Datasheet of 1.50 inch 8x8 Dot Matrix LED Display
LM15088C/D Series – 1.50 inch 8x8 Dot Matrix LED Display
ATTENTION
OBSERVE PRECAUTIONS
FOR HANDLING
ELECTROSTATIC
DISCHARGE
SENSITIVE
DEVICES
Features
37.90 mm (1.50 inch) matrix height
Dot size: Diameter 3.70 mm
Pitch: 4.75 mm
Wide viewing angle
Range of emitted colors
I.C. compatible
Low power consumption
White dot, grey or black face
RoHS compliant
Available options
Alternative emitting luminosity:
Standard or high brightness version
Alternative emitted color
Alternative dot color
Alternative face color
Both CA or CC versions are available
Cropped terminal pins
Package Dimensions
COL.
1
2
3
4
5
6
7
8
ROW
1
2
4.76*7=33.32
3
37.90
4
5
6
7
8
PIN 1
4.76*7=33.32
37.90
10.30
4.50 0.50
70
3.
0.51
28.40
2.54*7=17.78
Notes:
1. All dimensions are in millimeters (inches), Tolerance is + 0.25mm (0.01inch) unless other wise noted.
2. Specifications are subject to change without notice.
3. The gap between the reflector and PCB shall not exceed 0.25mm.
SPEC NO: DS10121820
REV: A.4
CHECKED: Emily Zhou
APPROVED: M.H. Lin
PAGE: 1/3
HTTP://WWW.DISPLAY-LEDS.COM
TEL: 0086-574-86322282
DATE: Jul/20/2011
LightKey
Internal Circuit Diagram
LM15088C (Common Cathode Row)
COL. 1
PIN
NO.
13
PIN
ROW NO.
9
1
2
3
4
5
6
7
8
14
8
12
1
7
2
5
Datasheet of 1.50 inch 8x8 Dot Matrix LED Display
LM15088D (Common Anode Row)
8
16
2
3
3
4
4
10
5
6
6
11
7
15
COL. 1
PIN
NO.
13
PIN
ROW NO.
9
1
2
3
4
5
6
7
8
14
8
12
1
7
2
5
2
3
3
4
4
10
5
6
6
11
7
15
8
16
Selection Guide
Part No.
Common
Cathode Row
LM15088CR
LM15088CD
LM15088CO
LM15088CY
LM15088CG
LM15088CUR
LM15088CUO
LM15088CUA
LM15088CUY
LM15088CUG
LM15088CPG
LM15088CUB
LM15088CUW
Unit:
\
Common
Anode Row
LM15088DR
LM15088DD
LM15088DO
LM15088DY
LM15088DG
LM15088DUR
LM15088DUO
LM15088DUA
LM15088DUY
LM15088DUG
LM15088DPG
LM15088DUB
LM15088DUW
\
Material
GaAlAs
GaAlAs
GaAsP
GaAsP
GaP
AlGaInP
AlGaInP
AlGaInP
AlGaInP
AlGaInP
InGaN
InGaN
SMD
\
Chip
Color
Super Red
Hi-Red
Orange
Yellow
Green
Ultra Red
Ultra Orange
Ultra Amber
Ultra Yellow
Ultra Green
Pure Green
Ultra Blue
Ultra White
WLD
640
640
625
588
568
640
625
605
595
573
525
470
\
nm
Iv@IF=20mA
One Dot
Min.
8
18
7
8
7
30
45
30
30
30
120
30
100
mcd
Typ.
10
25
9
10
9
45
60
45
45
45
300
45
120
mcd
SPEC NO: DS10121820
REV: A.4
CHECKED: Emily Zhou
APPROVED: M.H. Lin
PAGE: 2/3
HTTP://WWW.DISPLAY-LEDS.COM
TEL: 0086-574-86322282
DATE: Jul/20/2011
LightKey
Electrical
Characteristics
Color
V
F
@
I
F
=20mA
[2]
Typ.
Super Red
Hi-Red
Orange
Yellow
Green
Ultra Red
Ultra Orange
Ultra Amber
Ultra Yellow
Ultra Green
Pure Green
Ultra Blue
Ultra White
Unit:
Notes:
1. At Ta = 25 °C.
2. Forward voltage at forward current = 20mA.
3. Peak forward current at 1/10 Duty Cycle, 0.1ms Pulse.
[1]
Datasheet of 1.50 inch 8x8 Dot Matrix LED Display
Electrical Characteristics & Absolute Maximum Ratings
Absolute Maximum Ratings
[1]
DC
Forward
Current
25
25
30
30
30
30
30
30
30
30
30
30
30
mA
Peak
Forward
Current
[3]
100
100
100
100
100
100
100
100
100
100
100
100
100
mA
Reverse
Current
VR=5V
30
30
30
30
30
30
30
30
30
30
30
30
30
uA
Power
Dissipation
60
60
80
80
80
60
65
65
65
75
110
120
120
mW
Max.
2.2
2.2
2.5
2.5
2.5
2.6
2.6
2.6
2.6
2.6
4.0
4.0
4.0
V
Per Dot
Per Dot
Per Dot
Per Dot
Per Dot
Per Dot
Per Dot
Per Dot
Per Dot
Per Dot
Per Dot
Per Dot
Per Dot
\
1.8
1.8
2.1
2.1
2.2
1.9
2.0
2.0
2.0
2.1
3.5
3.5
3.5
V
