P34TG-xxxxE/Z2:1MLF
PMD-SERIES
Rev.11-2008
8 Watt
Regulated
Single
and
Dual
Output
1.5 kV
DC I/O Isolation
DIP24 Metal
Case
Continuous Short Circuit Prot.
Full SMD Technology
Input Specifications
Voltage Range
Input Filter
Input Reflected Ripple Current¹
Output Specifications
Voltage Accuracy
Short Circuit Protection
Line Regulation
Load Regulation
(Io = 10 - 100%)
Cross Regulation³
(Dual Output)
Over Current Protection
Ripple and Noise
(20Mhz bandwidth)
Temperature Coefficient
General Specifications
Efficiency
I/O Isolation Voltage
(3 sec.)
I/O Isolation Capacity
I/O Isolation Resistance
Switching Frequency
(typical)
Humidity
Reliability Calculated MTBF
(MIL-HDBK-217F)
Physical Specifications
Case Material
Potting Material
Weight
Environment Specifications
Operating Temperature
Maximum Case Temperature
Storage Temperature
Cooling
RoHS Conform
Mainzer Straße 151–153
D-55299 Nackenheim
Tel. +49 6135 7026-0
Fax: +49 6135 931070
www.peak-electronics.de
peak@peak-electronics.de
The PMD 8W series P34TG-xxxxE/Z2:1MLF is a family of cost effective 8W
single & dual output DC-DC converters. These converters are encapsulated
in miniature DIP24 metal case. High performance features: 1500VDC
input/output isolation, continuous short circuit protection with automatic
restart and tight line / load regulation, high efficiency operation, output
voltage accuracy of ±1% maximum and a wide input of 2:1
All specifications typical at Ta=25° nominal input voltage and full load unless otherwise specified
C,
2:1 Wide Input
Pi Type
35 mA pk-pk
± 1%
Indefinite
(automatic recovery)
± 0.5%
± 0.5% (3.3 Vout Models: ± 0.7%)
± 5%
150% of FL, typ.
75 mV pk-pk
± 0.02% / °
C
See Table
1500 VDC
1000 pF, typ.
1000 MOhm
330 kHz
95% rel H
> 0.91 Mhrs
Nickel Coated Copper
Epoxy
(UL94V-0 rated)
~ 17.0g, typ.
-40 to +60°
(ambient)
C
100°
C
-40 to +125°
C
Free Air Convection
Soldering 260° max.
(1.5mm from case 10s.)
C,
PMD-Series – P34TG-xxxxE/Z2:1MLF – Single and Dual Output – DIP24 - Metal Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 1/3
Selection Guide
Single/Dual
Output
A)
A)
)
)
d (m
mA ad (mA
d (m
a
)
Lo a
ad (
C)
)
o
. Lo
(uF
(VD
Min
Full
o Lo t Full L
VDC
(
e
N
ad
²
nt
nt
)
g
t
e
o
urre
urre
olta
rren
rren
y (%
ltag
or L
ut V
ut C
ut C
acit
t Vo
t Cu put Cu
ienc
p
p
p
Cap
Inpu
Inpu
In
Out
Out
Out
Effic
Order #
SINGLE OUTPUT
P34TG-123R3E2:1MLF
P34TG-1205E2:1MLF
P34TG-1212E2:1MLF
P34TG-1215E2:1MLF
P34TG-243R3E2:1MLF
P34TG-2405E2:1MLF
P34TG-2412E2:1MLF
P34TG-2415E2:1MLF
P34TG-483R3E2:1MLF
P34TG-4805E2:1MLF
P34TG-4812E2:1MLF
P34TG-4815E2:1MLF
DUAL OUTPUT
P34TG-1205Z2:1MLF
P34TG-1212Z2:1MLF
P34TG-1215Z2:1MLF
P34TG-2405Z2:1MLF
P34TG-2412Z2:1MLF
P34TG-2415Z2:1MLF
P34TG-4805Z2:1MLF
P34TG-4812Z2:1MLF
P34TG-4815Z2:1MLF
9-18
9-18
9-18
9-18
18-36
18-36
18-36
18-36
36-72
36-72
36-72
36-72
20
20
20
20
15
15
15
15
15
15
15
15
687
762
784
803
344
381
392
397
172
191
198
198
3.3
5
12
15
3.3
5
12
15
3.3
5
12
15
0
0
0
0
0
0
0
0
0
0
0
0
2000
1500
665
535
2000
1500
665
535
2000
1500
665
535
80
82
85
83
80
82
85
84
80
82
84
84
3300
2200
470
220
3300
2200
470
220
3300
2200
470
220
9-18
9-18
9-18
18-36
18-36
18-36
36-72
36-72
36-72
20
20
20
15
15
15
15
15
15
813
794
794
407
402
392
203
196
196
±5
± 12
± 15
±5
± 12
± 15
±5
± 12
± 15
0
0
0
0
0
0
0
0
0
± 800
± 335
± 265
± 800
± 335
± 265
± 800
± 335
± 265
82
84
84
82
83
85
82
85
85
± 1000
± 220
± 100
± 1000
± 220
± 100
± 1000
± 220
± 100
If you need other specifications, please enquire.
Notes:
PMD-Series – P34TG-xxxxE/Z2:1MLF – Single and Dual Output – DIP24 - Metal Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 2/3
Package / Pinning / Derating
PIN CONNECTIONS
#
SINGLE
DUAL
2
- Vin
- Vin
3
- Vin
- Vin
9
Omitted
Common
11
N.C.
- Vout
14
+Vout
+Vout
16
- Vout
Common
22
+Vin
+Vin
23
+Vin
+Vin
others Omitted
Omitted
App Notes:
¹ =
Measured Input reflected ripple current with a simulated source inductance of 12uH.
² =
Tested by nominal Vin and constant resistor load.
³ = One load is 25% - 100%, the other load is 100%, the output voltage variable rate is within ± 5%
4
= Input filter components (C1,C2,L) are used to help meet conducted emissions requirement for the module. These
components should be mounted as close as possible to the module; all leads should be minimized to decrease radiated noise.
5
= An external filter capacitor (e.g. Nippon - chemi - con KY series, 220uF/100V) is required if the module has to meet
EN61000-4-4 and EN61000-4-5.
EMC SPECIFICATIONS
Radiated Emissions
EN 55022
4
Conducted Emissions
EN55022
ESD
IEC 61000-4-2
RS
IEC 61000-4-3
5
EFT
IEC 61000-4-4
5
Surge
IEC 61000-4-5
CS
IEC 61000-4-6
PFMF
IEC 61000-4-8
CLASS A
CLASS A
Perf. Criteria B
Perf. Criteria A
Perf. Criteria B
Perf. Criteria B
Perf. Criteria A
Perf. Criteria A
PMD-Series – P34TG-xxxxE/Z2:1MLF – Single and Dual Output – DIP24 - Metal Case
Specification can change without a notice – We accept no liability for any inaccuracy or printing errors.
Page 3/3
