for most fields of modern electronics where

highest reliability and stability is of major concern. Typical

applications include automotive, telecommunication,

industrial, medical equipment, precision test and measuring

equipment.

•

Test and measuring equipment

Telecommunication

Medical equipment

Industrial equipment

Instrumentation

Automotive

STANDARD ELECTRICAL SPECIFICATIONS

DESCRIPTION

Metric size

Resistance range

Resistance tolerance

Temperature

coefficent

Climatic category

(LCT/UCT/days)

Rated dissipation,

70 (2)

Operating voltage,

max.

AC/DC

Maximum permissible

film temperature

Thermal resistance

(3)

Max. resistance

change at

;

ΔR/R

1000 h

8000 h

225 000 h

Insulation voltage:

ins

1 min

Continuous

FIT

observed

Weight/1000 pieces

75 V

≤

0.1 x 10

-9

0.65 g

100 V

75 V

≤

0.1 x 10

-9

200 V

75 V

5.5 g

300 V

75 V

10 g

300 V

75 V

≤

0.1 x 10

-9

16 g

300 V

75 V

≤

0.1 x 10

-9

28 g

300 V

75 V

≤

0.1 x 10

-9

39 g

55/125/56

0.063 W

50 V

155 °C

870 K/W

TNPW0402

RR 1005M

TNPW0603

RR 1608M

TNPW0805

RR 2012M

TNPW1206

RR 3216M

TNPW1210

(1)

RR 3225M

TNPW2010

RR 5025M

TNPW2512

(1)

RR 6332M

to 100 kΩ 10

to 332 kΩ 10

to 1 MΩ 10

to 2 MΩ 10

to 3.01 MΩ 10

to 4.99 MΩ 10

to 8.87 MΩ

± 1 %; ± 0.5 %; ± 0.1 %

± 50 ppm/K; ± 25 ppm/K; ± 15 ppm/K; ± 10 ppm/K

55/125/56

0.1 W

75 V

155 °C

550 K/W

55/125/56

0.125 W

150 V

155 °C

440 K/W

55/125/56

0.25 W

200 V

155 °C

220 K/W

55/125/56

0.33 W

200 V

155 °C

170 K/W

± 50 ppm/K; ± 25 ppm/K

55/125/56

0.4 W

300 V

155 °C

140 K/W

55/125/56

0.5 W

300 V

155 °C

110 K/W

to 100 kΩ 10

to 332 kΩ 10

to 1 MΩ 10

to 2 MΩ 10

to 3.01 MΩ 10

to 4.99 MΩ 10

to 8.87 MΩ

≤

0.05 %

≤

0.10 %

≤

0.30 %

≤

0.05 %

≤

0.10 %

≤

0.30 %

≤

0.05 %

≤

0.10 %

≤

0.30 %

≤

0.05 %

≤

0.10 %

≤

0.30 %

≤

0.05 %

≤

0.10 %

≤

0.30 %

≤

0.05 %

≤

0.10 %

≤

0.30 %

≤

0.05 %

≤

0.10 %

≤

0.30 %

≤

0.1 x 10

-9

≤

0.1 x 10

-9

Notes

(1)

Size not specified in EN 140401-801

(2)

Rated voltage

. The power dissipation on the resistor generates a temperature rise against the local ambient, depending on the heat

flow support of the printed-circuit board (thermal resistance). Using advanced temperature level may require special considerations towards

the choice of circuit board and solder material. The rated dissipation applies only if the permitted film temperature is not exceeded.

(3)

Measuring conditions in accordance with EN 140401-801

• TNPW 0402 without marking

Document Number: 28758

Revision: 30-Sep-08

For technical questions, contact: filmresistors.thinfilmchip@vishay.com

www.vishay.com
