Bussmann
®
In-Line Fuseholder
For Type SFE and
⁄Ω¢∑ ≈
Various Length Fuses
HR and HM
Series
Dimensional Data:
All dimensions (±0.015)
2.19"
(55.6mm)
0.75"
(19.1mm)
0.69"
(17.5mm)
1.56"
(39.7mm)
0.38"
(9.5mm)
Catalog Symbols:
HRJ, HRI, HRH, HRE, HRG, HRF, HMJ,
HMI, HMH, HME, HMG, HMF
In-Line Fuseholders
Ampere Rating:
20 Amperes
Voltage Rating:
32 Volts AC
Temperature Rating (RTI):
140°C
Agency Approvals:
No agency listing.
Catalog
Symbol
Amps
Volts AC
Includes Fuse
Wire
HRJ*
SFE-20
__________
____________________
HRI
SFE-14
__________
____________________
HRH
SFE-9
__________
____________________
19∑ of #14
HRE
SFE-7⁄Ω
™
__________
____________________
HRG
SFE-6
__________
____________________
HRF
SFE-4
__________
__________________________________ ____
_
20
32
HMJ**
SFE-20
__________
____________________
HMI
SFE-14
__________
____________________
HMH
SFE-9
__________
____________________
8∑ of #14
HME
SFE-7⁄Ω
™
__________
____________________
HMG
SFE-6
__________
____________________
HMF
SFE-4
*Also available as in-line fuseholder only with lead wire contacts,
HRJ-Less-Fuse.
**Also available as in-line fuseholder only with lead wire contacts,
HMJ-Less-Fuse.
HDJ-A – For
⁄Ω¢∑ ≈ 1⁄Ω¢∑
fuse, no wire or fuse included, accepts #18 - #20 wire.
HDJ-B – For
⁄Ω¢∑ ≈ 1⁄Ω¢∑
fuse, no wire or fuse included, accepts #12 - #16 wire.
HDI-A – For
⁄Ω¢∑ ≈ ‡Ω•∑
fuse, no wire or fuse included, accepts #18 - #20 wire.
HDI-B – For
⁄Ω¢∑ ≈ ‡Ω•∑
fuse, no wire or fuse included, accepts #12 - #16 wire.
HAF-A – For
⁄Ω¢∑ ≈ fiΩ•∑
fuse, no wire or fuse included, accepts #18 - #20 wire.
General Information:
• Bayonet type knob.
• Maximum current rating 20 amps; voltage rating 32 volts AC.
• Holders available as complete assembly consisting of in-line
holder with 8∑ or 14∑ of #14 insulated wire and installed
fuses.
• Replacement springs – BK/1A1853.
• Replacement contacts – 9838 for #18 - #22 wire.
9841 for #12 - #16 wire.
The only controlled copy of this BIF document is the electronic read-only version located on the Bussmann Network Drive. All other copies of this document are by definition uncontrolled. This bulletin
is intended to clearly present comprehensive product data and provide technical information that will help the end user with design applications. Bussmann reserves the right, without notice, to change
design or construction of any products and to discontinue or limit distribution of any products. Bussmann also reserves the right to change or update, without notice, any technical information con-
tained in this bulletin. Once a product has been selected, it should be tested by the user in all possible applications.
12-21-98
SB98107
Rev. A
Form No. HR and HM Series
Page 1 of 1
BIF Doc #2122
