Non resettable fuses
www.schurter.com/PG01_2
Surface Mount Fuse, 3.2 x 1.6 mm, Quick-Acting F, 32 VAC, 63 VDC
USI 1206
IEC 60127-4 · 32 VAC · 63 VDC · Quick-Acting F
Description
Standards
- IEC characteristic
- High melting I²t-values
- IEC 60127-4/2
- UL 248-14
- CSA C22.2 no. 248.14
Applications
- Secondary Protection DC and AC
- Circuits with inrush
- Industrial electronic
References
Weblinks
Packaging Details
pdf-datasheet, html-datasheet, General Product Information, Approvals,
CE declaration of conformity, RoHS, CHINA-RoHS, REACH, e-Shop,
SCHURTER-Stock-Check, Distributor-Stock-Check, Detailed request for
product
Approvals
- VDE Certificate Number: 40017666
- UL File Number: E41599
Technical Data
Rated Voltage
Rated current
Breaking Capacity
Characteristic
Mounting
Admissible Ambient Air Temp.
Climatic Category
Material: Housing
Material: Terminals
Unit Weight
Storage Conditions
Product Marking
32 VAC, 63 VDC
0.5 - 6.3 A
63 A
Quick-Acting F
PCB,SMT
-55 °C to 90 °C
55/090/21 acc. to IEC 60068-1
Epoxyd Glass
Copper, Ni/Au-plated
0.006 g
0 °C to 60 °C, max. 70% r.h.
Letter (see variants)
Soldering Methods
Solderability
Resistance to Soldering Heat
Moisture Resistance Test
Terminal Strength
Case Resistance
Resistance to Solvents
Flammability
Reflow, Wave (0.5 A variant only)
250 °C / 3 sec acc. to IEC 60068-2-58,
Test Td
260 +0/-5 °C / 30 sec acc. to IPC/JE-
DEC J-STD-020D, Level 1
MIL-STD-202, Method 106E
(50 cycles in a temp./mister chamber)
MIL-STD-202, Method 211A
(Deflection of board 1 mm for 1 minute)
acc. to EIA/IS-722, Test 4.7
>100 MΩ (between leeds and body)
MIL-STD-202, Method 215A
UL 94V-1
(acc. to EIA/IS-722, Test 4.12)
Dimension
3.2 mm
3.2
0.6
1.6
2.2
Fuses
1
Non resettable fuses
www.schurter.com/PG01_2
USI 1206
Marking
Breaking
Capacity
Voltage Drop
1.0 In max.
[mV]
600
500
400
300
300
300
300
300
300
300
300
300
Voltage Drop
1.0 In typ.
[mV]
201
170
110
108
96.3
94.5
80.2
78.8
65.5
62.8
61.6
55.3
Cold Resi-
stance typ.
[mΩ]
330
230
116
94.2
67
50.5
33.9
25.3
17.2
12.5
9.6
7.1
Melting I²t
10.0 Intyp.
[A²s]
0.041
0.076
0.18
0.2
0.31
0.33
0.79
0.94
1.44
2.74
4.65
4.84
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
l
Order Number
All Variants
Rated Cur-
rent [A]
Rated Vol-
tage [VAC]
Rated Vol-
tage [VDC]
0.5
0.63
0.8
1
1.25
1.6
2
2.5
3.15
4
5
6.3
█
Most Popular.
32
32
32
32
32
32
32
32
32
32
32
32
63
63
63
63
63
63
63
63
63
63
63
63
e
f
g
h
i
k
m
n
p
r
s
t
1)
1)
1)
1)
1)
1)
1)
1)
1)
1)
1)
1)
3413.0213.xx
3413.0214.xx
3413.0215.xx
3413.0216.xx
3413.0217.xx
3413.0218.xx
3413.0219.xx
3413.0220.xx
3413.0221.xx
3413.0222.xx
3413.0223.xx
3413.0224.xx
█
█
█
█
█
█
Availability for all products can be searched real-time:http://www.schurter.com/en/Stock-Check/Stock-Check-SCHURTER
1) UL: 63 A @ 32 VAC, 63 A @ 63 VDC
1) Additional internal testing: 150 A @ 24 VAC/DC, 400 A @ 12 VDC, 600 A @ 9 VDC
Packaging Unit
.xx = .11
.xx = .22
.xx = .24
.xx = .26
Blister Tape (100 pcs.)
Blister Tape 18 cm Reel (1000 pcs.)
Blister Tape 25.4 cm Reel (5000 pcs.)
Blister Tape 33 cm Reel (15000 pcs.)
The specifications, descriptions and illustrations indicated in this document are based on current
information. All content is subject to modifications and amendments. Information furnished is believed
to be accurate and reliable. However, users should independently evaluate the suitability and test each
product selected for their own applications.
Fuses
3
22.07.2014
