Part Number
GDB-32mA
GDB-40mA
GDB-50mA
GDB-63mA
GDB-80mA
GDB-100mA
GDB-125mA
GDB-160mA
GDB-200mA
GDB-250mA
GDB-315mA
GDB-400mA
GDB-500mA
GDB-630mA
GDB-800mA
GDB-1A
GDB-1.25A
GDB-1.6A
GDB-2A
GDB-2.5A
GDB-3.15A
GDB-4A
GDB-5A
GDB-6.3A
GDB-8A
GDB-10A
Voltage
Rating
Vac
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
250
Interrupting Rating (amps)
at Rated Voltage (50Hz)
Vac
35
35
35
35
35
35
35
35
35
35
35
35
35
35
35
35
35
35
35
35
35
40
50
63
80
100
Specifications
Typical DC
Cold Resistance
(Ω)*
40
25
17
12.5
5.0
3.8
2.8
9.1
6.8
4.3
3.1
2.0
0.26
0.20
0.14
0.125
0.096
0.066
0.043
0.034
0.025
0.021
0.014
0.010
0.010
0.008
Typical
Melting I
2
t
AC†
0.000047
0.00011
0.00020
0.00057
0.0012
0.003
0.005
0.008
0.016
0.28
0.58
0.18
0.18
0.35
0.67
0.60
0.84
1.6
4.2
6.1
13
22
42
69
N/A
N/A
Maximum
Agency Approval
Voltage
Drop (mV)‡
UR
VDE
3200
2500
2400
2000
1200
1100
1000
2000
X
X
1700
X
X
1400
X
X
1300
X
X
1100
X
X
220
X
X
220
X
X
190
X
X
200
X
X
200
X
X
190
X
X
150
X
X
150
X
X
130
X
X
130
X
X
120
X
X
120
X
X
120
X
X
120
X
X
* DC Cold Resistance (Measured at <10% of rated current)
† Typical Melting I
2
t (I
2
t was measured at listed interrupting rating and rated voltage)
‡ Maximum Voltage Drop (Voltage drop was measured at 20°C ambient temperature at rated current)
0209
BU-SB08762
Page 1 of 2
Data Sheet 2015
