ZSLS7031
Isolated and Non-isolated Flyback LED Driver with Active PFC
Circuit Block Diagram
Typical Applications
LED bulb lamps
LED tube lamps
General LED lighting
Ordering Information
Ordering Code
ZSLS7031ZI1R
ZSLS7031KIT-D1
Description
ZSLS7031 Flyback LED Driver IC, MSOP-8
ZSLS7031PCB-D1 Evaluation Board, 5 ZSLS7031 ICs
Package
Tape on Reel
Kit
