Series 518 Open Frame Capacitor
Collet Sockets with Solder Tail Pins
FEATURES:
• Capacitor bypasses unwanted electromagnetic “noise.”
• Available with either .1µF or .33µF capacitor, 50V, Z5U
temperature coefficient.
• Open frame allows for more efficient utilization of board
space and better cooling.
• Compatible with automatic insertion equipment.
• Side-to-side and end-to-end stackable.
SPECIFICATIONS:
• Body material is blue UL 94V-0 Glass-filled Polyester
Thermoplastic (PBT).
• Pin body is Brass Alloy 360 1/2 hard per UNS C36000 ASTM-
B16-85.
• Pin body plating is either 200µ [5.08µm] min. 93/7 Tin/Lead
per MIL-P-81728 or 10µ [.25µm] min. Gold per MIL-G-45204
over 100µ [2.54µm] min. Nickel per QQ-N-290.
Note: Aries specializes in custom design and production. In addition to the
• 4-fingered collet contact is Beryllium Copper Alloy per UNS
standard products shown on this page, special materials, platings, sizes, and
C17200 ASTM-B194-92.
configurations can be furnished, depending on quantities. Aries reserves the
right to change product specifications without notice.
• Contact plating is either 10µ [.25µm] min. Gold per MIL-G-
45204 or 150µ [3.81µm] min. 93/7 Tin/Lead per MIL-P-81728
ORDERING INFORMATION
over 50µ [1.27µm] min. Nickel per QQ-N-290. Heavy 30µ
[.76µm] Gold plating also available.
X X - X 5 1 8 - 1 X X X
Optional suffix:
H=Heavy Gold
• Contact current rating=3 Amps.
plating on
No. of pins
• Operating temperature=221°F [105°C] Tin plating,
collet
(see table)
=257°F [125°C] Gold plating.
T=Tin plating on
• Insertion Force=180 grams/pin; Withdrawal Force=90
Row-to-row spacing:
collet
grams/pin; Normal Force=140 grams/pin; based on a .018
3: “Y”=.300 [7.62]
E=Extra long
4: “Y”=.400 [10.16]
[.46] dia. test lead.
Series
solder tail
6: “Y”=.600 [15.24]
• Accepts leads .015-.025 [.38-.64] in diameter.
• Accepts lead lengths from .100 [2.54] min.
Solder tail pin
1=.1µF capacitor
MOUNTING CONSIDERATIONS:
Plating:
2=.33µF capacitor
•Suggested PCB hole size=.030 ± .002 [.76 ± .05] dia.
0=Gold collet/Tin shell
A
LL
DIMENSIONS
:
INCHES
[
MILLIMETERS
]
1=Gold collet/Gold shell
All tolerances ± .005 [.13]
unless otherwise specified
“W”=(NO. OF PINS PER ROW) X .100 [2.54]
“X”=(NO. OF PINS PER ROW - 1) X .100 [2.54]
Frame
Style
B
C
No. of
Ribs
2
3
Centers
“Y”
.300 [7.62]
.400 [10.16]
.300 [7.62]
.600 [15.24]
Dim.
“Z”
.400 [10.16]
.500 [12.70]
.400 [10.16]
.700 [17.78]
Available
Sizes
14, 16, 18, 20
20, 22, 24
24, 28
24, 28, 32, 40
SOLDER TAIL
EXTRA LONG “E”
STYLE B (2 RIB)
STYLE C (3 RIB)
Consult Data Sheet
No. 12027 for wire
wrap pins.
Consult Data Sheets
12016 and 12017 for
open frame sockets
w/out capacitor.
NORTH AMERICA
Frenchtown, NJ USA
TEL: (908) 996-6841
FAX:(908) 996-3891
12026
http://www.arieselec.com • info@arieselec.com
REV.C
PRINTOUTS OF THIS DOCUMENT MAY BE OUT OF DATE AND SHOULD BE CONSIDERED UNCONTROLLED
ABCDEFG
EUROPE
TEL: +44 870 240 0249
FAX: +44 871 919 6033
europe@arieselec.com
