75Watts Single Output LED Driver
Q
ualtek
P
P C
Electronics Corporation
PLV-075 Series
Features:
Constant Voltage Design
Universal AC input/ Full Range
Built-in Active PFC function, PF 0.99 Typical
High Efficiency (Up to 93%)
Output Protections: OLP/OVP/SCP/OTP
Lightning Protection
Waterproof (IP67)
5 Year Warranty
Model
DC Output
Rated Current
Current Range
Ripple and Noise (max)
Voltage Accuracy
Line Regulation
Load Regulation
Rise Time
Hold-up Time (Typ.)
Note 1
PLV-075S036
PLV-075S042
PLV-075S048
PLV-075S054
PLV-075S081
PLV-075S105
Output Characteristics
36V
2.08A
0~2.08A
±2% Vo
±2% Vo
±1% Vo
±2% Vo
20mS Max @ Rated Load
10mS Min (110VAC input, full load), 20mS Min (220VAC input, full load)
90VAC~305VAC
47Hz-63Hz
>0.99
>0.95
92%
>0.99
>0.95
93%
>0.99
>0.95
93%
>0.99
>0.95
93%
>0.99
>0.95
93%
>0.99
>0.95
93%
110VAC
220VAC
42V
1.78A
0~1.78A
48V
1.56A
0~1.56A
54V
1.38A
0~1.38A
81V
0.92A
0~0.92A
105V
0.71A
0~0.71A
Input Characteristics
Voltage Range
Frequency Range
Power Factor
(Typical)
Efficiency (Typical)
AC Current (max)
Inrush Current (max)
Leakage Current
1.0A @ 100-277VAC Input Full Load
65A @ 230VAC, 25°C
0.75mA max @ 277VAC
110°C (Temperature of internal components); shut down, auto recover after the temperature decreases
1.35Vo
1.15Vo
1.15Vo
1.15Vo
1.15Vo
1.15Vo
Long-term mode, auto recovery
-35°C~70°C
10% RH to 100% RH
-40°C~85°C, 5% to 100% RH non-condensing
10 to 300Hz sweep at constant acceleration of 1.0G(Breadth: 3.5mm) for 1 Hour for each of the perpendicular axes X, Y, Z
IP67
UL8750, Compliance to UL1012 UL935, IEC61347
L/N-GND: 4kV, L-N: 2kV
I/P-O/P: >100M Ohms / 500VDC / 25°C / 70% RH
Compliance to EN55022(CISPR22) Class B, EN61000-3-2 Class A, EN61000-3-3
Compliance to EN61000-3-2, 3 EN61000-4-2, 3, 4, 5, 6, 8, 11, EN61547
More than 50,000Hrs (25°C, 80% Load)
More than 475,000Hrs (25°C, 80% Load)
210.5x67.5x37mm
1. Ripple & Noise: Measured by 20 MHz bandwidth oscilloscope and the output paralleled with a 0.1 uF ceramic capacitor and a 10 uF electrolytic capacitor.
2. Latch Mode: The power supply shall return to normal operation only after the power is turned on again
Protection
Over Temperature (OTP)
Over Voltage (OVP)
Short Circuit (SCP)
Operating Temperature
Operating Relative Humidity
Storage Temperature
Vibration
Waterproof Rating
Safety Standards
Withstand Voltage
Isolation Resistance
EMC Emission
EMC Immunity
Note 2
Environmental Characteristics
Characteristics
Life Time
MTBF (MIL-HDBK-217F)
Dimension (LxWxH)
Note
Rev. C
Page 1 of 2
