Conductors: 30 AWG 7 X 38 [ 7 X 0.102 ] Tinned Stranded Copper
Marking:
Material: Polyvinyl Chloride (PVC)
Color: Gray
Electrical
Voltage Rating:
USA: 30V
Insulation Resistance:
>1 x 10
10
Ω
/10 ft [3 m]
Characteristic Impedance:
Unbalanced
73
Ω
Capacitance:
20.8 pF/ft (68.2 pF/m)
Inductance:
.11 μH/ft (0.36 μH/m)
EU: <50V
Balanced
122
Ω
12.0 pF/ft (39.4 pF/m)
1.45 ns/ft (4.76 ns/m)
Propagation Delay:
1.51 ns/ft (4.95 ns/m)
Velocity of Propagation:
67%
.18 μH/ft (0.59 μH/m)
70%
Note: Unbalanced is measured between ground-signal-ground conductors. Balanced is measured between signal conductors within a pair.
Environmental
Temperature Rating:
-20°C to +105°C
Flammability Rating:
USA:VW-1
UL File No.: E42769, Style No.: 20596
3
Electronic Solutions Division
Interconnect Solutions
http://www.3Mconnectors.com
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
3M
™
Round Conductor Flat Cable
.025" 30 AWG Stranded, PVC
Number of
Conductors
10
12
14
16
Inch
[mm]
Tolerance Unless Noted
.0
Inch
±.1
.00
±.01
.000
±.005
20
26
30
32
34
36
40
50
52
60
68
80
100
3M Part
Number
3754/10
3754/12
3754/14
3754/16
3754/20
3754/26
3754/30
3754/32
3754/34
3754/36
3754/40
3754/50
3754/52
3754/60
3754/68
3754/80
3754/100
Dimension A
0.250 ± .006 [ 6.350 ]
0.300 ± .006 [7.62]
0.350 ± .006 [8.89]
0.400 ± .006 [10.16]
0.500 ± .006 [ 12.70 ]
0.650 ± .006 [ 16.51 ]
0.750 ± .006 [ 19.05 ]
0.800 ± .008 [ 20.32 ]
0.850 ± .009 [ 21.59 ]
0.900 ± .009 [ 22.86 ]
1.000 ± .009 [ 25.40 ]
1.250 ± .009 [ 31.75 ]
1.300 ± .009 [ 33.02 ]
1.500 ± .012 [ 38.10 ]
1.700 ± .012 [ 43.18 ]
2.000 ± .015 [ 50.80 ]
2.500 ± .015 [ 63.50 ]
A
B
.013
±
.005
[ 0.33 ]
.025
±
.002 Typ
[ 0.64 ]
3754 Series
Dimension B
0.225 ± .004 [5.72 ]
0.275 ± .004 [6.99]
0.325 ± .004 [8.26]
0.375 ± .004 [9.53]
0.475 ± .004 [ 12.07 ]
0.625 ± .004 [ 15.88 ]
0.725 ± .006 [ 18.42 ]
0.775 ± .006 [ 19.69 ]
0.825 ± .006 [ 20.96 ]
0.875 ± .006 [ 22.23 ]
0.975 ± .006 [ 24.77 ]
1.225 ± .006 [ 31.12 ]
1.275 ± .006 [ 32.39 ]
1.475 ± .009 [ 37.47 ]
1.675 ± .009 [ 42.55 ]
1.975 ± .011 [ 50.17 ]
2.475 ± .012 [ 62.87 ]
[ ] Dimensions for Reference Only
.025
±
.003
[ 0.64 ]
30 AWG 7 X 38 ( 7 X 0.102 ) Tinned
Stranded Copper Conductors
PVC Insulation
Note: Red marking on one edge of cable designates wire #1.
Ordering Information
3754/XX
Number of Conductors
(See Table)
Note: Available in standard 100 ft or 300 ft rolls, please specify
when ordering. Contact 3M for availability of additional conductor
counts and/or custom roll lengths.
TS-0875-E
Sheet 2 of 3
3
Electronic Solutions Division
Interconnect Solutions
http://www.3Mconnectors.com
3M is a trademark of 3M Company.
For technical, sales or ordering information call
800-225-5373
Important Notice
All statements, technical information, and recommendations related to 3M’s products are based on information believed to be reliable, but the accuracy or completeness
is not guaranteed. Before using this product, you must evaluate it and determine if it is suitable for your intended application. You assume all risks and liability associated
with such use. Any statements related to the product which are not contained in 3M’s current publications, or any contrary statements contained on your purchase order
shall have no force or effect unless expressly agreed upon, in writing, by an authorized officer of 3M.
Warranty; Limited Remedy; Limited Liability.
This product will be free from defects in material and manufacture for a period of one (1) year from the time of purchase.
3M MAKES NO OTHER WARRANTIES
INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
If this product is defective within the
warranty period stated above, your exclusive remedy shall be, at 3M’s option, to replace or repair the 3M product or refund the purchase price of the 3M product.
Except
where prohibited by law, 3M will not be liable for any indirect, special, incidental or consequential loss or damage arising from this 3M product, regardless of
