SS Series
Miniature Slide Switches
Features/Benefits
•
Broad range of products
•
Various circuit design, SPDT, 4P3T,
vertical, right angle
•
Compact miniature slide switch
•
Shorting or non-shorting
•
Custom design available
Typical Applications
•
Consumer electronics
•
Computer peripherals
•
Telecommunication
•
Audio & visual equipment
•
Medical
•
Automotive
SS-12D1305-G 2
1P2T NON-SHORTING
I
Slide
9
3.6
Specifications
CONTACT RATING: 0.3A @ 6 VDC
INITIAL CONTACT RESISTANCE: 70 m ohms max.
INSULATION RESISTANCE: 100 M ohms min.
2 TRAVEL
A
B
1.5
3.6
1.5
DIELECTRIC STRENGTH: 500 V AC (50-60 Hz) between open
terminals and between the frame and terminal.
OPERATING LIFE: 10,000 cycles with load
OPERATING FORCE: 200 ± 100 gf (1.96 ± 0.98N)
TRAVEL: 2 ± 0.3 mm
OPERATING TEMPERATURE: -20˚C to 70˚C
3.5
2
Materials
3
0.5
2.5
2.5
3.3
0.3
KNOB: PA
COVER: SUS
HOUSING: PA
CONTACT: Silver clad
TERMINAL: Silver plated
2.5
1P - 2T
1
2
2.5
Ø0.8
TYP.3
SCHEMATIC
PIERCING PLAN
3.3
Dimensions are shown: mm
Specifications and dimensions subject to change
I–97
www.ck-components.com
SS Series
Miniature Slide Switches
SS-12D1505-G
9
3.6
1P2T NON-SHORTING
Specifications
CONTACT RATING: 0.3A @ 6 VDC
INITIAL CONTACT RESISTANCE: 70 m ohms max.
INSULATION RESISTANCE: 100 M ohms min.
2 TRAVEL
3.6
1.5
DIELECTRIC STRENGTH: 500 V AC (50-60 Hz) between open
terminals and between the frame and terminal.
OPERATING LIFE: 10,000 cycles with load
OPERATING FORCE: 200 ± 100 gf (1.96 ± 0.98N)
TRAVEL: 2 ± 0.3 mm
OPERATING TEMPERATURE: -20˚C to 80˚C
G=
G
1.5
I
Slide
3.5
1.2
0.5
2.5
2.5
3.3
0.3
Materials
KNOB: PA
COVER: SUS
HOUSING: PA
1P - 2T
2.5
1
2
2.5
CONTACT: Silver clad
TERMINAL: Silver plated
Ø0.8
TYP.3
SCHEMATIC
PIERCING PLAN
DPDT NON-SHORTING
9
3.6
SS-22D0205-G
3.3
Specifications
CONTACT RATING: 0.3A @ 6 VDC
INITIAL CONTACT RESISTANCE: 70 m ohms max.
INSULATION RESISTANCE: 100 M ohms min.
2 TRAVEL
1.5
3.60
1.5
DIELECTRIC STRENGTH: 500 V AC (50-60 Hz) between open
terminals and between the frame and terminal.
OPERATING LIFE: 10,000 cycles with load
OPERATING FORCE: 200 ± 100 gf (1.96 ± 0.98N)
TRAVEL: 2 ± 0.3 mm
OPERATING TEMPERATURE: -20˚C to 80˚C
G=
G
3.50
Materials
0.5
2.5
2.5
3.30
0.3
3
KNOB: PA
COVER: SUS
HOUSING: PA
CONTACT: Silver clad
2P - 2T
1
2
2.5
2.5
TERMINAL: Silver plated
Ø0.8
SCHEMATIC
TYP.6
PIERCING PLAN
3.3
Dimensions are shown: mm
Specifications and dimensions subject to change
I–98
www.ck-components.com
SS Series
Miniature Slide Switches
SS-22D0205-G 2 -LT
9
3.6
DPDT NON-SHORTING
Specifications
CONTACT RATING: 0.3A @ 6 VDC
INITIAL CONTACT RESISTANCE: 70 m ohms max.
INSULATION RESISTANCE: 100 M ohms min.
DIELECTRIC STRENGTH: 500 V AC (50-60 Hz) between open
terminals and between the frame and terminal.
2 TRAVEL
3.6
1.5
1.5
OPERATING LIFE: 10,000 cycles with load
OPERATING FORCE: 200 ± 100 gf (1.96 ± 0.98N)
TRAVEL: 2 ± 0.3 mm
OPERATING TEMPERATURE: -20˚C to 70˚C
3.5
Materials
KNOB: PA
7.5
0.3
I
Slide
2
0.5
2.5
2.5
2P - 2T
5
6-3X0.8
LAND
1
2
COVER: SUS
HOUSING: PA
CONTACT: Silver clad
TERMINAL: Silver plated
7
PIERCING PLAN
SCHEMATIC
2.2
TYP.6
Ø2.8
Ø24.8
Ø13.4
Ø2.2
1.75
4 4
Ø1.5
0.4
7.5
16
TOTAL 900PCS PER REEL
12
6.1
Ø95
Ø290
Ø330
16.5
2
P
Ø75
Dimensions are shown: mm
Specifications and dimensions subject to change
I–99
www.ck-components.com
SS Series
Miniature Slide Switches
SS-23D31-G 1.5 NS
13
2P3T NON-SHORTING
Specifications
CONTACT RATING: 0.3A @ 6 VDC
INITIAL CONTACT RESISTANCE: 70 m ohms max.
INSULATION RESISTANCE: 100 M ohms min.
TRAVEL
1.5
1.5
1.5
3.6
A
2
B
2
C
DIELECTRIC STRENGTH: 500 V AC (50-60 Hz) between open
terminals and between the frame and terminal.
OPERATING LIFE: 10,000 cycles with load
OPERATING FORCE: 200 ± 100 gf (1.96 ± 0.98N)
250 ± 100 gf (2.47 ± 0.98N)
TRAVEL: 2 ± 0.3 mm
0.3
I
Slide
2
4
2
1.5
0.6
3.5
OPERATING TEMPERATURE: -20˚C to 70˚C
2
2
2P - 3T
1
2
3
2
2
Materials
KNOB: PA
COVER: SUS
HOUSING: PA
3.3
CONTACT: Silver clad
TERMINAL: Silver plated
8-Ø0.8
SCHEMATIC
PIERCING PLAN
SS-12D01-G E NS
8.6
1P2T NON-SHORTING
Specifications
CONTACT RATING: 0.3A @ 30 VDC
INITIAL CONTACT RESISTANCE: 30 m ohms max.
INSULATION RESISTANCE: 100 M ohms min.
2
1.5
0.2x45°
TRAVEL
3.5
DIELECTRIC STRENGTH: 500 V AC (50-60 Hz) between open
terminals and between the frame and terminal.
1.5
G=
OPERATING LIFE: 10,000 cycles with load
OPERATING FORCE: 200 ± 100 gf (1.96 ± 0.98N)
0.2x45°
FREE
G
TRAVEL: 2 ± 0.3 mm
OPERATING TEMPERATURE: -20˚C to 70˚C
COMAX
5.5
3.5
Materials
KNOB: POM
COVER: SUS
0.3
0.5
2
8.3
8.3
1P - 2T
1
2
2
2
2
0.5
0.3
0.8
2
FRAME: SPTE
CONTACT: Silver clad
TERMINAL: Silver plated
2-Ø1.1
SCHEMATIC
PIERCING PLAN
3-Ø0.8
Dimensions are shown: mm
Specifications and dimensions subject to change
I–100
www.ck-components.com
SS Series
Miniature Slide Switches
SS-12D05-G E NS
8.6
1P2T NON-SHORTING
Specifications
CONTACT RATING: 0.3A @ 30 VDC
INITIAL CONTACT RESISTANCE: 30 m ohms max.
INSULATION RESISTANCE: 100 M ohms min.
3.5
2
G=
1.5
TRAVEL
1.5
DIELECTRIC STRENGTH: 500 V AC (50-60 Hz) between open
terminals and between the frame and terminal.
OPERATING LIFE: 10,000 cycles with load
0.2x45°
FREE
0.2x45°
OPERATING FORCE: 200 ± 100 gf (1.96 ± 0.98N)
TRAVEL: 2 ± 0.3 mm
OPERATING TEMPERATURE: -20˚C to 70˚C
G
3.5
COMAX
I
Slide
Materials
1.8
KNOB: POM
FRAME: SPTE
CONTACT: Silver clad
TERMINAL: Silver plated
0.5
2
8.3
2
0.3
0.3
1P - 2T
1
2
2
2
3-Ø0.8
SCHEMATIC
PIERCING PLAN
SS-12D06-G E NS
8.6
1P2T NON-SHORTING
Specifications
CONTACT RATING: 0.3A @ 30 VDC
INITIAL CONTACT RESISTANCE: 30 m ohms max.
INSULATION RESISTANCE: 100 M ohms min.
2
1.5
0.2x45°
TRAVEL
3.5
DIELECTRIC STRENGTH: 500 V AC (50-60 Hz) between open
terminals and between the frame and terminal.
OPERATING LIFE: 10,000 cycles with load
1.5
G=
OPERATING FORCE: 200 ± 100 gf (1.96 ± 0.98N)
TRAVEL: 2 ± 0.3 mm
0.2x45°
FREE
G
OPERATING TEMPERATURE: -20˚C to 70˚C
COMAX
3.5
Materials
KNOB: POM
FRAME: SPTE
2.5
0.5
2
8.3
2
0.3
0.3
CONTACT: Silver clad
TERMINAL: Silver plated
2
1P - 2T
1
2
2
3-Ø0.8
SCHEMATIC
PIERCING PLAN
Dimensions are shown: mm
Specifications and dimensions subject to change
I–101
www.ck-components.com
