Miniature Low Profile (2.5" x 1.55" x 0.5") PCB Mountable
High Reliability DCDC Converters
Wide Input Range
6QP
12QP
24QP
48QP
4.5 9 Vdc
9 18 Vdc
18 36 Vdc
36 72 Vdc
Consult Factory for Special Input
FEATURES:
The QP Series of Miniature Power DC/DC Converters operates over wide
input voltage ranges (4.59Vdc, 918Vdc, 18 36 Vdc, and 36 72 Vdc)
while maintaining tight output regulation and low ripple.
Safety Features of QP Modules include: Overtemperature, Input
Under/Over voltage, Output Overcurrent and Short Circuit Protection.
Units in QP Series also feature Remote Shutdown, Trim capability, 3Vref,
External Bias and do not use OptoCouplers in the feedback loop.
Fixed Frequency operation enables parallel connection for higher power
requirements.
QP Series units are fully encapsulated for rugged operation.
APPLICATIONS:
Commercial, industrial and Military applications, process control, distributed
power, test equipment, telecommunications.
Input Voltage Ranges: 4.5 9 Vdc, 918Vdc, 1836Vdc., and 36
72 Vdc. For additional input voltages consult factory.
Output Voltage: 5Vdc to 500Vdc. 11 standard voltages, custom
output voltages are also available.
Line and Load Regulation: from 0.5% Vout
Efficiency: Up to 90%
Low Ripple
Input Under/Over Voltage Protection
Output Overcurrent and Short Circuit Protection
Output Voltage Clamp: typ. 120% Vout
Thermal Shutdown
Trim Capability: 5% Vout
3Vref output pin
Remote Shutdown
External Bias pin for capacitor charging applications
0°C to +85°C standard operating base plate temperature. Expanded
operating temperature also available
2500 Vrms In/Out Isolation
Fully Encapsulated
6QP SERIES
25W, SINGLE OUTPUT, 4.5 9Vin
PICO
MODEL
INPUT VOLTAGE
RANGE
(V)
OUTPUT
VOLTAGE
(V)
OUTPUT
POWER
MAX.
(W)**
20
20
25
25
25
25
25
25
20
20
20
EFF.
(TYP.)
@
FL
(%)
73
82
82
81
81
80
82
77
80
79
76
REGULATION
(MAX)
LINE
4.59Vin
(%)
4
2
2
1.5
1.5
2
3
3
2.5
2.5
2
LOAD***
10100%
FL
(%)
2
1.5
1.5
1
1
1.5
2
2
2
2
1.5
OUTPUT
VOLTAGE
RIPPLE
PkPk,@FL
(mVpp)
50
40
40
20
20
30
20
150
100
200
200
OUTPUT
VOLTAGE
SETUP
TOL.
(%)
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
PRICE
(US $)
6QP5.0
6QP12
6QP15
6QP24
6QP28
6QP48
6QP100
6QP200
6QP300*
6QP400*
6QP500*
4.5 9
4.5 9
4.5 9
4.5 9
4.5 9
4.5 9
4.5 9
4.5 9
4.5 9
4.5 9
4.5 9
5
12
15
24
28
48
100
200
300
400
500
159.14
159.14
159.14
159.14
170.59
182.04
223.26
280.50
337.75
372.09
400.72
* For these units, Pout max is linearly derated at 7.5W/V for input voltages lower than 5.5V
**Proper thermal management required: Base Plate Temp. <85°C (See Application Notes)
***10% minimum load required at any time
12QP SERIES
50W, SINGLE OUTPUT, 918Vin
EFF.
(TYP.)
@
FL
(%)
78
85
85
85
85
85
86
85
87
87
86
REGULATION
(MAX)
LINE
918Vin
(%)
3
1.5
1.5
1
1
1
1
1.5
1
1
1
LOAD***
10100%
FL
(%)
3
2
2
1.5
1.5
1.5
1.5
2
1
1
1
OUTPUT
VOLTAGE
RIPPLE
PkPk,@FL
(mVpp)
50
40
40
20
20
30
20
150
100
200
200
OUTPUT
VOLTAGE
SETUP
TOL.
(%)
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
PICO
MODEL
INPUT VOLTAGE
RANGE
(V)
OUTPUT
VOLTAGE
(V)
OUTPUT
POWER
MAX.
(W)**
40
40
50
50
50
50
50
50
40
40
40
PRICE
(US $)
12QP5.0
12QP12
12QP15
12QP24
12QP28
12QP48
12QP100
12QP200
12QP300*
12QP400*
12QP500*
918
918
918
918
918
918
918
918
918
918
918
5
12
15
24
28
48
100
200
300
400
500
159.14
159.14
159.14
159.14
170.59
182.04
223.26
280.50
337.75
372.09
400.72
* For these units, Pout max is linearly derated at 6.7 W/V for input voltages lower than 10.5V
**Proper thermal management required: Base Plate Temp. <85°C (See Application Notes)
***10% minimum load required at any time
24QP SERIES
50W, SINGLE OUTPUT, 1836Vin
PICO
MODEL
INPUT VOLTAGE
RANGE
(V)
OUTPUT
VOLTAGE
(V)
OUTPUT
POWER
MAX.
(W)**
40
40
50
50
50
50
50
50
40
40
40
EFF.
(TYP.)
@
FL
(%)
79
88
88
87
87
87
88
87
90
89
89
REGULATION
(MAX)
LINE
1836Vin
(%)
3
1
1
1
1
1
1
1
0.5
0.5
1
LOAD***
10100%
FL
(%)
2
1.5
1.5
1
1
1
1
1.5
1
0.5
1
OUTPUT
VOLTAGE
RIPPLE
PkPk,@FL
(mVpp)
50
40
40
20
20
30
20
150
100
200
200
OUTPUT
VOLTAGE
SETUP
TOL.
(%)
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
PRICE
(US $)
24QP5.0
24QP12
24QP15
24QP24
24QP28
24QP48
24QP100
24QP200
24QP300*
24QP400*
24QP500*
1836
1836
1836
1836
1836
1836
1836
1836
1836
1836
1836
5
12
15
24
28
48
100
200
300
400
500
159.14
159.14
159.14
159.14
170.59
182.04
223.26
280.50
337.75
372.09
400.72
* For these units,< Pout max is linearly derated at 3.3 W/V for input voltages lower than 21V
**Proper thermal management required: Base Plate Temp. <85°C (See Application Notes)
***10% minimum load required at any time
48QP SERIES
50W, SINGLE OUTPUT, 36 72 Vin
EFF.
(TYP.)
@
FL
(%)
81
83
84
88
88
89
89
89
90
87
89
REGULATION
(MAX)
LINE
1836Vin
(%)
2
1
1
1
1
1
1
1
0.5
0.5
1
LOAD***
10100%
FL
(%)
2
1
1
1
1
1
1
1.5
1
1
1.5
OUTPUT
VOLTAGE
RIPPLE
PkPk,@FL
(mVpp)
30
20
30
20
20
30
50
250
200
200
200
OUTPUT
VOLTAGE
SETUP
TOL.
(%)
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
PICO
MODEL
INPUT VOLTAGE
RANGE
(V)
OUTPUT
VOLTAGE
(V)
OUTPUT
POWER
MAX.
(W)**
40
50
50
50
50
50
50
50
40
40
40
PRICE
(US $)
48QP5.0
48QP12
48QP15
48QP24
48QP28
48QP48
48QP100
48QP200
48QP300
48QP400
48QP500
3672
3672
3672
3672
3672
3672
3672
3672
3672
3672
3672
5
12
15
24
28
48
100
200
300
400
500
159.14
159.14
159.14
159.14
170.59
182.04
223.26
280.50
337.75
372.09
400.72
** Proper thermal management required, Base Plate Temp <85° C (See Application Notes)
*** 10% minimum load required at any time
ELECTRICAL CHARACTERISTICS:
Input OV/UV Protection
6QP Series 12QP Series 24QP Series 48QP Series
UV SHDN
UV RESTART
OV SHDN
3.6
4.25
11
7.1 V
7.6 V
20 V
14.6 V
15.6 V
41 V
31.2V
31.8V
82V
OV RESTART
Converter Frequency: 150 kHz typical
Reference Voltage: 3Vdc +/0.2V, 10mA max.
Current Limit Protection: Hiccup Mode
Output Voltage Clamp: 120% Vout typical
Output Trimming Range: 5% max.
10.8
19.5 V
40 V
81.5V
Rtrim
connected between
TRIM DOWN
TRIM (Pin #4) and VREF (Pin #3)
Rtrim (kohm) calculation
for a specified /\ Vout (%)
(425/ /\ Vout)51
/\ Vout (%)
TRIM DN
1
374
Rtrim (kohm)
2
162
3
91
5
33
FIG. 2 Trim Down typical resistor values
For Trim Up: Consult Factory 8004311064
Remote Shutdown: Converter is turned off when Pin # 2 (SHDN) is clamped to Pin # 1 within less than 0.4 V
FIG. 3 Non Isolated Shutdown
Fig. 4 Isolated Shutdown
External Bias Function
Ex.B Voltage = 17...20Vdc; Ex.B Current = 20mA (typical)
External Bias should be used in Capacitor Charging applications. The QP unit will not startup under a shortcuicuit condition because the Internal Bias
Supply cannot develop the required startup voltage. To charge up a large capacitor, an external bias voltage should be used only until the output voltage,
Vout, reached 90 95% of its nominal value and therefore the internal bias voltage has come up and is able to sustain converter operation.
Note that during External Bias operation, output overload and short circuit protection are disabled and for this reason it is highly recommended as shown
in diagram to disable the External Bias supply after Vout reaches its nominal value and allow from that moment on for the internal bias voltage operation.
While on internal bias operation, overload and short circuit protections are restored.
For additional information, see Application Notes.
Base Plate Over Temperature Shutdown: 95+/5°C, nonlatching
Isolation Characteristics:
INPUT TO OUTPUT
INPUT TO BASE PLATE
OUTPUT TO BASE PLATE
Operating Termperature Range (Base Plate): 0°C to + 85 °C
Storage Temperature Range: 55°C to + 125°C
PHYSICAL CHARACTERISTICS:
Size (WxDxH): 2.5" x 1.55" x 0.5"
Weight: 75 grams
Fully Encapsulated
NOTES:
All specifications are given under following conditions: +25°C ambient, 6Vdc (6QP Series), 12Vdc (12QP Series), 24Vdc (24QP Series), and 48V
(48QP Series) Input at Full Load
For correct operation, a 10% maximum load should be maintained at all times
For expanded temperature range or nonstandard features, please consult factory.
