SS52~SS510(SK 52~SK 510) SMB
Schottky rectifier
Major Ratings and Characteristics
I
F(AV)
5.0 A
20 V to 100 V
V
RRM
150 A
I
FSM
0.50V,0.55 V , 0.70 V, 0.85V
V
F
T
j
max.
125 °C
Features
Low profile package
Ideal for automated placement
Ultrafast reverse recovery time
Low power losses, high efficiency
Low forward voltage drop
High surge capability
High temperature soldering
260 /10 seconds at terminals
Component in accordance to
RoHS 2002/95/1 and WEEE 2002/96/EC
Mechanical Date
Case:
JEDEC DO-214AA molded plastic
body over passivated chip
Terminals:
Solder plated, solderable per
J-STD-002B and JESD22-B102D
Polarity:
Laser band denotes cathode end
Maximum Ratings & Thermal Characteristics & Electrical Characteristics
(T
A
= 25 °C unless otherwise noted)
Symbol
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak forward surge current 8.3 ms single half sine-
wave superimposed on rated load
Maximum instantaneous forward voltage at 5.0A
Maximum DC reverse current
at Rated DC blocking voltage
T
A
= 25
T
A
= 100
V
RRM
V
RMS
V
DC
I
F(AV)
I
FSM
V
F
I
R
R
JL
SS52
SK 52
20
14
20
SS53
SK 53
30
21
30
SS54
SK 54
40
28
40
SS55
SK 55
50
35
50
5
150
SS56
SK 56
60
42
60
SS58
SK 58
80
56
80
SS510
UNIT
SK 510
100
70
100
V
V
V
A
A
0.85
20
V
mA
/W
0.50
0.55
10
0.70
0.5
25
–65 to +125
Thermal resistance from junction to Lead
Operating junction and storage temperature range
T
J
, T
STG
Note:Thermal resistance from junction to ambient and from junction to lead mounted on P.C.B. with 0.3 x 0.3" (8.0 x 8.0 mm) copper pad areas
