Control and signalling units Ø 22
Harmony
®
style 5
Pushbuttons, switches and pilot lights with double
insulated bezel
Complete units, XB5 A
0
Complete units
Contact functions
Pushbuttons, spring return
Flush push
XB5 AA
/
1/AA42
see page 36012/2
XB5 AA3311/AA33
/
1
see page 36012/2
XB5 AA4322
see page 36012/2
Booted flush push
XB5 AP
/
1/AP42
see page 36012/2
Double-headed pushbuttons,
spring return
Projecting push
XB5 AL42
see page 36012/2
Mushroom head
XB5 AC21
see page 36012/2
Flush push + projecting push
XB5 AL845
see page 36012/2
Ø 40 Emergency stop
mushroom head pushbuttons
with or without trigger action
Booted flush push + projecting push
XB5 AL945
see page 36012/2
Push-pull
XB5 AT42/AT845
see page 36012/3
Selector switches
and key switches
Turn to release
XB5 AS542/AS8445
see page 36012/3
Key release
XB5 AS142/AS9445
see page 36012/3
Standard black handle
XB5 AD
see page 36012/3
Long black handle
XB5 AJ
see page 36012/3
Key switch
XB5 AG
see page 36012/3
Characteristics :
pages 36011/2 to 36011/5
References :
pages 36012/2 to 36019/3
Dimensions :
pages 36021/2 to 36021/9
2
General
(continued)
Control and signalling units Ø 22
Harmony
®
style 5
Pushbuttons, switches and pilot lights with double
insulated bezel
Complete units, XB5 A
0
Complete units
(continued)
Pilot lights
Signalling functions
With integral LED
XB5 AVB/AVG/AVM
see page 36013/2
For BA 9s bulb
Direct supply
XB5 AV
see page 36013/3
Via integral transformer
XB5 AV3/AV4
see page 36013/3
Combined functions (contact + signalling)
Illuminated pushbuttons,
spring return, flush push
With integral LED
XB5 AW3
/
B6/AW3
/
G5/AW3
/
M5
see page 36014/2
Double-headed pushbuttons,
spring return, with pilot light
For BA 9s bulb
Direct supply
XB5 AW3
/
65
see page 36014/2
Via integral transformer
XB5 AW3
/
35/AW3
/
45
see page 36014/2
With integral LED
XB5 AW84
/
5
see page 36014/3
Illuminated selector
switches, standard handle
With integral LED
XB5 AK12
/
B5/AK12
/
G5/BK12
/
M5
see page 36014/3
Characteristics :
pages 36011/2 to 36011/5
References :
pages 36012/2 to 36019/3
Dimensions :
pages 36021/2 to 36021/9
3
General
Control and signalling units Ø 22
Harmony
®
style 5
Pushbuttons, switches and pilot lights with double
insulated bezel
Sub-assemblies, ZB5 A
0
Non illuminated units
for user assembly
Contact functions
Body
sub-assemblies
Head
sub-assemblies
For pushbuttons, spring
return, without marking
Screw clamp
terminals
ZB5 AZ10
/
/AZ141
see page 36015/2
Flush push
with cap mounted or not mounted
ZB5 AA0/AA9
ZB5 AA
G
see page 36015/3
see page 36015/3
Flush push for
insertion of legend
ZB5 AA
/
8
see page 36015/3
Flush push
ZB5 CA
/
see page 36015/5
Plug-in connector
ZB5 AZ10
/
4/AZ1414
see page 36015/2
Projecting push
ZB5 AL
/
see page 36015/3
For pushbuttons,
spring return, with marking
Recessed push
ZB5 AA
G
see page 36015/3
Booted flush push
ZB5 AP
G
/AP
G
8
see page
36015/3
Projecting push
ZB5 CL
/
see page 36015/3
Flush push
ZB5 AA
/
3
/
/AA
/
4
/
see page 36015/4
For "push-turn to release”
pushbuttons
Projecting push
ZB5 AL
see page 36015/4
Flush push
ZB5 CA
/
3/CA
/
9
see page 36015/4
(1) Knob positions
Key switch
ZB5 AFD
see page 36015/4
For double-headed
pushbuttons, spring return
Knurled knob
(1)
ZB5 AF
see page 36015/4
Flush pushes (IP 40/IP 66)
Without/with marking
ZB5 AA81/AA82
ZB5 AA91/AA92
see page 36015/5
see page 36015/5
For "push-push to release”
pushbuttons
Flush push + projecting push (IP 40/IP 66)
Without/with marking
ZB5 AL83/AL84
ZB5 AL93/AL94
see page 36015/5
see page 36015/5
Flush push
ZB5 AH0//CH0
see page 36015/5
Projecting push
ZB5 AH
/
see page 36015/5
Flush push
ZB5 CH0
/
see page 36015/5
Characteristics :
pages 36011/2 to 36011/5
References :
pages 36012/2 to 36019/3
Dimensions :
pages 36021/2 to 36021/9
4
General
(continued)
Control and signalling units Ø 22
Harmony
®
style 5
Pushbuttons, switches and pilot lights with double
insulated bezel
Sub-assemblies, ZB5 A
0
Non illuminated units
for user assembly
(continued)
For mushroom head
pushbuttons, spring return
Contact functions
(continued)
Body
sub-assemblies
Head
sub-assemblies
Ø 30
Ø 40
Ø 60
Screw clamp terminals
ZB5 AZ10
/
/AZ141
see page 36015/2
For mushroom head
pushbuttons, latching, with
or without trigger action
Spring return
ZB5 AC/AR
see page 36015/6
Ø 30
Ø 40
Ø 60
Plug-in connector
ZB5 AZ10
/
4/AZ1414
see page 36015/2
Push-pull
ZB5 AT84/AT
/
/AX
/
see page 36015/7
Ø 30
Ø 40
Ø 60
Turn to release
ZB5 AS8
/
4/AS4
/
/ AS5
/
/AS6
/
see page 36015/7
Ø 30
Ø 40
Ø 60
Key release
ZB5 AS9
/
4/AS7
G
/AS1
G
/AS2
G
see page 36015/7
For selector switches
and key switches
(1) Switch handle
(2) Key switch
and knob positions
positions
Key withdrawal
positions
Standard handle
(1)
ZB5 AD
/
see page 36015/8
Long black handle
(1)
ZB5 AJ
/
see page 36015/9
Knurled black knob
(1)
ZB5 AD
/
9
see page 36015/10
For toggle switches
Key switch
(2)
ZB5 AG
/
/AG0
/
see page 36015/11
2-position
ZB5 AD
/
8
see page 36016/11
Characteristics :
pages 36011/2 to 36011/5
References :
pages 36012/2 to 36019/3
Dimensions :
pages 36021/2 to 36021/9
