PIC24F08KA102T-I/SS datasheet, PDF

PIC24F08KA102T-I/SS: Description16-bit microcontrollers - mcu 8kb flash 1kb ram 512b eeprom 16mips; CategoryThe embedded processor and controller Microcontrollers and processors; File Size2MB，255 Pages; ManufacturerMicrochip; Websitehttps://www.microchip.com; Environmental Compliance

Download Datasheet Parametric View All

PIC24F08KA102T-I/SS Overview

16-bit microcontrollers - mcu 8kb flash 1kb ram 512b eeprom 16mips

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Microchip
Parts packaging code	SSOP
package instruction	5.30 MM, LEAD FREE, PLASTIC, SSOP-28
Contacts	28
Reach Compliance Code	compli
ECCN code	3A991.A.2
Has ADC	YES
Other features	ITS ALSO OPERATES MINIMUM 1.8V AT 8 MHZ
Address bus width
bit size	16
CPU series	PIC
maximum clock frequency	32 MHz
DAC channel	NO
DMA channel	NO
External data bus width
JESD-30 code	R-PDSO-G28
JESD-609 code	e3
length	10.2 mm
Humidity sensitivity level	1
Number of I/O lines	24
Number of terminals	28
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	SSOP
Encapsulate equivalent code	SSOP28,.3
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	260
power supply	2/3.3 V
Certification status	Not Qualified
RAM (bytes)	1536
rom(word)	2048
ROM programmability	FLASH
Maximum seat height	2 mm
speed	32 MHz
Maximum slew rate	18 mA
Maximum supply voltage	3.6 V
Minimum supply voltage	3 V
Nominal supply voltage	3.3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Matte Tin (Sn)
Terminal form	GULL WING
Terminal pitch	0.65 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	40
width	5.3 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER

PIC24F16KA102 Family

Data Sheet

20/28-Pin General Purpose,

16-Bit Flash Microcontrollers

with nanoWatt XLP™ Technology

2009 Microchip Technology Inc.

Preliminary

DS39927B
