Ip67 outdoor rated
Industrial radio modem
Zlinx Xtreme Wireless Radio Modems
produCt FEaturEs
•
•
•
•
•
•
•
•
•
•
•
•
IP67 rated for outdoor applications
RS-232/422/485, serial communications
Modbus Compatible
Ranges to 40 miles (64 km) Line of Sight & Antenna Dependent
Heavy duty machine mount industrial grade case and components
Signal strength indicator aids trouble shooting
900 MHz and 2.4 GHz versions
Wide temperature range -40 to 74°C
Wide range power input: 10VDC to 30VDC
AES Encryption
UL Class1/Division2
NEMA TS2
Do you need to get a digital signal across a highway or river? Zlinx
®
Xtreme Radio Modems can do it faster, easier, and less expensively
than stringing cable. Easy plug-and-play set-up saves installation and
maintenance time. These compact and rugged IP67 units are ideal
for outdoor applications requiring Serial-to-Serial (RS-232/422/485)
connectivity or to connect Zlinx
®
Xtreme Wireless I/O’s to a Modbus RTU
Master over a wireless network. Point-to-Multi Point connections are
also possible.
Zlinx
®
Industrial Wireless products operate in license-free, Proprietary
RF 900 MHz and 2.4 GHz ISM bands. Select the 900 MHz version for
longer distances. For further flexibility, the output power is software
selectable.
The 900 MHz units offer 256 bit AES Encryption. The 2.4 GHz units have
128 bit AES Encryption.
ordErIng InFormatIon
Model nuMBer
deSCriPtion
Zlinx Xtreme IP67 900MHz Radio Modem, Long Range,
ZXT9-RM
RS- 232/422/485
Zlinx Xtreme IP67 2.4GHz Radio Modem, Short Range,
ZXT24-RM
RS-232/422/485
Zlinx Xtreme IP67 900MHz Radio Modem Kit, (2) Radio
ZXT9-RM-KIT
Modems, (2) 24VDC IP67 Power Supplies, (1) USB
Programming Cable
World-wide.
Check with your local distributor for availability and options.
* Check wireless regulations/standards in your geographic area.
aCCEssorIEs
CLG-60-24
ZXT9-ANT
ZZ24D-ANT1
ZXTMT
IP67 Power Supply, Panel Mount, 24V DC, 60W
900 MHz Spare Antenna
2.4 GHz Spare Antenna
Zlinx Xtreme Conduit Kit
www
.
bb
-
elec
.
com
|
Zlinx Xtreme Wireless Radio Modems_3713ds
Ip67 outdoor rated
Industrial radio modem
Zlinx Xtreme Wireless Radio Modems
spECIFICatIons
rF ProPertieS
Physical Standard
802.15.4
FrequenCy
ZXT9-RM
900 MHz ISM (902-928 MHz)
ZXT24-RM
2.4 GHz ISM (2.4 to 2.5 GHz)
tranSMit Power
1 mW, 10 mW, 100 mW, 500 mW
ZXT9-RM
1 W – Software Selectable
10 mW, 16 mW, 25 mW, 30 mW
ZXT24-RM
63 mW – Software Selectable
Receiver Sensitivity
-100 dBm
oVer the air data rate
ZXT9-RM
9.6 or 115.2 kbps
Software Selectable
ZXT24-RM
250 kbps
outdoor range
Supplied Antenna 14 mi (23 km)
ZXT9-RM
High Gain Antenna 40 mi (64 km)
Supplied Antenna 1.5 mi (2.4 km)
ZXT24-RM
High Gain Antenna 10 mi (16 km)
Range estimates based on optimal RF conditions and an unobstructed line of sight.
Serial ProPertieS
data rates
ZXT9-RM
ZXT24-RM
Data Bits
Parity
Stop Bits
Flow Control
RS-232
RS-422
RS-485 (2/4 Wire)
SD Control
Termination
Industrial Bus
Power
Power Connector
Input Voltage
Power Use
enVironMent
Dimensions
Operating Temp
Storage Temp
Op Humidity
Enclosure Rating
Use
CertiFiCationS
UL
CE
1.2 to 230.4 kbps
1.2 to 115.2 kbps
8
None, Even, Odd, Mark, Space
1 or 2
None or Software
Connector: Terminal Block
Signals: TD, RD, RTS, CTS, GND
Connector: Terminal Block
Signals: TDA(-) TDB(+) RDA(-) RDB(+) GND
Connector: Terminal Block
Signals (4-Wire): TDA(-), TDB(+), RDA(-), RDB(+), GND
Signals (2-Wire): Data A(-), Data B(+), GND
Automatic Bit Wise
120Ω Ohm DIP Switch Selectable
MODBUS RTU
Terminal Block
10 to 30 VDC
ZXT9-RM: 1.7 W (typical), 5.8 W (maximum)
ZXT24-RM: 1.2 W (typical), 3.5 W (maximum)
5.12x5.12x2.37 in /130.1x130.1x60.2 mm
-40° to 74°C (-40 to 165°F)
-40° to 85°C (-40 to 185°F)
0 to 95% (Non-Condensing)
IP67
Indoor and Outdoor
UL, cUL, Class 1 Div 2 Groups A, B, C, D File E245458
EN55022: 2006 – Class A
EN61000-6-1: 2006 – Heavy Industrial
EN61000-4-2:2008 – ESD
EN61000-4-3:2006 – EFT
EN61000-4-6:2005 – Cond. Immunity
Class A
FCC ID – ZXT9-RM – OUR-9XTEND
FCC ID – ZXT24-RM – OUR-XBEEPRO
tranSMiSSion Method
ZXT9-RM
ZXT24-RM
Modulation
Channel CaPaCity
ZXT9-RM
ZXT24-RM
Network Topologies
enCryPtion
ZXT9-RM
ZXT24-RM
SuPPlied antenna
FHSS
DSSS
FSK
10 hop sequences share 50 Frequencies
12 Direct Sequence Channels
Peer-to-Peer, Point-to-Point,
Point-to-Multi Point
256 bit AES
128 bit AES
Impedance – 50 Ω
Connector – RPSMA Female
VSWR – 2.0 Max (in-band)
Gain – 3 dBi
Polarization – Vertical
Length – 7.8 in (198 mm)
Impedance - 50Ω
Connector – RPSMA Female
VSWR – 2.0 Max (in-band)
Gain – 2.1 dBi
Polarization – Vertical
Length – 4.38 in (113 mm)
RPSMA Male
Win XP, 7
RSSI signal range test
ZXT9-RM
FCC
ZXT24-RM
Modem Antenna Con.
SoFtware
Support
Features
NEMA TS2
ControlS and indiCatorS
Signal Strength
8 Green RSSI LED’s indicate signal strength
Power
Green LED
Receive Data
Green LED
Transmit Data
Green LED
Programming Port
USB
Reset
Push Button
