RS2501 thru RS2507
SINGLE-PHASE SILICON
BRIDGE RECTIFIER
CHENG- YI
ELECTRONIC
VOLTAGE RANGE -50 to 1000 Volts
CURRENT 25 Amperes
FEATURES
Low leakage
Low forward voltage
Mounting position:Any
Surge overload rating:300 amperes peak
Siliver-plated copper leads
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating at 25
0
C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
MAXIMUM RATINGS
( At T
A
=25 C unless otherwise noted)
0
Ratings
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Bridge Input Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Output Current
at Tc=50
0
C
Peak Forward Surge Current, 8.3 ms single half
sine-wave superimposed on rated load
Operating and Storage Temperature Range
Maximum Forward Voltage Drop per element at 12.0A DC
Maximum Reverse Current at Rated @T
A
=25
0
C
DC Blocking Voltage per element
@T
C
=100
0
C
Symbol
V
RRM
V
RMS
V
DC
I
O
RS2501 RS2502 RS2503 RS2504 RS2505 RS2506 RS2507
50
35
50
100
75
100
200
140
200
400
280
400
25
600
420
600
800
560
800
1000
700
1000
UNITS
Volts
Volts
Volts
Amps
I
FSM
T
J
T
STG
V
F
I
R
300
-55 to +150
1.0
10
0.2
Amps
0
C
Volts
Amps
mAmps
RS2501 thru RS2507
SINGLE-PHASE SILICON BRIDGE
CHENG- YI
ELECTRONIC
RATING AND CHARACTERISTICS CURVES
RS2501 THRU RS2507
Fig. 1
-
MAXIMUM FORWARD SURGE CURRENT
PEAK FORWARD SURGE CURRENT, (A)
300
250
200
150
100
50
0
1
10
100
Fig. 2
-
DERATING CURVE FOR
AVERAGE FORWARD OUTPUT CURRENT
AMPERES
OUTPUT RECTIFIED CURRENT
40
30
20
10
0
50
100
150
NUMBER OF CYCLES AT 60 Hz
TEMPERATURE,
0
C
Fig. 3 - TYPICAL FORWARD
CHARACTERISTICS
100
Fig. 4
-
TYPICAL REVERSE
CHARACTERISTICS
10
INSTANTANEOUS FORWARD CURRENT, AMPERES
10
INSTANTANEOUS REVERSE
CURRENT, MICROAMPERES
1.0
1.0
TJ=25
0
C
0.1
0.1
.01
0
.01
.4
.6
.8
1.0
1.2
1.4
1.6
20
40
60
80
100
120
140
PERCENT OF RATED PEAK
REVERSE VOLTAGE
INSTANTANEOUS FORWARD VOLT
AGE, VOLTS
