HI-546, HI-547, HI-548, HI-549
Data Sheet
September 21, 2005
FN3150.5
Single 16 and 8, Differential 8-Channel
and 4-Channel CMOS Analog MUXs with
Active Overvoltage Protection
The HI-546, HI-547, HI-548 and HI-549 are analog
multiplexers with active overvoltage protection and
guaranteed r
ON
matching. Analog input levels may greatly
exceed either power supply without damaging the device or
disturbing the signal path of other channels. Active
protection circuitry assures that signal fidelity is maintained
even under fault conditions that would destroy other
multiplexers.
Analog inputs can withstand constant 70V
P-P
levels with
±15V
supplies. Digital inputs will also sustain continuous
faults up to 4V greater than either supply. In addition, signal
sources are protected from short circuiting should
multiplexer supply loss occur. Each input presents 1kΩ of
resistance under this condition. These features make the
HI-546, HI-547, HI-548 and HI-549 ideal for use in systems
where the analog inputs originate from external equipment
or separately powered circuitry. All devices are fabricated
with 44V Dielectrically Isolated CMOS technology. The
HI-546 is a single 16-Channel, the HI-547 is an 8-Channel
differential, the HI-548 is a single 8-Channel and the HI-549
is a 4-Channel differential device. If input overvoltage
protection is not needed the HI-506/507/508/509
multiplexers are recommended. For further information see
Application Notes AN520 and AN521.
For MIL-STD-883 compliant parts, request the HI-546/883,
HI-547/883, HI-548/883 and HI-549/883 datasheets.
Features
• Analog Overvoltage Protection. . . . . . . . . . . . . . . . . . 70V
P-P
• No Channel Interaction During Overvoltage
• Guaranteed r
ON
Matching
• Maximum Power Supply. . . . . . . . . . . . . . . . . . . . . . . 44V
• Break-Before-Make Switching
• Analog Signal Range . . . . . . . . . . . . . . . . . . . . . . . .
±15V
• Access Time (Typical) . . . . . . . . . . . . . . . . . . . . . . . 500ns
• Standby Power (Typical). . . . . . . . . . . . . . . . . . . . . 7.5mW
•
Pb-Free Plus Anneal Available (RoHS Compliant)
Applications
• Data Acquisition
• Industrial Controls
• Telemetry
1
CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.
1-888-INTERSIL or 321-724-7143
|
Intersil (and design) is a registered trademark of Intersil Americas Inc.
Copyright © Intersil Americas Inc. 2003, 2005. All Rights Reserved
All other trademarks mentioned are the property of their respective owners.
HI-546, HI-547, HI-548, HI-549
Ordering Information
PART
NUMBER
HI1-0546-5
HI1-0546-2
HI3-0546-5
HI4P0546-5
HI4P0546-5Z
(Note)
HI9P0546-9**
PART
MARKING
HI1-546-5
HI1-546-2
HI3-546-5
HI4P546-5
HI4P546-5Z
HI9P546-9
TEMP.
RANGE
(
o
C)
0 to 75
PACKAGE
PKG.
DWG. #
Ordering Information
(Continued)
PART
NUMBER
HI9P0548-5**
PART
MARKING
HI9P548-5
TEMP.
RANGE
(
o
C)
0 to 75
0 to 75
-40 to 85
-40 to 85
PACKAGE
16 Ld SOIC
16 Ld SOIC
(Pb-free)
16 Ld SOIC
16 Ld SOIC
(Pb-free)
PKG.
DWG. #
M16.15
M16.15
M16.15
M16.15
28 Ld CERDIP F28.6
-55 to 125 28 Ld CERDIP F28.6
0 to 75
0 to 75
0 to 75
-40 to 85
-40 to 85
0 to 75
0 to 75
0 to 75
0 to 75
0 to 75
-40 to 85
-40 to 85
28 Ld PDIP
28 Ld PLCC
28 Ld PLCC
(Pb-free)
28 Ld SOIC
28 Ld SOIC
(Pb-free)
E28.6
HI9P0548-5Z** HI9P548-5Z
(Note)
HI9P0548-9
HI9P548-9
HI9P548-9Z
HI1-549-2
HI3-549-5
HI4P549-5
HI4P549-5Z
HI9P549-9
HI9P549-9Z
N28.45
N28.45
M28.3
HI3-0549-5
0 to 75
0 to 75
0 to 75
-40 to 85
-40 to 85
16 Ld PDIP
20 Ld PLCC
20 Ld PLCC
(Pb-free)
16 Ld SOIC
16 Ld SOIC
(Pb-free)
E16.3
N20.35
N20.35
M16.15
M16.15
M28.3
HI4P0549-5
HI4P0549-5Z
(Note)
HI9P0549-9
HI9P0548-9Z
(Note)
HI1-0549-2
-55 to 125 16 Ld CERDIP F16.3
HI9P0546-9Z** HI9P546-9Z
(Note)
HI1-0547-5
HI3-0547-5
HI3-0547-5Z
(Note)
HI4P0547-5
HI4P0547-5Z
(Note)
HI9P0547-9
HI9P0547-9Z
(Note)
HI1-0548-2
HI1-0548-5
HI3-0548-5
HI4P0548-5
HI1-547-5
HI3-547-5
HI3-0547-5Z
HI4P547-5
HI4P547-5Z
HI9P547-9
HI9P547-9Z
HI1-548-2
HI1-548-5
HI3-548-5
HI4P548-5
28 Ld CERDIP F28.6
28 Ld PDIP
28 Ld PDIP*
(Pb-free)
28 Ld PLCC
28 Ld PLCC
(Pb-free)
28 Ld SOIC
28 Ld SOIC
(Pb-free)
E28.6
E28.6
HI9P0549-9Z
(Note)
N28.45
N28.45
M28.3
M28.3
*Pb-free
PDIPs can be used for through hole wave solder processing
only. They are not intended for use in Reflow solder processing
applications.
**Add “96” suffix for tape and reel.
NOTE: Intersil Pb-free plus anneal products employ special Pb-free
material sets; molding compounds/die attach materials and 100%
matte tin plate termination finish, which are RoHS compliant and
compatible with both SnPb and Pb-free soldering operations. Intersil
Pb-free products are MSL classified at Pb-free peak reflow
temperatures that meet or exceed the Pb-free requirements of
IPC/JEDEC J STD-020.
-55 to 125 16 Ld CERDIP F16.3
0 to 75
0 to 75
0 to 75
16 Ld CERDIP F16.3
16 Ld PDIP
20 Ld PLCC
E16.3
N20.35
Pinouts
HI-546 (CERDIP, PDIP, SOIC)
TOP VIEW
+V
SUPPLY
1
28 OUT
27 -V
SUPPLY
26 IN 8
25 IN 7
24 IN 6
23 IN 5
22 IN 4
21 IN 3
20 IN 2
19 IN 1
18 ENABLE
17 ADDRESS A
0
16 ADDRESS A
1
15 ADDRESS A
2
HI-547 (CERDIP, PDIP, SOIC)
TOP VIEW
+V
SUPPLY
1
28 OUT A
27 -V
SUPPLY
26 IN 8A
25 IN 7A
24 IN 6A
23 IN 5A
22 IN 4A
21 IN 3A
20 IN 2A
19 IN 1A
18 ENABLE
17 ADDRESS A
0
16 ADDRESS A
1
15 ADDRESS A
2
NC 2
NC 3
IN 16 4
IN 15 5
IN 14 6
IN 13 7
IN 12 8
IN 11 9
IN 10 10
IN 9 11
GND 12
V
REF
13
ADDRESS A
3
14
OUT B 2
NC 3
IN 8B 4
IN 7B 5
IN 6B 6
IN 5B 7
IN 4B 8
IN 3B 9
IN 2B 10
IN 1B 11
GND 12
V
REF
13
NC 14
2
