.079
[2.00] SOCKET, DUAL ENTRY
Specifications
.0179 [.50] + .079 [2.0] X (No of Positions)
Current Rating:
Insulator Resistance:
Contact Resistance:
Dielectric Withstanding:
Operating Temperature:
Contact Material:
Insulator Material:
Finish:
1 Amps
5000 Megohms min
20m ohm max
AC 500V
-40° ~± 105° C
Phosphor Bronze
Phosphor Bronze
Polyester, UL 94V-0
See Contact Plating
.079 [.20] X (No of Contacts/2-1)
.079 [2.0]
PIN .0197 [.50] X .0079 [.20]
R
C
R
.181 [4.6]
.044 [1.12]
Recognized under the recognized component
Program of Underwriters Laboratories, Inc.
.169 [4.3]
Products specifications are subject to be changed
without notice.
For drawings, technical data or samples,
contact E.C.S. at (714) 895-6351
A
B
.059 [1.5]
.079 [2.0]
.197 [5.0]
.032 [.80] Dia. TYP.
.039 [1.0] Dia. TYP.
Recommended P.C.B Layout
Dimensions are in inches [mm]
PART NUMBERING
94 XX S
SERIES CODE
NO. OF CONTACTS
06
to
60
A0
= 100 Contacts
M 02
0X
XX
CONTACT PLATING
Lead Free & RoHS Compliant
.000050” Nickel underplate
CONTACT
TAIL
03
= Gold Flash
80
= 10µ” Gold
85
= 15µ” Gold
90
= 30µ” Gold
70
= Tin Plated
75
= Au Flash
100µ” Tin
15
= 10µ” Au
100µ” Tin
25
= 15µ” Au
100µ” Tin
35
= 30µ” Au
100µ” Tin
PIN LENGTH
DIM “A”
DIM “B”
0 .118 [3.00]
1 .142 [3.60]
.236 [6.00]
.197 [5.00]
CONSULT FACTORY FOR CONNECTORS BUILT TO YOUR DESIGN
WWW.ECSCONN.COM
