IKH series
Surface mount half pitch DIP switches
• 1,27 mm (.050) terminal to terminal pitch
• Overall height from PCB : 1,6 mm (.063) only
• Very small PCB space requirement
• Process compatible - withstand IR and vapor phase reflow soldering
• Washable (tape seal standard)
➞
Tape
Tape & reel
IKH0204000
IKH0404000
IKH0604000
IKH0804000
IKH1004000
IC tubes (Qty)
IKH0203000
(125)
IKH0403000
(75)
IKH0603000
(54)
IKH0803000
(40)
IKH1003000
(33)
No
pos.
2
4
6
8
10
Dimension “A”
3,77 (.148)
6,31 (.248)
8,85 (.348)
11,39 (.448)
13,93 (.548)
(.242)
ON
(.060)
4.50
(.177)
1.50
(.004)
0.10
0.60
PAS 1.27
(.050) PITCH
0.40
(.016)
A
1.27x(P-1)
(.050x(P-1))
PAS 1.27
(.050) PITCH
(.024)
6.70
(.264)
6.15
Supplied with all poles in “ON” position.
Switches without tape seal : on request.
TAPE AND REEL PACKAGING
Unrolling direction
12.00
(.472)
1 2 3 4 5 6 7 8
(0.30)
SPECIFICATIONS
➞
• Max. current/voltage rating :
- switching : 25mA 24VDC
- non switching : 100mA 50VDC
• Initial contact resistance : 100 mΩ max.
• Insulation resistance : 100 MΩ min. at 500VDC
• Dielectric strength : 300 Vca min.
• Electrical life : 1.000 cycles
• Travel : 0,60 mm (.024)
• Operating temperature : -20°C to +70°C
• Storage temperature : -40°C to +85°C
4.90
7.40
0.76
(.193)
(.291)
F
1 2 3 4 5 6 7 8
Pos.
2
4
6
8
10
Tape dim. “L”
12,00 (.472)
16,00 (.629)
16,00 (.629)
24,00 (.944)
24,00 (.944)
Reel dim. “A”
12,40 (.488)
16,40 (.646)
16,40 (.646)
24,40 (.960)
24,40 (.960)
L
(12.992 DIA MAX)
(3.937 DIA MIN)
ø330.00 Maxi
le 11/04/02
Ø13.00±0.25
(.511 DIA±.009)
Ø100.00 mini
FICHIER:CIKHB
Echelle:1
ON
MATERIALS
• Case and cover : high temperature thermoplastic UL 94-V0, black
• Actuator : high temperature thermoplastic UL 94-V0, white
• Contacts : phosphor bronze, gold plated, over nickel barrier
• Terminals : tin plated
• Tape seal : polyimide
Antistatic packaging - standard packaging units
• Reels of 4.000 pieces
Tape meeting international standard IEC - Publication 286-3 (EIA481A)
• IC tubes : see above.
A
3.00
(.118)
Dimensions in mm and inches.
APEM
www.apem.com
F-17
