High-Q Ceramic Capacitors
(HQN Series)
Features:
•
•
•
•
•
•
RoHS Compliant and Halogen Free
Excellent Q and low ESR performance at high frequency
Voltage range: 25V to 250V
Capacitance range: 0.1pF to 220pF
Low power consumption
Suitable for IC decoupling application
Part Number Structure
C
0805 HQN
Size
0201
0402
0603
0805
201
-
1R0
Capacitance
(pico - Farads)
1st two digits
are significant,
followed by
number of
zeroes.
(R denotes
decimal)
0R5=0.5pF
101=100pF
C
Tolerance
* * A =
±
0.05pF
* B =
±
0.1pF
*C =
±
0.25pF
*D =
±
0.5pF
F =
±
1%
G =
±
2%
J =
±
5%
K = ± 10%
*For capacitance
values below
10pF only
** For capacitance
values of 8.2pF
and less
N
Termination
N = 100% matte Tin (Sn)
over Nickel
P
Packaging
P = Paper Tape
E = Embossed Tape
Ceramic
Capacitor
Series
Rated Voltage
250 = 25VCDW
500 = 50VCDW
101 = 100VCDW
201 = 200VCDW
251 = 250VCDW
501 = 500VCDW
Example P/N:
C0805HQN201-1R0CNP
Dimensions
w
L
E/B
Unit: inches (mm)
Size
(inches)
0201
0402
0603
0805
L
0.024
(0.6
±
0.010)
0.040
(1.02
±
0.1)
0.060
(1.52)
0.080
(2.03)
W
0.012
(0.30)
0.020
(0.51
±
0.01)
0.030
(0.76)
0.050
(1.27)
T (Max)
0.012
(0.3)
0.20
(0.51
±
0.01)
0.035
(0.90)
0.050
(1.27)
E/B (Max)
0.006
(0.15)
0.010
(0.25)
0.015
(0.38)
0.020
(0.508)
T
Electrical Specifications
High-Q NPO
10
0201
0402
0603
0805
Frequency (GHz)
Typical Series Resonant Frequency
1
0.1
Temperature Coefficient:
0% ± 30PPM /°C, -55°C to +125°C
Quality Factor:
Q > 5,000 @ 1MHz (Typical 10,000)
0201 Quality Factor:
Q > 1,000 @ 1MHz (Typical 10,000)
Ageing:
None
Insulation Resistance:
1,000 Ω-F or 100 GΩ (whichever is
less at 25°C, VDCW). 50 mA max.
(IR at 125°C is 10% of the value at 25°C)
Dielectric Strength:
2.5 x VDCW Min., 25°C, 50 mA max
1000
1
10
Capacitance (pF)
100
Email:
sales@venkel.com
|
Phone:
512.794.0081
|
Toll Free:
800.950.8365
|
Web:
www.venkel.com
Rev. 10/2018-B
1
High-Q Ceramic Capacitors
(HQN Series)
Voltage & Capacitance Range
100pF
120pF
150pF
180pF
220pF
270pF
CASE
SIZE
Volt-
age
25V
50V
25V
0402
50V
100V
200V
50V
0603
100V
200V
250V
100V
0805
200V
250V
500V
330pF
390pF
0.1pF
0.2pF
0.3pF
0.4pF
0.5pF
0.6pF
0.7pF
0.8pF
0.9pF
1.0pF
1.2pF
1.5pF
1.8pF
2.2pF
2.3pF
2.7pF
3.3pF
3.9pF
4.7pF
5.6pF
5.7pF
6.8pF
8.2pF
9.1pF
10pF
12pF
15pF
18pF
20pF
22pF
27pF
33pF
39pF
47pF
56pF
68pF
82pF
0201
Additional values may be available. Please contact us for more information.
Test Parameters
Test parameters for High-Q NPO Capacitors: 1MHz ± 100Hz at 1.0 ± 0.2 Vrms, 25°C, ~50% relative humidity.
RF Performance Characteristics
0201, 0402, 0603 & 0805 Maximum ESR
0.25
0.20
2.7pF
0402
10pF
5.6pF
10pF
47pF
100pf
ESR (ohms)
0.10
0.05
100
300
500
80
0 1000
Frequency (MHz)
2
Email:
sales@venkel.com
|
Phone:
512.794.0081
|
Toll Free:
800.950.8365
|
Web:
www.venkel.com
Rev. 10/2018-B
