ATMEGA48P-20AUR: Description8-bit microcontrollers - mcu avr 4K flsh 256b EE 512b sram5v-20mhz 5V; CategoryThe embedded processor and controller Microcontrollers and processors; File Size6MB，421 Pages; ManufacturerAtmel (Microchip); Environmental Compliance

Download Datasheet Parametric View All

ATMEGA48P-20AUR Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ATMEGA48P-20AUR	-	-	View	Buy Now

ATMEGA48P-20AUR Overview

8-bit microcontrollers - mcu avr 4K flsh 256b EE 512b sram5v-20mhz 5V

ATMEGA48P-20AUR Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Parts packaging code	QFP
package instruction	TQFP, TQFP32,.35SQ,32
Contacts	32
Reach Compliance Code	compli
ECCN code	EAR99
core architecture	AVR
Device core	AVR
clock speed	20
Memory	0.5
flash memory	4
were able	0
Adc channel	8
ADC resolution	10
Has ADC	YES
Other features	ALSO OPERATES AT 2.7 V MINIMUM SUPPLY AT 10 MHZ
Address bus width
bit size	8
CPU series	AVR RISC
maximum clock frequency	20 MHz
DAC channel	YES
DMA channel	NO
External data bus width
JESD-30 code	S-PQFP-G32
length	7 mm
Number of I/O lines	23
Number of terminals	32
On-chip program ROM width	16
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	TQFP
Encapsulate equivalent code	TQFP32,.35SQ,32
Package shape	SQUARE
Package form	FLATPACK, THIN PROFILE
power supply	3/5 V
Certification status	Not Qualified
RAM (bytes)	512
rom(word)	2048
ROM programmability	FLASH
Maximum seat height	1.2 mm
speed	20 MHz
Maximum slew rate	9 mA
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	QUAD
width	7 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER, RISC
Base Number Matches	1

Preview

Download Datasheet

View All

Features

•

High Performance, Low Power Atmel

AVR

8-Bit Microcontroller

•

Advanced RISC Architecture

– 131 Powerful Instructions – Most Single Clock Cycle Execution

– 32 x 8 General Purpose Working Registers

– Fully Static Operation

– Up to 20 MIPS Throughput at 20 MHz

– On-chip 2-cycle Multiplier

High Endurance Non-volatile Memory Segments

– 4/8/16KBytes of In-System Self-Programmable Flash progam memory

– 256/512/512Bytes EEPROM

– 512/1K/1KBytes Internal SRAM

– Write/Erase Cycles: 10,000 Flash/100,000 EEPROM

– Data retention: 20 years at 85°C/100 years at 25°C

(1)

– Optional Boot Code Section with Independent Lock Bits

In-System Programming by On-chip Boot Program

True Read-While-Write Operation

– Programming Lock for Software Security

QTouch

library support

– Capacitive touch buttons, sliders and wheels

– QTouch and QMatrix acquisition

– Up to 64 sense channels

Peripheral Features

– Two 8-bit Timer/Counters with Separate Prescaler and Compare Mode

– One 16-bit Timer/Counter with Separate Prescaler, Compare Mode, and Capture

Mode

– Real Time Counter with Separate Oscillator

– Six PWM Channels

– 8-channel 10-bit ADC in TQFP and QFN/MLF package

Temperature Measurement

– 6-channel 10-bit ADC in PDIP Package

Temperature Measurement

– Programmable Serial USART

– Master/Slave SPI Serial Interface

– Byte-oriented 2-wire Serial Interface (Philips I

C compatible)

– Programmable Watchdog Timer with Separate On-chip Oscillator

– On-chip Analog Comparator

– Interrupt and Wake-up on Pin Change

Special Microcontroller Features

– Power-on Reset and Programmable Brown-out Detection

– Internal Calibrated Oscillator

– External and Internal Interrupt Sources

– Six Sleep Modes: Idle, ADC Noise Reduction, Power-save, Power-down, Standby,

and Extended Standby

I/O and Packages

– 23 Programmable I/O Lines

– 28-pin PDIP, 32-lead TQFP, 28-pad QFN/MLF and 32-pad QFN/MLF

Operating Voltage:

– 1.8 - 5.5V for ATmega48P/88P/168PV

– 2.7 - 5.5V for ATmega48P/88P/168P

Temperature Range:

– -40

C to 85

Speed Grade:

– ATmega48P/88P/168PV: 0 - 4MHz @ 1.8 - 5.5V, 0 - 10MHz @ 2.7 - 5.5V

– ATmega48P/88P/168P: 0 - 10MHz @ 2.7 - 5.5V, 0 - 20MHz @ 4.5 - 5.5V

Low Power Consumption at 1MHz, 1.8V, 25°C:

– Active Mode: 0.3mA

– Power-down Mode: 0.1µA

– Power-save Mode: 0.8µA (Including 32kHz RTC)

•

8-bit Atmel

Microcontroller

with 4/8/16K

Bytes In-System

Programmable

Flash

ATmega48P/V

ATmega88P/V

ATmega168P/V

•

Note:

1. See

”Data Retention” on page 8

for details.

Rev. 8025M–AVR–6/11

ATmega48P/88P/168P

1.1

1.1.1

Pin Descriptions

VCC

Digital supply voltage.

1.1.2

GND

Ground.

1.1.3

Port B (PB7:0) XTAL1/XTAL2/TOSC1/TOSC2

Port B is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The

Port B output buffers have symmetrical drive characteristics with both high sink and source

capability. As inputs, Port B pins that are externally pulled low will source current if the pull-up

resistors are activated. The Port B pins are tri-stated when a reset condition becomes active,

even if the clock is not running.

Depending on the clock selection fuse settings, PB6 can be used as input to the inverting Oscil-

lator amplifier and input to the internal clock operating circuit.

Depending on the clock selection fuse settings, PB7 can be used as output from the inverting

Oscillator amplifier.

If the Internal Calibrated RC Oscillator is used as chip clock source, PB7:6 is used as TOSC2:1

input for the Asynchronous Timer/Counter2 if the AS2 bit in ASSR is set.

The various special features of Port B are elaborated in

”Alternate Functions of Port B” on page

and

”System Clock and Clock Options” on page 27.

1.1.4

Port C (PC5:0)

Port C is a 7-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The

PC5:0 output buffers have symmetrical drive characteristics with both high sink and source

capability. As inputs, Port C pins that are externally pulled low will source current if the pull-up

resistors are activated. The Port C pins are tri-stated when a reset condition becomes active,

even if the clock is not running.

1.1.5

PC6/RESET

If the RSTDISBL Fuse is programmed, PC6 is used as an I/O pin. Note that the electrical char-

acteristics of PC6 differ from those of the other pins of Port C.

If the RSTDISBL Fuse is unprogrammed, PC6 is used as a Reset input. A low level on this pin

for longer than the minimum pulse length will generate a Reset, even if the clock is not running.

The minimum pulse length is given in

Table 29-3 on page 314.

Shorter pulses are not guaran-

teed to generate a Reset.

The various special features of Port C are elaborated in

”Alternate Functions of Port C” on page

83.

1.1.6

Port D (PD7:0)

Port D is an 8-bit bi-directional I/O port with internal pull-up resistors (selected for each bit). The

Port D output buffers have symmetrical drive characteristics with both high sink and source

capability. As inputs, Port D pins that are externally pulled low will source current if the pull-up

resistors are activated. The Port D pins are tri-stated when a reset condition becomes active,

even if the clock is not running.

8025M–AVR–6/11
