ARIZONA OPERATION
ISO 9001 Certified
COAXIAL RESONATOR OSCILLATORS
•
•
•
High stability, fixed frequency source
0.75 to 2.9 GHz frequency coverage
Mechanical and electrical tuning options
PARAMETER
8100 Series (Commercial)
7100 Series (Military)
Frequency Range
0.75 – 2.9 GHz
0.75 – 2.9 GHz
Frequency Stability
+.03%
+.05%
Power Output
+8 dBm (min)
+8 dBm (min)
Power Stability vs. Temperature
+0.8 dB
+.1.0 dB
Harmonics
-15 dBc (max)
-15 dBc (max)
Load Pulling 2:1 VSWR
.05% (max)
.08% (max)
Supply Pushing
.04%/V (max)
.05%/V (max)
Input Voltage
+12 to +15 Vdc
+12 to +15 Vdc
Input Current
50 mA (typ)
50 mA (typ)
Temperature Range
0°C to +60°C
-45°C to +85°C
Tuning
None*
None*
Mechanical Dimensions
1.50” x 1.60” x 0.65”
Notes: *Mechanical tuning to 10% and electrical tuning to 0.5% available as options
HIGH PERFORMANCE MODEL
PARAMETER
Frequency Range
Frequency Stability
Power Output
Power Stability vs. Temp
Harmonics
Load Pulling 2:1 VSWR
Supply Pushing
Input Voltage
Input Current
Temperature Range
Tuning
Mechanical Dimensions
8110 Series
(Commercial)
0.75 – 2.9 GHz
+.03%
+16 dBm (min)
+0.8 dB
-35 dBc
.03%
<2 kHz/V
+12 to +15 Vdc
95 mA (typ)
0°C to +60°C
None
7110 Series
(Military)
0.75 – 2.9 GHz
+.06%
+15 dBm (min)
+1.0 dB
-35 dBc
.04%
<2 kHz/V
+12 to +15 Vdc
95 mA (typ)
-45°C to +85°C
None
1.50” x 2.50” x 0.65”
Options
0.75 – 2.9 GHz
+.01%
To +25 dB
+0.4 dB
To –60 dB
.001%
<2 kHz/V
+5 to +24 Vdc
Depends on Options
-45°C to +100°C
Mechanical to 10%
Electrical to .5%
Signal Technology Corp., Arizona Operation
340 N. Roosevelt Avenue, Chandler, AZ 85226
Tel:
480-940-1655
Fax:
480-961-6297
www.sigtech.com
May 2002
