Ternary PIN Photodiode with Pigtail
SRD 00214X
SRD 00215X
•
InGaAs/InP - PIN-photodiode
•
Designed for telecommunications applications
•
Sensitive receiver for the 2
nd
and 3
rd
optical window
•
•
•
•
•
•
•
(1300 nm and 1500 nm)
Suitable for bit rates up to 1.2 Gbit/s
Low junction and low package capacitance
Fast switching times
Low dark current
Low noise
Hermetically sealed 3-pin metal case
With optimally coupled multimode-fiber pigtail
Ordering Code
Q62702-Pxxxx
Q62702-Pxxxx
Q62702-P3059
Q62702-P3060
Connector/Flange
Pigtail, FC/PC-Multimode
connector
Pigtail with flange, FC/PC-
Multimode connector
Pigtail, DIN-Multimode
connector
Pigtail with flange, DIN-
Multimode connector
Type
SRD 00214H
SRD 00215H
SRD 00214C
SRD 00215C
Component with other connector types on request.
Maximum Ratings
Parameter
Forward current
Reverse voltage
Operating and storage temperature
Max. radiant power into the opt. port
(
V
R
= 5 V)
Soldering time (wave / dip soldering), distance
between solder point and base plate,
(≥ 2 mm, 260 °C)
Symbol
Values
10
20
−
40
…
+ 85
1
10
Unit
mA
V
°C
mW
s
I
F
V
R
T
A
T
stg
Φ
port
t
s
Semiconductor Group
1
02.95
SRD 00214x
SRD 00215x
Characteristics
All optical data refer to a coupled 10/125
µm
SM fiber at ambient temperature of 25 °C,
unless otherwise defined.
Parameter
Spectral sensitivity
λ
= 1310 nm,
V
R
= 2 V
Change in spectral sensitivity in operating
temperature range
Rise and fall time (10 % - 90 %)
R
L
= 50
Ω,
V
R
= 2 V,
λ
= 1310 nm,
Φ
port
= 100
µW
Total capacitance
V
R
= 2 V,
Φ
port
= 0,
f
= 1 MHz
Dark current
V
R
= 2 V,
T
A
= 85 °C,
Φ
port
= 0
Backreflection of optical power into optical port
Symbol
Values
0.9 (
≥
0.75)
≤
0.2
0.3 (≤ 1.0)
Unit
A/W
%/K
ns
S
λ
∆
S
λ
t
r
;
t
f
C
2
I
D
R
1 (≤ 1.5)
1 (< 50)
≤ −
20
pF
nA
dB
Semiconductor Group
2
