RJZ-243.3SHP Overview

2 Watt DIP14 Single & Dual Output

Preview

Download Datasheet

View All

Features

Unregulated

Converters

●

2W Single and Dual Outputs in DIP 14

3kVDC and 4kVDC Isolation

Optional Continuous Short Circuit Protected

Custom Solutions Available

UL94V-0 Package Material

Efficiency up to 85%

ECONOLINE

DC/DC-Converter

RJZ

RGZ

Series

2 Watt

DIP14

Single

Dual

Output

Selection Guide

Part

Number

DIP 14

RJZ-xx3.3S

RJZ-xx05S

RJZ-xx09S

RJZ-xx12S

RJZ-xx15S

RJZ-xx24S

Input

Voltage

(VDC)

3.3,5,9,12,15,24

Output

Voltage

(VDC)

3.3

±3.3

±5

±9

±12

±15

Output

Current

(mA)

606

400

222

166

133

±303

±200

±111

±84

±66

Efficiency

(%)

70-75

78-85

78-84

80-85

82-85

80-85

75-82

75-80

78-82

80-84

82-84

4kV

(H)

RGZ-xx3.3D (H)

RGZ-xx05D

RGZ-xx09D

RGZ-xx12D

RGZ-xx15D

(H)

RGZ-xx24D (H)

3.3,5,9,12,15,24

±24

±42

xx = Input Voltage

* add Suffix “P” for Continuous Short Circuit Protection, e.g. RGZ-0524D/P,

e.g. RGZ-0524D/HP, has 4kV Isolation and is Short Circuit Protected.

EN-60950-1 Certified

EN-60601-1 Certified

Specifications

(Core Operating Area)

Input Voltage Range

Output Voltage Accuracy

Line Voltage Regulation

Load Voltage Regulation

(10% to 100% full load)

Output Ripple and Noise (20MHz limited)

Temperature Coefficient

Operating Frequency

Efficiency at Full Load

Isolation Voltage

(H-Suffix)

Rated Working Voltage

Isolation Capacitance

Isolation Resistance

Short Circuit Protection

P-Suffix

Operating Temperature Range (free air convection)

Storage Temperature Range

Relative Humidity

Package Weight

3.3V Types

5V Types

All other Types

±10%

±5%

1.2%/1% of Vin typ.

±20% max.

±15% max.

±10% max.

±150mVp-p max.

0.02%/°C max.

20kHz min./ 50kHz typ. / 90kHz max.

(tested for 1 second)

(long term isolation)

70% min. / 80% typ.

3000VDC min.

4000VDC min.

see Application Notes

Output Power (%)

100

Derating-Graph

(Ambient Temperature)

120pF max.

15GΩ min.

1 Second

Continuous

-40°C to +85°C (see Graph)

-55°C to +125°C

95% RH

2.8g

continued on next page

July-2006

Safe Operating Area

Operating Temperature °C

-40

150

www.recom-international.com
