CX3HSM CRYSTAL
18 kHz to 600 kHz
Low Profile Surface Mount
Quartz Crystal for Series Oscillators
DESCRIPTION
The CX3HSM quartz crystals are leadless devices
designed for surface mounting on printed circuit boards
or hybrid substrates. These miniature crystals are
intended to be used in Series oscillators. They are
hermetically sealed in a rugged, miniature ceramic
package. They are manufactured using the STATEK-
developed photolithographic process, and were designed
utilizing the experience acquired by producing millions of
crystals for industrial, commercial, military and medical
applications. Maximum process temperature should not
exceed 260
O
C.
FEATURES
actual size
Glass Lid Shown
PACKAGE DIMENSIONS
D
side view
A
TOP
D
BOTTOM
Miniature tuning fork design
High shock resistance
Designed for low power applications
Compatible with hybrid or PC board packaging
Low aging
Full military testing available
Designed and manufactured in the USA
DIM
A
B
C
D
E
EQUIVALENT CIRCUIT
B
C
D
E
TYP.
inches
0.263
0.097
-
0.052
0.030
mm
6.68
2.46
-
1.32
0.76
inches
0.270
0.104
0.058
0.035
MAX.
mm
6.86
2.64
1.47
0.89
see below
C
0
1
L
1
C
1
R
1
2
DIM “C“”
MAX
SM1
SM2/SM4
SM3/SM5
GLASS LID
inches
0.053
0.055
0.058
mm
1.35
1.40
1.47
CERAMIC LID
inches
0.067
0.069
0.072
mm
1.70
1.75
1.83
R
1
Motional Resistance L
1
Motional Inductance
C
1
Motional Capacitance C
0
Shunt Capacitance
CONVENTIONAL SERIES
OSCILLATOR CIRCUIT
R
f
SUGGESTED LAND PATTERN
0.070 (1.78)
OSCILLATOR
0.110 (2.79)
CX3H XTAL
C
A
R
A
R
B
BUFFER
Contact factory for
design guidelines
inches (mm)
0.210 (5.33)
10146 - Rev E
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
SPECIFICATIONS
FIGURE 1
CX3H TYPICAL MOTIONAL RESISTANCE (R
1
)
(in 1000's)
Specifications are typical at 25
O
C unless otherwise noted.
Specifications are subject to change without notice.
Frequency Range
18 kHz to 600 kHz
Functional Mode
Tuning Fork (Flexure)
Standard Calibration Tolerance
1
(see table below)
Motional Resistance (R
1
)
See Figure 1
MAX: 18-25 kHz, 2x Typ.
25-600 kHz, 2.5x Typ.
Motional Capacitance (C
1
) Figure 2
Quality Factor (Q)
Figure 3
MIN is 0.25x Typ.
1.8 pF MAX.
Shunt Capacitance (C
0
)
Drive Level
18-24.9 kHz 0.5
µW
MAX.
25-600 kHz 1.0
µW
MAX.
Turning Point (T
0
)
2
Figure 4
Temperature Coefficient (k) -0.035 ppm/
0
C
2
Aging, first year
5 ppm MAX
3
Shock, survival
1,500 g, 0.3 ms, 1/2 sine
3
Vibration, survival
10 g RMS, 20-2,000 Hz random
Operating Temp. Range
-10
O
C to +70
O
C (Commercial)
-40
O
C to +85
O
C (Industrial)
-55
O
C to +125
O
C (Military)
Storage Temp. Range
-55
O
C to +125
O
C
Max Process Temperature 260
O
C for 20 sec.
1. Other calibration values available, consult factory.
2. Other turning point available.
3. Higher shock and vibration available.
1000
500
200
100
50
20
10
18
50
100
200
600
R
1
(k
)
Frequency (kHz)
FIGURE 2
CX3H TYPICAL MOTIONAL CAPACITANCE (C
1
)
5
C
1
(fF)
2
1.0
0.5
18
50
Frequency (kHz)
100
200
600
FIGURE 3
CX3H TYPICAL QUALITY FACTOR (Q)
50
20
10
5
2
CX3H Standard Calibration T
olerance at 25
O
C
18
50
Frequency Range (kHz)
18-74.9
30 ppm
(0.003%)
+
_
+
_
Frequency (kHz)
100
200
600
75-169.9
50 ppm
(0.005%)
+
_
+
_
170-249.9
+
_
250-600
+
_
FIGURE 4
CX3H TYPICAL TURNING POINT TEMP (T
0
)
.
100 ppm
(0.01%)
200 ppm
(0.02%)
200 ppm
(0.02%)
+
_
1000 ppm
(0.1%)
+
_
1000 ppm
(0.1%)
+
_
2000 ppm
(0.2%)
+
_
5000 ppm
(0.5%)
PACKAGING OPTIONS
T
O
( C)
O
100 ppm
(0.01%)
100 ppm
(0.01%)
+
_
+
_
500 ppm
(0.05%)
+80
+70
+60
+50
+40
+30
+20
+10
0
-10
-20
CX3HSM - Tray Pack
- Tape and Reel
(Reference tape and reel data sheet 10109)
HOW TO ORDER CX3HSM CRYSTALS
CX3H
S
C
SM1
32.0K
Frequency
K = kHz
18
50
Frequency (kHz)
100
200
600
Note: Frequency f at temperature T is related to frequency f
0
at
turning point temperature T
0
by:
f-f
0
=
k(T-T )
2
0
f
0
,
30
/
I
TERMINATIONS
Blank = Glass Lid
C = Ceramic Lid
“S” if special or
custom design.
Blank if Std.
SM1 = Gold Plated
SM2 = Solder Plated
SM3 = Solder Dipped
SM4 = Solder Plated (Lead Free)
SM5 = Solder Dipped (Lead Free)
Calibration Operating Temp. Range:
Tolerance C = -10
O
C to +70
O
C
@ 25
O
C
I
= -40
O
C to +85
O
C
(in ppm) M = -55
O
C to +125
O
C
S = Customer Specified
Designation
SM1
SM2
SM3
SM4
SM5
Termination
Gold Plated
Solder Plated
Solder Dipped
Solder Plated (Lead Free)
Solder Dipped (Lead Free)
10146 - Rev E
STATEK CORPORATION 512 N. MAIN ST., ORANGE, CA 92868 714-639-7810 FAX: 714-997-1256
www.statek.com
