VARITRONIX LIMITED
Specification
of
LCD Module Type
Model No.: COG-VLGT6566-04
1.
•
•
•
•
•
•
•
•
General Description
4.3” TFT, 480 x RGB x 272 dots, 16M Colors, positive, transmissive dot matrix LCD module.
Viewing angle: 6 o’clock.
Driving IC: ‘HIMAX’ HX8257-A (COG) TFT LCD controller & driver or equivalent.
Data interface: parallel RGB interface.
Logic voltage: 3.0V.
White LED backlight.
FPC connection.
“RoHS” compliance.
2.
Mechanical Specifications
The mechanical detail is shown in Fig. 1 and summarized in Table 1 below.
Table 1
Parameter
Outline dimensions
Active area
Display format
Color TFT
480xRGBx272 Color configuration
Dot pitch
Weight
Specifications
105.5(W) x 109.8(H) x 3.05(D)
95.04(W) x 53.86(H)
480 x RGB x 272
RGB stripe
0.198(RGB)(W) x 0.198(H)
(0.066(W) x 0.198(H))
Approx: 45
Unit
mm
mm
dots
-
mm
gram
MCU
